Mania ELORIAN Instruction Manual

INSTRUCTION MANUAL
MEN'S WATCH ELORIAN
TECHNICAL SPECIFICATION
•
Weight: 135g
•
Mechanism: quartz
•
Front: hardlex glass
•
Material: stainless steel
•
Waterproof: 3ATM/30m
•
Function: time, date, stopwatch
•
Battery: 1x LR44 (included)
•
Dial diameter: 42mm
•
Dial thickness: 12mm
•
Strap width: 21mm
•
Strap length: 21cm
WATER RESISTANCE
The watch is waterproof according to the 3 ATM
standard, which provides:
•
Resistance to splashing and rain
•
Resistance to everyday use (hand washing)
•
The watch is not suitable for showering,
swimming or diving.
FUNCTIONS
A –> Button A
B –> Button B
1 –> Crown
2 –> Middle position
3 –> Outer position
4 –> Calendar
5 –> Stopwatch seconds
6 –> Stopwatch minutes
7 –> 24 hours
In addition to time, the watch also has a stopwatch
and displays the date.
All time chronometers are functional and
automatic, which means that they are set once and
then move forward accordingly.
BATTERY POWER
The watch runs manually, onan LR44 battery that
lasts approximately 1–1 ½ year. When the watch
stops running, it's time to replace it. This is best
done by the local watchmaker. If you open the
watch yourself with inadequate equipment there is
a chance it will lose waterproofing.
SET TIME AND DATE
Time setting:
To set the analog time, use the crown on the right
side:
•
Pull the crown out (to the right)
•
Rotate it clockwise
•
When the clock is set, push it in (to the left)
Date setting:
Use the crown to set the chronometer date:
•
Pull it into the middle position (not completely
out but only to the middle)
•
Turn the crown up
•
When the date is set, push it back (to the left)
STOPWATCH
Press button A to start the stopwatch. The
stopwatch seconds dial will start moving (60
