US-8015
NET TONER & PROBE KIT
Instruction Manual
The Net Probe comes with adjustable volume
control and Ring/Tip polarity test indicators, an
earphone jack for noisy environments, low
battery indicator, easy tip replacement, and
lanyards attachment point for hand-free
operation. The Net Probe is also equipped with
a visual signal indicator and a flashlight help to
find the target in dark field (US-8015A only).
When used in conjunction with the toner, the
Net Probe allows you to trace and troubleshoot
Telecom/Datacom, Security/Alarm, CATV and
Audio cable systems. This Kit is a must-have
tool for installation, service and repair.
Features:
Net Toner
1. Provides 2 selectable tones for tracing
wires and cables.
2. Enhances talk battery power supply to allow
communication over inactive pairs.
3. Test cable/wire continuity, and determine
line 1 and line 2 polarity.
4. Built-in alligator clips and 4-conductor RJ12
cable for multiple connection options.
5. Durable nylon carrying case with belt loop
includes.
6. An audible sound will be heard when a
short circuit is detected (US-8015A only).
1
3
US-8015 NET TONER & PROBE KIT
Description
The Net Toner & Probe Kit is a practical
telecom and network installation, maintenance
and troubleshooting tool. The kit helps you
locate and identify wires, pairs and cables.
The Net Toner has the unique features of
enhancing talk battery power supply to allow
communication over inactive pairs, using
telephone test sets. It provides two selectable
tones which allow you to trace cable and locate
faults for troubleshooting both voice
and data circuits. It also tests cable continuity
and can determine line 1 and line 2 polarity
and voltage in data and voice lines. It features
a tone signal, two alligator clips, & 4-conductor
(RJ12) modular cable to test telecom, cats
cabling, coax cable and bare wires. In
continuity mode, when a short circuit is
detected an audible sound will be heard (US-
8015A only). The short circuit test function are
only applied to line 1 4/5 when using the RJ12
plug cable. The tone generated by the Net
Toner can be easily traced by the Net Probe or
any other commercial probe.
Net Probe
1. Comes with adjustable table volume
control.
2. Includes Ring/Tip polarity indicators and
RJ45 jack.
3. An earphone jack for noisy environments.
4. With low-battery indicator and easy tip
replacement.
5. Lanyards attachment point for hand-free
operation.
6. Includes visual signal indicator and
flashlight (PR-608A only).
US-8015
2
4
Advertisement
Summary of Contents for Link US-8015
- Page 1 US-8015 NET TONER & PROBE KIT Description The Net Toner & Probe Kit is a practical telecom and network installation, maintenance and troubleshooting tool. The kit helps you locate and identify wires, pairs and cables. The Net Toner has the unique features of...
- Page 2 When connecting the tester to a previously untested circuit, the tester should always be in Operating Instructions OFF mode. WARNING – ELECTRIC SHOCK RISKS (A) To Send Tone for Cable Tracing ★ Keep this unit away from water, moisture and rain to avoid electrical shock. Do not connect to circuit carrying AC voltage in “Tone”...
- Page 3 1) With the left slide switch in “Cont/Talk” position. 2) Connect the red and black alligator test leads to both ends of the 3) With the right slide switch in “Talk” cable/wire you want to test. position. 3) The “Cont” LED indicator will light This provides additional battery Green.
-
Page 4: Trace〞 ↓ Position
2) Set the switch to〝OFF〞↓position to turn off the light. NET PROBE (C) Ear Jack: In noisy environments, 2.5 mm (A) Tone tracing headphone may be plugged into the ear 1) Set the〝Tel/Trace〞 selector to jack on the 〝Trace〞 ↓ position. right side of the Net Probe, be sure to fully seat the plug into the jack, and set 2) Push〝Trace〞... -
Page 5: Specifications
3) Carrying Pouch 4) User Manual Battery One 9V DC Standard or Alkaline Battery Order Information US-8015 Net Toner & Probe kit. US-8015A Net Toner & Probe kit, Flash light Trace Button, LEDs, Volume Control Interface Replaceable Tip, 2.5mm Earphone Jack...
