DPW-199C
58
This appliance is certified for use without any limitation of the any altitude
61
installation. However for better combustion, from 2,000ft to 4,500ft
62
installation decrease the manifold pressure 0.3' W.C.for Natural Gas.
64
From 4,500ft to 6,000ft installation derease the maniforld pressure 0.6'W.C.
from the regular manifold pressure for Nature Gas. For installation above
6,000ft or for specific instructions on how to adjust the manifold pressure,
73
please contact
Quiteside
technical
support
4
.
