Summary of Contents for S4A GTP-6200 Series

Page 1: Table Of Contents
GTP-6200 series Manual Auto-induction Guard Tour System································ 2 Auto-induction LCD Display Guard Clocking System·········5 Strong Lighting Guard Tour System······························· 8 LCD & Lighting Guard Tour System···························· 11 Auto-induction Guard Tour System······························14 Touch Torch Guard Tour System··································18 Auto-induction Guard Tour System······························ 22 Wireless communication Guard Tour Reader··················...
Page 2 Software installation & set-up······································42 System composition Supplied Accessories ❶ Charger; Accessories included with the device ❷ Silicone case; ❸ User manual; ❹ Software disk; ❺ USB cable. ❻ Check point; Accessories recommended for the device ❼ Staff ID tag; ❽ PC/laptop; ❾...
Page 3: Auto-Induction Guard Tour System
1. Auto-induction Guard Tour System 1.1 General features  Read Method: Automatic sensors and Non-touch reading of RFID tag.  Structure: Metal structure, waterproof, durable, resistant to high and low temperatures.  Direction: LED flash and vibration.  Card-reading Technology: Switzerland EM induction card-reading technology.
Page 4 ❶ ❷ ❸ ❹ ❺ ❶ Sensor area; ❷ LED indicator; ❸ Anti-slide area; ❹ Label Area; ❺ USB port. 1.3 How to use How to turn on the device: This reader work with built-in battery , so the factory mode is standby. How to scan tags: Closing to the check point with the black head of reader, there...
Page 5 Impact records: While the reader is subjected to an external force or dropped, the red and blue light will flash 3 times alternately, and reader will record the impact time . Impact record can be queried at software. Which is very helpful to query the impact history of reader.
Page 6: Auto-Induction Lcd Display Guard Clocking System
Vibrate 6 times, and red Connect patrol reader with Time error light flickers 6 times computer , click “Update time” Connect patrol reader with Vibrate 3 times, and red Memory is full computer, save data to software first light flickers 3 times and click “...
Page 7 battery prompt and so on. Meanwhile , it work with USB cable to download data , no need to purchase download station additionally , low purchase cost . Besides ,this model is with impact recording function, while the device is been dropped or beat by force during usage, the device will record the impact time automatically, which is very helpful for supervisor to check the impact history of reader .
Page 8 screen will display tag ID, time and memory space ,which means scan tag successfully. There will be a vibration and 3 times blue light flicker ,LCD screen on Impact records: While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time .At the same time, LCD screen will show time and impact record count.
Page 9: Strong Lighting Guard Tour System
Problem Reason Handling method Vibrate 6 times, and red Connect patrol reader with Time error light flickers 6 times computer , click “Update time” Connect patrol reader with Vibrate 3 times, and red Memory computer, save data to software light flickers 3 times full first and click “...
Page 10 ❶ Sensor area; ❷ LED lamp; ❸ LED indicator; ❹ Lighting switch; ❺ Anti-slide area; ❻ Label Area; ❼ USB port. 3.3 How to use How to turn on the device : This reader work with built-in battery , so the factory mode is standby.
Page 11 While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time . Which is very helpful to query the impact history of reader . Delete data: If there are 3 times vibration and 3 times red light flicker while scan tags, which means the memory of reader is full.
Page 13: Lcd & Lighting Guard Tour System
4. LCD & Lighting Guard Tour System 4.1 General features  Read Method: Automatic sensors and Non-touch reading of RFID tag.  Physical: Metal structure, waterproof, durable, resistant to high and low temperatures  Direction: LED flash ,screen display and vibration. ...
Page 14 ❹ Label Area ❺ LED Lamp; ❻ Lighting Switch; 4.3 How to use How to turn on the device : This reader work with built-in battery , so the factory mode is standby. How to scan tags: Closing to the check point with the black head of reader , there will be a vibration with 3 times blue light flickers together with LCD display tags ID , which means scan tag successfully.
Page 15 Impact records: While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time . Which is very helpful to query the impact history of reader . Delete data: If there are 3 times vibration and 3 times red light flicker while scan tags, which means the memory of reader is full.
