Emerald Green Distortion Machine Electrical Specification; Notes - BJF Electronics EMERALD GREEN DISTORTION MACHINE Owner's Manual

address to where you want it to be sent. Any tampering with the circuit or obvious signs
of misuse will void the warranty. Send to manufacturer address (see below).
The unit will be repaired or replaced as appropriate at prepaid shipping cost.
Any polite questions will be answered promptly by the manufacturer.
The fastest way to get a reply is always to contact the distributor
This product is distributed by:
Custom-Sounds
Neulaspolku 3
35100 Orivesi Finland
www.custom-sounds.com
info@custom-sounds.com
Emerald Green Distortion machine ELECTRICAL
SPECIFICATION
Z in at 1kHz
Pout 1kHz in 50k
Max load
Max output
Max current consumption
Upper freq.-3dB
Max gain at 1KHz
Max inputsignal
Suppl. Voltage range
Power requirements
Notes: EGDM will distort easier at lower voltage. Maintain recommended voltage for best
results EGDM is protected against false polarity and will not take harm by false polarity
only not work under such conditions. Normal operation is resumed with correct polarity
The manufacturer claims that the above mentioned product fulfils the requirements as set
by
EN 55 013, EN 55 020, EN 60 555-2 and EN 60 555-3.
Manufactured by:
BJF Electronics
Sweden
app. 500K
app. 0uW35 RMS
app. 10K
1V peak
3mA at 10V
app. 10KHz
app. 60 dB
3V peak
7V5-18V
6F22 9V battery or DC
eliminator 2,1 mm plug
center negative and positive
sleeve
