- Page 1 HD100BaseT-In-Wall-Balun 4K/18Gbps Wall Plate Switcher for HDMI & VGA Inputs 4159 McConnell Drive Burnaby BC Canada V5A-3J7 Tel: 778-800-1918 Mail: info@factorelectronics.com www.factorelectronics.com info@factorelectronics.com...
- Page 2 Thank you for purchasing the Factor Electronics HD100BaseT-In-Wall-Balun. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
Table of Contents Introduction ....................... 4 Features ........................4 Panel Descriptions ....................5 Application Diagram ....................8 Specifications ......................8 Package Contents ..................... 9 Maintenance ......................10 Warranty Policy ....................... 10 Limitations of Warranty.................... 10 Exclusive Remedies ....................11 RMA Policy ......................12 Standard Replacement .................. -
Page 4: Introduction
Introduction The HD100BASET-IN-WALL-BALUNis an HDMI 2.0 HDBaseT transmitter/receiver Kit designed as North America two-gang Wall-plate with switchable HDMI and VGA/Audio inputs. It supports 4K/60Hz with 4:4:4 chroma sampling, as well as HDMI data rates up to 18Gbps. It can extend HDMI/VGA signals up to 330ft (100m) for 1080p video, and up to 229ft (70m) for 4K HDR over CAT5e/6a/7 cable. -
Page 5: Panel Descriptions
Panel Descriptions TX Transmitter Front Panel Active Input LED indicator – Illuminates when an Active HDMI/VGA signal is connected Link LED indicator – Illuminates when the HDBT Out on the TX unit is properly connected to the HDBT In on the RX unit. Input selection button –... - Page 6 L/R Input -- 3.5mm stereo phone-jack, NOTE: the analog audio input 3.5 jack is modulated with the VGA signal. Without a valid VGA connection the 3.5mm jack will not transmit audio. HDMI Input – Connect an HDMI cable from this port to an HDMI source. Rear Panel Mode DIP Switch –...
- Page 7 10: MCU firmware upgrade 11: Valens RS232 pass through & MCU firmware upgrade Micro USB port – Used for firmware upgrade HDBT Output – Connect to HDBT Input on the RX unit. RS232 port -- 3-pin phoenix terminal connector. DC Power port - - 2-pin phoenix terminal connector, connect to 24V/1A DC power supply if power is not available at the RX end.
-
Page 8: Application Diagram
upgrade mode. As below: 00: RS232 pass through 01: Valens firmware upgrade 10: MCU firmware upgrade ⑦ RS-232 port -- DB9 female connector, connect to a DTE or DCE ⑧ HDBT Input -- RJ45 connector, connect to the HDBT Out port of the transmitter via cat5e/6 ⑨... -
Page 9: Specifications
Specifications Bandwidth 18Gbps 18Gbps Video Input Connectors 1x HDMI, Type A, 19 Pin, female 1x HDBaseT RJ45 connector 1x VGA, 15-pin, female Audio Input Connectors 1x 3.5mm stereo earphone jack (L/R) Audio Output Connectors 1x 3.5mm L/R analogue audio, 1x digital coaxial (RCA) Video Output Connectors 1x HDBaseT RJ45 connector... -
Page 10: Maintenance
Limitations of Warranty The warranty does not apply to any part of a product that has been installed, altered, repaired, or misused in any way that, in the opinion of Factor Electronics, would affect the reliability or www.factorelectronics.com info@factorelectronics.com... -
Page 11: Exclusive Remedies
The warranty does not cover damage or loss incurred in transportation of the product. The warranty does not cover replacement or repair necessitated by loss or damage from any cause beyond the control of Factor Electronics, such as lightning or other natural and weather related events or wartime environments. -
Page 12: Rma Policy
RMA Policy When returning product to Factor Electronics for any reason, the customer should fill out the official RMA form to obtain a RMA number. Without the permission or approval, Factor Electronics will be no responsible for any return. -
Page 13: Once You Have Obtained An Rma Number
Shipping your RMA to Factor Electronics using regular mailing envelopes is not acceptable, as they do not protect the product from damage during shipping. Factor Electronics will not repair or replace a module that is shipped in such a way that the product is not properly protected. - Page 14 www.factorelectronics.com info@factorelectronics.com...
