6
STARTUP PROCEDURE
A. Use the monitor's power switch
(last button on the right) to turn
on the monitor.
C. If the amplifier has a gain control,
turn it fully ON (clockwise). Then
turn the POWER switch ON to power
up the amplifier.
Refer to the Help files for
SUPPORT
operating and troubleshooting
instructions.
B. Depress the 3110A POWER
switch to turn the 3110 ON.
D. Wait for the 3110A to load (loading
will take up to 30 seconds). Then
open the on-screen Help system for
help with 3110A System Calibration
and Operation.
OR
Contact AE Techron Tech Support at 574-295-9495.
WAVEFORM GENERATOR
QUICK START GUIDE
97-8003840
05-13-2019
3110A
STANDARDS
www.aetechron.com
Advertisement
Table of Contents
Summary of Contents for Aetechron 3110A
- Page 1 WAVEFORM GENERATOR QUICK START GUIDE C. If the amplifier has a gain control, D. Wait for the 3110A to load (loading will take up to 30 seconds). Then turn it fully ON (clockwise). Then open the on-screen Help system for...
- Page 2 CONTROLS, CONNECTORS AND INDICATORS INSTALLATION/MOUNTING The 3110A controller can be placed on a desk or DIAGNOSTICS PORT bench top for convenient operation. Or you can use the rack “ears” located on each side of the front panel to mount the controller to a standard EIA rack (2U).
