10 GALLON FREESTANDING SOLAR SHOWER
ITEM: 75033
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE
PRODUCT'S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM
(OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Summary of Contents for Xtreme Power 75033
- Page 1 10 GALLON FREESTANDING SOLAR SHOWER ITEM: 75033 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
- Page 2 IMPORTANT SAFETY INFORMATION SAFETY The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating.
- Page 3 PRODUCT FEATURES Outdoor Solar Shower Powered Adjustable Hot & Cold Water Base Shower Head Connects to Garden Hose 7ft This Solar shower allows you to take a refreshing shower in your garden or by your pool before or after swimming. The shower easily connects to your garden hose, then through solar energy it heats the cold water up to 140°F for a perfect outdoor shower.
- Page 4 PARTS DIAGRAM TOP PLATE SHOWER HEAD PIPE SHOWER HEAD SHOWER TUBE HOSE CONNECTION DRAIN SCREW HANDLE FAUCET BASE PLATE BOLTS & WASHERS...
- Page 5 INSTALLATION 1. Drill holes in the concrete floor or other solid ground. Fix the shower to the ground using the bolts in the parts bag. Make sure the solar shower will not collapse due to strong wind and other external forces. 2.
- Page 6 INSTALLATION GARDEN HOSE CONNECTOR Shower Male Thread Shower Female Connector Garden Hose Connector OPTION 1: Firstly, connect the double female connector with the inlet and outlet connector. Then, connect the male thread end of the ball valve to the double female connector. NOTE: Both the thread of the double female connector and the inlet and outlet connector are 3/4 NH thread.
- Page 7 DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
