Summary of Contents for MyCableMart ZT-T-505A
- Page 1 3D Full HD 1080P HDMI Extender Over Single CAT5e/6 With IR（ （ （ （ 60M） ） ） ） HDMI EXTENDER User Manual HDMI Extender Over Single CAT5e/6 With IR（60M） (3D Full HD 1080P) Model ZT-T-505A Bring High-Definition to your life!
- Page 2 3D Full HD 1080P HDMI Extender Over Single CAT5e/6 With IR（ （ （ （ 60M） ） ） ） Thank you for purchasing our product. To ensure safety and many years of trouble-free operation of this product, please read the manual carefully before using this product.
- Page 3 3D Full HD 1080P HDMI Extender Over Single CAT5e/6 With IR（ （ （ （ 60M） ） ） ） Input Video signal -------------------------------------------------------------------------------------------0.5~1.5Volts p-p Output DDC signal-----------------------------------------------------------------------------------------5Volts p-p (TT1L) Input/Output HDMI cable distance-------------------------------------------≤20m AWG26 HDMI standard cable Max working current----------------------------------------------------------------------------------------------------800mA Power adapter format -----------------------------------Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A Operating Temperature range------------------------------------------------------------------------------ (-15 to +55℃) Operating Humidity range------------------------------------------------------------5 to 90%RH (No Condensation) 5.0 PANEL DESCRIPTIONS...
- Page 4 3D Full HD 1080P HDMI Extender Over Single CAT5e/6 With IR（ （ （ （ 60M） ） ） ） 6.01.Connect HDMI signal source to the transmitter of HDMI extender. 6.02.Use LAN cable (Recommend:CAT 6) to connect transmitter and receiver of HDMI Extender. 6.03.Connect the display equipment with HDMI connector to the receiver of HDMI extender.
