Summary of Contents for Alango Technologies BeHear Access MODEL II
- Page 1 MODEL Hearing Amplifier in a Bluetooth Stereo Headset ® Model: ABH-120 Quick Start Guide Live Mobile/ Conversation Video Calls Listening Music Looped Tinnitus & Audio Venues Masking...
- Page 2 Wearing Recommendations When not in use, ear buds can be secured with magnets and rest on your chest. If you have an ICD or pacemaker, avoid close or prolonged contact with magnets or their magnetic fields. Keep headset magnets at least 1 inch from where your device is implanted.
- Page 3 Ear Fittings If the default fittings are not comfortable, replace them. Choose an ear hook with a comfortable fit. Ÿ Note the “ ” and “ ” symbols for “Left” and “Right” on each ear hook. Replace the ear bud, squeezing it gently to attach it Ÿ...
- Page 4 Powering the Headset LED indicator To turn ON BeHear ACCESS Ÿ press and hold the power button until the unit vibrates and the LED turns light blue. Power button To turn OFF BeHear ACCESS press and hold the power Ÿ button until the unit vibrates, and the light blue LED turns off.
- Page 5 Live Hearing Amplification Use the LEFT-HAND controls as follows: Increase the volume. Decrease the volume. Use the RIGHT-HAND controls as follows: Long press to toggle hearing amplification ON/OFF. Short press to scroll through the hearing profiles. Change the tonal balance to emphasize high frequencies.
-
Page 6: Connecting To A Bluetooth Device
Connecting to a Bluetooth Device To use your BeHear headset for mobile calls or audio streaming, you need to connect it to a phone or other device via Bluetooth. If BeHear is ON, press the power button until the LED switches off. Press the power button for about 5 seconds, until the LED starts alternating red/blue. - Page 7 Mobile Phone Calls Use the LEFT-HAND controls as follows: Short press to accept incoming call. Short press to end the active call. Long press to reject an incoming call. Double press to redial last number. Increase the call Decrease the call volume.
-
Page 8: Audio Play
Audio Play Manage audio play from a Bluetooth-connected device using the LEFT-HAND controls. Short press to toggle Play/Pause audio. Double press to forward to the next audio track. Triple press to return to the previous audio track. Increase the volume. Decrease the volume. - Page 9 Audio Transparency & Tone Control Stay alert with ListenThrough™ while listening to music, and control treble and bass balance using the RIGHT- HAND controls. Long press to toggle ListenThrough ON/OFF. Change the tonal balance to emphasize high frequencies. Change the tonal balance to emphasize low frequencies.
- Page 10 Smartphone Application (optional) Get truly personalized results based on a hearing assessment in our dedicated W&H BeHear app . Also use the app to manage, customize and get support for your BeHear headset. Download the app from the Google Play Store or the Apple App Store and install it on your smartphone.
- Page 11 Personalization (optional) Adjust the acoustic performance of the headset to suit your own personal hearing preferences. Put on the headset, inserting the ear buds. Choose Personal >> Assessment in the W&H BeHear app. Follow the prompts to perform the hearing assessment. Save and apply the results to the headset.
- Page 12 Tinnitus Masking Tinnitus Masking Sound Therapy is designed to ease the discomfort of tinnitus sufferers. In live hearing mode, you can activate the masking noise file to distract yourself from your tinnitus. Toggle the tinnitus masking noise ON/OFF by pressing the bottom button on each headset control box simultaneously.
- Page 13 Using the Telecoil Receivers Activate T-coil mode where induction loops are present. Use the RIGHT-HAND controls as follows: Double press to toggle T-coil mode ON/OFF. Short press to toggle between Exclusive and Transparent T-coil profiles. Change the tonal balance to emphasize high frequencies.
-
Page 14: Led Indication
LED Indication The LED indicator shows power and operation states of the headset. LED indicator State Indication Light blue (1s flash) Headset is powered ON/OFF (toggle) Purple, blinking Assistive function active Red/blue alternating Bluetooth pairing mode Red, blinking Disconnected from paired Bluetooth device, or battery low Red, steady Charging... -
Page 15: Troubleshooting
Troubleshooting Issue Suggestion Hearing Turn off phone tones (touch sounds, interruptions keyboard taps, notifications). Bluetooth When within range (30 ft/10 m) place disconnects often Bluetooth device on right side of body. Grayed-out Home Headset is not connected properly. menu in the BeHear Review section F “Connecting to a Bluetooth Device”. -
Page 16: Package Contents
Package Contents Headset Charging Micro-USB Travel cradle charging cable pouch Ear hook pairs Ear bud pairs Wind protection (3 sizes) (variety of types covers (2 pairs) and sizes) Support Video Tutorials: https://bit.ly/bhaccess-video U.S. & Canada: (888) 215 0620 (toll free) behearsupport@amplicomusa.com Elsewhere: support@alango-behear.com www.alango-behear.com...
