INSTRUCTION MANUAL
WI-FI SECURITY CAMERA
NIGHTOWL
COMPONENTS
• IP Camera
• Power adapter
• Wi-Fi antenna 5 dBi
• Set of mounting screws
• Screwdriver
• Foam base
• User manual
TECHNICAL SPECIFICATIONS
• Image sensor: 2.0M HD CMOS
• Lens: 3.6mm
• Min. illumination: 0.5 Lux (colour mode), 0.1 Lux
(black & white mode)
• Resolution: 1920 x 1080P
• Video compression: H.264/ MJPEG
• Frame rate: 25-30fps
• Audio compression: G.711a
• Audio input: built-in-48dB microphone
• Audio output: built-in 8Ω 1W speaker
• Alarm trigger: motion detect
• Wireless Lan: IEEE802.11b/g/n
• Wireless security: WEP/WPA-PSK/WPA2-PSK
data encryption
• Protocols: ONVIF, TCP, UDP, DHCP, DNS, RTSP,
P2P
• Memory: micro SD card slot
• Power supply: DC12V±10%
• Waterproof standard: IP66
• Operation condition: temperature-25°C -+65°C
• Humidity: 10%-90%
• Number of online users: max 5 users
• Rotation angle: 320°horizontally/110°vertically
• Night vision: automatic switching of double
filters, 4 dot-infrared lamps, irradiation distance
10-30 m
FEATURES
(1) Wi-Fi antenna
(2) Micro SD card slot
(3) Power port
(4) Reset button
(5) 1080p HD lens
(6) Speaker
(7) PIR sensor
(8) Microphone
(9) White LED
(10) Infrared LED
MOUNTING THE SECURITY CAMERA
ON A WALL
1. Drill three holes on the wall by using the base
of the security camera as a template. Make
sure to position the base unit so the camera is
in the upright direction. It is recommended
that you mark the locations of the holes with a
pencil before drilling. The diameter of each
hole is approximately 6mm, and the depth is
approximately 25mm.
2. Insert the three plastic anchors into the holes
on the wall.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NIGHTOWL and is the answer not in the manual?

Questions and answers

Summary of Contents for Mania NIGHTOWL

  • Page 1 (3) Power port • Operation condition: temperature-25°C -+65°C (4) Reset button WI-FI SECURITY CAMERA (5) 1080p HD lens • Humidity: 10%-90% NIGHTOWL (6) Speaker • Number of online users: max 5 users (7) PIR sensor • Rotation angle: 320°horizontally/110°vertically (8) Microphone •...

  • Page 2: Add Camera

    O HOW TO OPERATE THE MOBILE APP CONNECTING CAMERA WITH REGISTER AN ACCOUNT APPLICATION When you use this app for the first time, you need to O MAIN FUNCTION DESCRIPTION use your email to register an account, click “Sign Up” and set a password according to this procedure.
  • Page 3 • Please make your phone connect to the Wi-Fi, • Click “Next” and Select your own Wi-Fi and login Addition by connecting to network cable (Only and then click “Device adding by scanning the with your password. supports Lan Port Device) •...

  • Page 4: Function Introduction

    • hotspot" (if you don't hear the voice, reset the FUNCTION INTRODUCTION Preset camera) 1. Click the preset icon to enter the preset Real-time preview interface • Open the YCC365 plus app to enter the login management interface. interface, click “Local login”. 2.
  • Page 5 Delete the preset O DOWNLOAD CLOUD VIDEO / SHARE O VIDEO CLIP O VIDEO PLAYBACK CLOUD VIDEO Note: Only the cameras with cloud service package Video is by default recording to cloud. If you want Click the cloud album icon and click the video clip, have this feature.
  • Page 6 O CLOUD VIDEO PLAYBACK O CLOUD STORAGE SERVICE Click “Device storage” to check the memory. Click “Memory card recording mode” to select the Click “Message” to view the alarm video. We offer a 30-day-long cloud service, which video mode of TF card. everyone can enjoy for free.

  • Page 7: Frequently Asked Questions

    O OTHER FUNCTIONS SETTINGS Device Details: Check the ID and the number of the FREQUENTLY ASKED QUESTIONS software\hardware of the device. 1. Can’t add the device? Remove Device: Please remove the camera in your A. Please make sure the camera has been account if you need to use another account to add reset.
  • Page 8 doesn’t work, please scan the QR code 5. Why I can’t get the notifications on my Two ways: to add the camera. phone? A: When you need to change to another Wi-Fi B. If you can’t go to the third step, please Make sure the App gets the message pushing rights without moving the place.

  • Page 9: Warranty

    • To avoid heat accumulation, ensure there is good ventilation to the device. • Do not immerse camera in water or other liquids. • While shipping, pack the camera in its original, or equivalent, packing materials. WEEE disposal and recycling symbol. The WEEE symbol is attached to the Notes: product in compliance with the EU...
