Summary of Contents for Foxtech SL300
- Page 1 SL300 Searchlight User Manual V1.0...
-
Page 2: Table Of Contents
SL300 Searchlight User Manual Content Product Overview................. 1 The Service Statement..............1 Brief Introduction................ 1 Technical Parameters............... 1 Interface Definition..............2 Packing List................. 3 Installation and Usage..............3 How to mount to multi-rotors............3 Power Supply and Signal Cable Connection......4 Remote Controller Settings and Operation......5... -
Page 3: Product Overview
The searchlight weighs only 840g and has the power of 45W. 10° two-lens is built-in that emits a sharp beam, and the effective illumination distance is as far as 400 meters. SL300 has a spot diameter up to 15 meters at 100m height and the illuminated area is about 177 square meters. -
Page 4: Interface Definition
SL300 Searchlight User Manual Voltage DC 12-26V Battery type 3S-6S Li-ion battery Power interface XT30 Operating current 2.3A@18V Total power consumption ﹥20000 lumens Brightness ﹥300 meters Effective illumination distance Spot diameter 15m@100m flight altitude Beam angle 10° super-concentrating illumination Lighting mode... -
Page 5: Packing List
SL300 Searchlight User Manual The main body of the searchlight is made of aluminum alloy and the lens is made of glass. If the surface is dirty, you can wipe it with clean water or alcohol. Do not use organic solvents such as circuit board cleaner or turpentine to avoid damage to the body or lens. -
Page 6: Power Supply And Signal Cable Connection
SL300 Searchlight User Manual Power Supply and Signal Cable Connection The searchlight supports wide voltage input. To ensure stable long-term operation, it is recommended to use a 12V~26V DC power supply with an output current greater than 2.5A@18V (power output greater than 45W). For the M600 series drones, there is a 18V DC power output (3.0A current) at the bottom to power the searchlight. -
Page 7: Remote Controller Settings And Operation
FLYSKY i6 remote controller(10 channels) as an example to introduce the setting of the SL300 searchlight controlled by an external PWM signal , The setting method of other drone remote controller is similar to this. - Page 8 SL300 Searchlight User Manual The functions of the searchlight require three channels to achieve. After the searchlight is installed on the drone, use a 3 pin DuPont cable to connect the drone's remote controller receiver channel and the searchlight control signal interface. The pitch control adopts a channel that can be continuously adjusted...
- Page 9 SL300 Searchlight User Manual The PWM value range of different brands of remote controllers is slightly different. The two-stage or three-stage switch setting method is the same as the above-mentioned FLYSKY remote controller. Please fine-tune the pitch angle control as needed to meet the duty ratio. If the UAV has few remote control channels, and light color and brightness do not need to be adjusted at any time.
