HearthRite HVF2R18N-2 User's Manual And Operating Instructions

Vent-free gas log heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

HVF2R18N-2 / HVF2R18P-2
WARNING
This appliance
is equipped
for natural or
propane gas. Field
conversion is not
permitted.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or loss of life.
•
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
•
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
•
Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to the AIR FOR COMBUSTION
AND VENTILATION section on page 8 of this manual.
This appliance may be installed in an aftermarket, permanently located, manufactured (mobile)
home, where not prohibited by local codes. This appliance is only for use with the type gas
indicated on the rating plate. This appliance is not convertible for use with other gases.
CONSUMER: Retain this manual for future reference.
!
CAUTION —FOR YOUR SAFETY
INSTALLER: Leave this manual with the appliance.
Models:
HVF2R24N-2 / HVF2R24P-2
VENT-FREE
GAS LOG HEATER
User's Manual and Operating
Instructions
ANS Z21.11.2-2019
ANS Z21.60-2017
MC NO. 274387
•
CSA 2.26-2017
HR2008VFL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVF2R18N-2 and is the answer not in the manual?

Questions and answers

Related Manuals for HearthRite HVF2R18N-2

Summary of Contents for HearthRite HVF2R18N-2

  • Page 1 VENT-FREE GAS LOG HEATER User’s Manual and Operating Instructions Models: HVF2R18N-2 / HVF2R18P-2 HVF2R24N-2 / HVF2R24P-2 WARNING This appliance is equipped for natural or propane gas. Field ANS Z21.11.2-2019 conversion is not • ANS Z21.60-2017 CSA 2.26-2017 permitted. CAUTION —FOR YOUR SAFETY MC NO.
