Kali-Ko Kathouses 20 Kiji Dava Circle
Prescott, Arizona 86301
1-800-658-5925
rover@roverpet.com
Assembly Instructions for Kali-Ko Kastle #K646
72" high panels
Inventory: The Kali-Ko Kastle #K646 consists of (9) #C72
(with FDC fold down clips attached) (1) #CD72 72" high single door panel (2)
#F24 shelves (1) #F26 shelf (4) #S31 shelf support braces, (2) #C72C lids (top)
(with (66) #200 panel clips (13) #250 floor divider clips (3) #175 door clips. The
panels will already have been snapped together. (Optional purchase: floors)
*NOTE: Please make sure your inventory is complete!
Step 1: Unwrap the sections, placing them where described, and stretch out the
panels in the shape of a 4' x 6' enclosure, making sure the #CD72 door is in the
middle of one #C72 side of the enclosure. Connect the sections together by
snapping the #200 panel clips to the adjoining sections. DO NOT connect the
door panel with the panel to its right yet.
Step 2: With the #CD72 door panel open step inside the enclosure and 'fold
down' all the FDC fold down clips around the perimeter of the enclosure. Next,
take a #F24 shelf and place it to the left on the fold down clips which are 2/3 of
the way up the enclosure. Place the shelf with the flat side up, and let the pipe
rest on the #FDC fold down clips. Secure in place by snapping on (8) #250 floor
divider clips (2 per 2 ft. section); snapping them to the shelf's pipe and the
panel's center bar. Place the #250 floor divider clips underneath and inside of
the #FDC clips. (See figure 1 below of the underside of the shelf.) Place the next
#F24 shelf on the #FDC fold down clips to the right and secure in the same
manner. The last #F26 shelf will go 1/3 of the way up on the back panels of the
enclosure
Advertisement
Summary of Contents for Roverpet Kali-Ko Kastle
- Page 1 Assembly Instructions for Kali-Ko Kastle #K646 72” high panels Inventory: The Kali-Ko Kastle #K646 consists of (9) #C72 (with FDC fold down clips attached) (1) #CD72 72” high single door panel (2) #F24 shelves (1) #F26 shelf (4) #S31 shelf support braces, (2) #C72C lids (top) (with (66) #200 panel clips (13) #250 floor divider clips (3) #175 door clips.
- Page 2 Kali-Ko Kathouses 20 Kiji Dava Circle Prescott, Arizona 86301 1-800-658-5925 rover@roverpet.com Step 3: Secure the shelves in place with the #S31shelf support braces. The #F24 shelves will have (1) #S31 support brace attached, and the #F26 shelf will have (2) #S31. The single braces for the #F24 shelves will go approximately in the center of the shelf, and the (2) #S31 braces for, fig.