Page 16: Auto-Induction Guard Tour System
5. Auto-induction Guard Tour System System composition Supplied Accessories ❶ USB cable (A or B); Accessories included with the device ❷ User manual; ❸ Software disk; ❹ Charger plug; Accessories recommended for the device ❺ Check point; ❻ Staff ID tag; ❼...
Page 17 5.1 General features  Read Method: Automatic sensors and Non-touch reading of RFID tag.  Structure: flexible rubber shell.  Direction: LED flash and vibration.  Card-reading Technology: Switzerland EM induction card-reading technology.  Storage Capacity: 40,000pcs.  Impact record function : Record impact logs up to 8,000pcs. ...
Page 18 cable to download data , no need to purchase download station additionally , low purchase cost . Besides ,this model is with impact recording function, while the device is been dropped or beat by force during usage, the device will record the impact time automatically, which is very helpful for supervisor to check the impact history of reader ❸...
Page 19 Impact records: While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time . Impact record can be queried at software. Which is very helpful to query the impact history of reader .
Page 20: Touch Torch Guard Tour System
Vibrate 6 times, and red Connect patrol reader with Time error light flickers 6 times computer , click “Update time” Connect patrol reader with Vibrate 3 times, and red Memory is full computer, save data to software first light flickers 3 times and click “...
Page 21 ❻ PC/laptop; ❼ Printer. ❷ ❸ ❶ ❹ ❺   6.1 General features  Read Method: Automatic sensors and Non-touch reading of RFID tag.  Structure: Aluminum alloy.  Direction: LED flash and vibration.  Card-reading Technology: Switzerland EM induction card-reading technology.
Page 22 This guard tour reader work with rfid technology ,is drop resistant, waterproof, shockproof. No need wiring and very simple for operation . There is real time built-in clock inside of device , can generate time stamp automatically once the reader scan rfid tags . Meanwhile , it work with USB cable to download data , no need to purchase download station additionally , low purchase cost .
Page 23 There will be vibration and 3 times blue light flicker Impact records: While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time .
Page 24: Auto-Induction Guard Tour System
Problem Reason Handling method Vibrate 6 times, and red Connect patrol reader with Time error light flickers 6 times computer , click “Update time” Connect patrol reader with Vibrate 3 times, and red Memory is full computer, save data to software first light flickers 3 times and click “...
Page 25 Supplied Accessories ❶ Charger; Accessories included with the device ❷ Leather case; ❸ User manual; ❹ Software disk; ❺ USB cable (A or B). ❻ Check point; Accessories recommended for the device ❼ Staff ID tag; ❽ PC/laptop; ❾ Printer. 7.
Page 26  Direction: LED flash and vibration.  Card-reading Technology: Switzerland EM induction card-reading technology.  Storage Capacity: 80,000pcs.  Impact record function : Record impact logs up to 32,000pcs.  Date Safety: Data can be stored for 30 years without power. ...
Page 27 ❻ ❸ ❷ ❹ ❺ ❶ ❶ USB port; ❷ LED indicator; ❸ Anti-slide area; ❹ Label Area; ❺ Sensor area; ❻ Battery cover. 7.3 How to use How to scan tags: Closing to the check point with the black head of reader , there will be a vibration with 3 times blue light flickers ,which means scan tag successfully.
Page 28 Impact records: While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time . Impact record can be queried at software. Which is very helpful to query the impact history of reader .
Page 29 7.5 How to connect USB cable There are small arrows in patrol device and data cable,please make these 2 arrows corresponding and screw follow the direction “Lock” or “Open”. 7.6 Failure and Solutions Problem Reason Handling method Vibrate 6 times, and red Connect patrol reader...
Page 30: Wireless Communication Guard Tour Reader
8. Wireless communication Guard Tour Reader System composition Supplied Accessories ❶ Holder; Accessories included with the device ❷ CR123A battery (for Pattern A only); ❸ User manual; ❹ Software disk; ❺ USB cable (for Pattern B only) ❻ Check point; Accessories recommended for the device ❼...
Page 31 8.1 Device Introduction Pattern A ❶ ❷ ❸ ❹ ❶LED Indicator ❷ Label Area ❸ Sensor ❹Magnetic USB Port Pattern B...
