Summary of Contents for Global Coinco Four-Tube 700 Series
- Page 1 ® 7 0 0 COINCO FOUR TUBE 700 SERIES O P E R AT I O N A N D S E R V I C E M A N U A L...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION 1: GENERAL INFORMATION Introduction .................... 3 For Your Records ................... 3 Payout Configurations ................4 Features ....................5 After Unpacking ..................5 Specifications ..................5 SECTION 2: INSTALLATION Installing the Changer ................6 SECTION 3: CONFIGURATION Single Price “S”... -
Page 3: Section 1: General Information Introduction
COINCO FOUR-TUBE coin changer. cate when the unit was built which is also the beginning of the warranty period. The first two COINCO FOUR-TUBE 700 Series Changers digits indicate the week of manufacture; the can accept and validate up to 16 different coins third and fourth digits indicate the year of or tokens ranging in diameter from 15.5 to 32.5... -
Page 4: Payout Configurations
SECTION 1: GENERAL INFORMATION Payout Tube Location Configuration $1.00 $1.00 $1.00 $1.00 $1.00 $1.00 $1.00 $1.00 $1.00 $1.00 Example: USD-G706 = United States Dollar, MDB 700 series, 5-10-10-5 payout CAD-L701= Canadian Dollar, Logic 700 series, $1-10-5-25 payout NOTE: “L” model changers should only be configured as 701, 702, or 708. -
Page 5: Features
• Programmable acceptor allows for easy Power Requirements (by model) reconfiguration of coin tubes in the field. • The COINCO GLOBAL® coin changer has MDB-(G) ..........34V DC a modular design for easy service. • Individual tubes snap in and out of housing Single Price-(S) ...... -
Page 6: Section 2: Installation
SECTION 2: INSTALLATION Installing The Changer Remove power from vendor. Remove the acceptor from the changer by pressing down and releasing the acceptor latch, releasing the acceptor. Rotate the top of the acceptor forward, away from the changer (see figures 1 and 2). Unplug the ribbon cable from changer. - Page 7 SECTION 2: INSTALLATION Figure 3 Figure 4 % 5AHEAI 2=CA%...
-
Page 8: Section 3: Configuration
SECTION 3: CONFIGURATION Single Price “S” Models SWITCH D (SWITCH 12) When to enter “Use Correct Change” condition. SETTING THE VEND PRICE/OPTION The changer will use the vend price plus SWITCH the largest denomination coin accepted Located behind the acceptor in the middle right (U.S. -
Page 9: Canadian Four Price Changers
SECTION 3: CONFIGURATION Canadian Four Price SWITCH C (SWITCH #11) Vend signal length Changers Vend signal is held until a selection is SETTING THE VEND PRICE made Vend signal is pulsed (300msec) Located behind the acceptor in the middle right hand side of the changer housing are twelve SWITCH D (SWITCH #12) switches (see Figure 2). -
Page 10: Setting The Vend Price On A Four-Price Changer
SECTION 3: CONFIGURATION Setting The Vend Price On VIA GLOBAL SUPPORT TOOLS Consult Global Support Tools manual for price A Four-Price Changer setting instructions. The vend price may be set on a four-price Setting The Vend Price On changer in two ways: •... -
Page 11: Float Mode
SECTION 3: CONFIGURATION Float Mode Example: A USD-G710 has four nickel tubes. If you are hand loading the payout tubes and do Float Mode is used to reduce the number of not have enough nickels to completely fill all coins kept in a tube to a level anywhere be- four tubes, load each tube with approximately tween the upper and lower tube sensors. -
Page 12: Setting The Float Mode Levels
SECTION 3: CONFIGURATION SETTING THE FLOAT Replace the tube and shim assemblies by inserting the tube’s dovetails into the guides in MODE LEVELS the housing and push down. The Float Mode Levels for both Float Level Coin tubes should be arranged in the order and Float Pay-Down are set for all four tubes specified on page 2. -
Page 13: Rerouting The Coins
SECTION 3: CONFIGURATION Rerouting the Coins Example: For a payout configuration of 25 – 10 – 10 – 05 (USD-_ 708) Whenever the coin tubes are rearranged, the -Press and release inventory button A, insert a programmable acceptor has to be reconfigured quarter through the acceptor. -
Page 14: Section 4: Maintenance Routine Maintenance
SECTION 4: MAINTENANCE Routine Maintenance For more detailed cleaning of the acceptor, remove the front cover by opening the coin tube Routine maintenance will improve performance loading door and wedge your thumb underneath and extend the life of your COINCO FOUR- the front cover. -
Page 15: Clearing Coin Jams
SECTION 4: MAINTENANCE REMOVING THE LOGIC BOARD COVER REMOVING THE CASHBOX CHUTE To remove the logic board cover, first remove From the backside of the changer housing, the strain relief bracket and screw. Next, remove the tape seal from the cashbox chute. remove the screw in the lower center portion of Lift the bottom of the chute up and slide the the logic board cover. -
Page 16: Section 5: Troubleshooting
SECTION 5: TROUBLESHOOTING TROUBLESHOOTING GUIDE TROUBLE POSSIBLE CAUSE PROCEDURE REMEDY No coin acceptance No power Make sure changer Plug changer into is plugged into vendor. into vendor. Acceptor Check Acceptor LED. Replace acceptor. If LED is on, replace acceptor. If still no coin acceptance, Replace changer’s main logic board. - Page 17 SECTION 5: TROUBLESHOOTING TROUBLESHOOTING GUIDE TROUBLE POSSIBLE CAUSE PROCEDURE REMEDY Accepted Coins Always Front Cover Check front cover for proper Clean or replace front cover. Go to Cashbox installation, check the mirrors Acceptor If coin still goes to cashbox, replace Reprogram acceptor coin acceptor with good acceptor and test routing.
-
Page 18: Section 6: Views Dimensional Views
SECTION 6: EXPLODED VIEWS 700 Series Dimensional View ALL MEASUREMENTS ARE SHOWN IN CENTIMETERS 5.84 13.89 6.65 6.15 6.83 2.51 2.21 R 17.30 International Max Opening 1.09 Lever 1.80 7.62 35.71 13.89 10.57 6.15 3.73 Ø .48 3X .63 Coin Return Area Ø... -
Page 19: Harness And Logic Board Configuration
SECTION 6: EXPLODED VIEWS 700/800 Series Harness and Logic Board Configuration “L” HARNESS 407621 “G” (MDB) “G” (MDB) HARNESS HARNESS 407544 407544 SMALL PLUG “G” (CONNECTOR) LARGE PLUG PROTOCOL “L ” HARNESS (2 REQ’D) SMALL (CONNECTOR) “G” (MDB) PLUG HARNESS (CONNECTOR) 407526 407499... - Page 20 CCEPTORS PRODUCTS ARE PATENTED AND PATENTS ARE PENDING IN THE NITED TATES AND THROUGHOUT THE WORLD ® Coin Acceptors, Inc. World Headquarters 300 Hunter Avenue St. Louis, MO 63124-2013 Phone: (314) 725-0100 Coinco Publication No. 922227-7 Rev. 3 2/99 Printed in the U.S.A.
