OWNER'S MANUAL

COMBINE

CALC-U-DRI II

With Averaging

PNEG-1138

Date: 9-21-06

PNEG-1138

Table of Contents

Need help?

Do you have a question about the Combine CALC-U-DRI II and is the answer not in the manual?

Questions and answers

Summary of Contents for DMC Combine CALC-U-DRI II

Page 1 OWNER’S MANUAL COMBINE CALC-U-DRI II With Averaging PNEG-1138 Date: 9-21-06 PNEG-1138...
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instructions Introduction to DMC’s Combine Calc-U-Dri II Operation 1 - 2 Installation of Control Box & Digital Display 3 - 5 Installation of Sensor 5 - 7 Installation of Averaging Switch 8 - 9 Sampling Procedure...
Page 3: Operation
Distribution Center or DMC’s factory in Mason City, Iowa (See the listings on page 15.) OPERATION The Combine Calc-U-Dri II control box is designed to be mounted to the ceiling of a combine cab. Always refer to the owners manual for installation and operating infor- mation.
Page 4 After a delay of approximately six (6) seconds, the “AVG ON” light will turn on. This light indicates that the Combine Calc-U-Dri II moisture reading is being used to update both the short and long averages. If sufficient grain is not present to keep the average switch covered, the “AVG ON”...
Page 5: Installation Of Control Box & Digital Display
CONTROL BOX INSTALLATION The Combine Calc-U-Dri II control box is designed to be mounted to the ceiling of the combine cab or any convenient location. Select a location in the cab and check the area above for any hoses, tubes or electrical wiring that could be dam- aged by the control box mounting screws.
Page 6 CONTROL BOX INSTALLATION (continued) For installations where the control box is to be mounted to a flexible surface, it may be desireable to use a back-up plate or brackets to stiffen the mounting surface. Use the cover of the control box as a template to mark the location of the six (6) mounting holes on the back-up plate or brackets.
Page 7: Installation Of Sensor
CONTROL BOX INSTALLATION (continued) Feed the power supply wires through the same grommet and route them to a convenient power source in the cab. Make sure that one end of the red wire is connected to the positive (+) side of a power source and the other end to terminal number five.
Page 8 SENSOR INSTALLATION (continued) Mark the flighting that sweeps over the sensor hole and disassemble the auger tube from the flighting. Locate the marks made on the flighting above the sensor hole and weld the flighting to the auger shaft starting 3/8” beyond each end of the marks. Cut approximately six and one-half inches (6-1/2”) of flighting out between the welds and smooth out any rough edges on the flighting ends and on the auger shaft.
Page 9 SENSOR INSTALLATION (continued) Use a self drilling screw to attach the ground strap to the auger tube 90 degrees up from the sensor. See Photo F. Make sure that the sensor is oriented properly in the tube. Note the direction of the grain flowing over the sensor blade.
Page 10: Installation Of Averaging Switch
AVERAGING SWITCH INSTALLATION The averaging switch should be mounted in the boot housing of the clean grain auger. so that grain being thrown hits and accumulates on the yellow face of the switch. See Diagrams 3 - 6. The switch must be horizontal and facing oncoming grain.
Page 11 AVERAGING SWITCH INSTALLATION (continued) Drill a 15/32” hole through the housing next to the bracket and insert a grommet. Run the cable from the switch through this grommet. Secure the cable to the bracket using a plastic wire tie ran through the two small holes. Make sure the cable is protected from oncoming grain by placing the cable and grommet directly behind the bracket.
Page 12: Sampling Procedure
SAMPLING PROCEDURE !!CAUTION!! *Always stop the combine (travel, thresher and unload auger) before getting a sample. Ideally, stop the combine engine! *Be careful when climbing into the grain hopper. Follow the combine manufacturer’s recommendations. The following procedure should be done prior to the hopper auger being covered with grain and should be done when the moisture of the grain is at the level of which you are most concerned: If the meter is changing rapidly, it is possible to have a sample that is either...
Page 13: Parts Listing
COMBINE CALC-U-DRI II PARTS (21) (22) (11) (13) (16) (15) (29) (30) (31) (12) (14) (10) (18,19,20) (17) Reference Part Number Number Number Required Description 602E382 Calc-U-Dri Sensor, Complete 602E091 Sensor Clearance Gauge (not shown) MS0309 As Req’d Worm Gear Clamp 38” Long (not shown)
Page 14: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE PROBLEM PROBABLE CAUSE SOLUTION Digital readout dead Ignition switch is off Turn on Power switch is off Turn on Control fuse (2 Amp) Replace is blown Bad circuit board Replace circuit board Bad digital readout Replace digital readout Moisture readings Moisture on sensor...
Page 15 TROUBLE SHOOTING GUIDE (continued) PROBLEM PROBABLE CAUSE SOLUTION Moisture readings Check for the sensor Hook up strap are intermittently ground strap not high then low hooked up Sensor cable is Replace sensor damaged. and cable Loose terminal leads Tighten where sensor leads are hooked to screws.
Page 16 Contact your dealer or DMC if you have any questions on the operation or service of your combine Calc-U-Dri Moisture Monitor. TAKE TIME FOR PROPER INSTALLATION --- IT SAVES SERVICE CALLS!
Page 17: Warranty
COMBINE CALC-U-DRI OFFSET RECOMMENDATIONS The Combine Calc-U-Dri can be used with various grains by calibrating the moisture offset. After determining an offset value for a particular grain and grain condition, log the offset value on the following chart for future reference. A few grains and approximate offset values are already listed to assist with your initial calibration.
Page 18: Optional Elevator Sampler Installation
“off” to control the auger motor in the combine sampler. The sensor housing is designed for a DMC Calc-U-Dri moisture sensor which is held in place with 2 latches. The sensor ground wire should be attached to the flange of the housing with a #10 self- tapping screw.
Page 19 Combine Elevator Grain Sampler Parts List 1EL0709 Fuse, 15 Amp AGC 32 volt 405L004 Decal, “Disconnect power before servicing” 5041332 Auger motor with wiring connector 5041333 Intake housing 5041338 Intake housing spacer 5041339 Auger/sensor housing, R.H. 5041340 Auger/sensor housing, L.H. 5041344 Auger motor mounting plate 5041345...
Page 23 The GSI Group, Inc. Warranty THE GSI GROUP, INC. (“GSI”) WARRANTS ALL PRODUCTS WHICH IT MANUFACTURES TO BE FREE OF DEFECTS IN MATERIAL AND WORKMANSHIP UNDER NORMAL USAGE AND CONDITIONS FOR A PERIOD OF 12 MONTHS AFTER RETAIL SALE TO THE ORIGINAL END USER.
Page 24 Authorities having jurisdiction should be consulted before installation occurs. For more information, contact the DMC Distribution Center closest to you. Illiana Distribution Center Clear Lake Distribution Center 1004 E. Illinois St.