Page 32 8.2 General features Read Method: Auto-induction technology, non-touch scanning. Read 125khz RFID tags  Super lower consumption: Standby power is 100UA, 3.0V camera battery can powered (for Pattern A). Built-in rechargeable lithium battery powered(for Pattern B).  Structure: Supper metal liner , flexible rubber shell, super impact resistant ,shake-proof, high/low temperature resistant .
Page 33 There will once beep sound (vibration) and 3 times blue led flicker while scanning tags successfully. Delete data: When the buzzer beeps (vibration) for three times and the red indicator light flashes for 3 times, it means the memory is full, please connect device with PC to check whether memory is up to 8000 logs, then click “...
Page 34 8.5 Failure and Solutions Problem Reason Handling method The buzzer beeps (vibration) 6 Synchronize the time and date of times, the red and green lights Time error the patrol device with the flash for six times computer. The buzzer beeps (vibration) 6 times, the red light flashes Low power Change the new battery...
Page 35 9. Wireless Date Transfer Communication Station 9.1 General features It like a bridge to connect patrol device with computer . Powered by USB cable directly . Communication: Wireless communication with patrol reader; USB connection with PC Size：118mm*82mm*36mm Weight: 220g Memory :No Operation prompt : LED flicker 9.2 How to use Connect Data downloader with PC, turn on power button (power light on), plug...
Page 36 Notice : If long time no connection or no any operation from software , data downloader will cut connection with patrol reader automatically ,and there will be 10 times beep sound as a reminding for user to take patrol reader away to save power .
Page 37 Communication: Wireless communication with patrol reader; USB connection with PC Size：118mm*82mm*36mm Weight: 220g Memory :600,000 logs. Operation prompt : LED flicker + LCD screen. Offline storage: Yes, work with 3pcs AA batter to store data temporarily. 10.2 How to use Method A : Connect Data downloader with PC, turn on power button (power light on), plug patrol reader to data downloader slot , there will be once beep sound means...
Page 38 Notice : If long time no connection or no any operation from software , data downloader will cut connection with patrol reader automatically ,and there will be 10 times beep sound as a reminding for user to take patrol reader away to save power .
Page 39: Led Lighting Guard Patrol Stick
11. LED lighting Guard Patrol Stick System composition Supplied Accessories ❶ Charger; Accessories included with the device ❷ Leather case; ❸ User manual; ❹ Software disk; ❺ USB cable (A or B). ❻ Check point; Accessories recommended for the device ❼...
Page 40 11. 1 General features  Read Method: Automatic sensors and Non-touch reading of RFID tag.  Structure: Aluminum alloy structure, waterproof, durable, resistant to high and low temperatures.  Direction: LED flash and vibration.  Card-reading Technology: Switzerland EM induction card-reading technology.
Page 41 ❺ ❹ ❸ ❷ ❼ ❻ ❶ ❶ Sensor area; ❷ LED indicator; ❸ Torch light switch; ❹ Anti-slide area; ❺ Battery cover; ❻ Lighting area; ❼ USB port. 11.3 How to use How to scan tags: Closing to the check point with the black head of reader , there will be a vibration with 3 times blue light flickers ,which means scan tag successfully.
Page 42 Impact records: While the reader is subjected to an external force or dropped , the red and blue light will flash 3 times alternately, and reader will record the impact time . Impact record can be queried at software. Which is very helpful to query the impact history of reader .
Page 43 must pay attention to the positive and negative electrode of battery . 11.5 How to connect USB cable There are 4 pogo pin dots and screw holes in patrol device and data cable, please make these pogo in and screws corresponding and screw with anticlockwise direction.
Page 44: Accessories Introduction
12. Accessories Introduction (1)Checkpoint (ask extra purchase) Check point is use for marking patrol site , which is with chip inside , every check point is with global unique ID number (can’t be modified) . Easy for installation, no need wiring , no need power supplied , can fixed with structural adhesive or screw.
Page 45 (2) Communication cable It is used for connecting guard tour reader and software to transfer data. Easy operation and no need extra data downloader , save much cost. Full plastic shell, reliability and good looks; Wire communication, do not use power; The transmission speed is 115200Bps.
Page 46 Guarantee card including guarantee items Product Maintenance Guarantee Card Customer shall please fill in below content and keep it carefully after purchasing the device, in order to gain perfect after-service. Please read carefully the items given: Customer name: Customer contact Tel: Product model: Device number: Purchase date:...
