E-Guardian S409

Mask & Fever Screening Solution

Quick Start Guide

Table of Contents

Need help?

Do you have a question about the E-Guardian S409 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMobile E-Guardian S409

Page 1 E-Guardian S409 Mask & Fever Screening Solution Quick Start Guide...
Page 2 Copyright Notice ©2020 All Rights Reserved. This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
Page 3 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
Page 4: System Overview
System Overview The S409 mask and fever screening solution is designed for fast preliminary detection of potential fever symptoms. The S409 comprises of the following main components: Thermal camera: An infrared thermography camera to detect • potential fever. A temperature of >37.5°C is defined as potential fever with S409.
Page 5 How the S409 Works AI-Powered Human Recognition S409 an AI-powered 36.4°C solution so it is able to recognize a human from the thermal image and thus measuring the forehead temperature mask. individual wearing a mask can still be detected. Real-time On-Screen Display The S409 continuously measures the temperature and mask of people passing through the S409.
Page 6: Installation Options
Installation Options Designed for flexible installation, the S409 comes with an all-in-one installation kit to support various installations. A. VESA Mount S409 can be installed on the VESA kit for the vehicle application. Optional VESA mount kit B. Tripod Mount S409 can be installed on the tripod with an universal 1/4"...
Page 7: Package Contents
Package Contents Package Contents S409 (including power cord and S409.) • Type-U power cord for vehicle • (Please note that this is for vehicle version) M8 to DC power cord for indoor • (Please note that this is for indoor version)
Page 8: Getting Started
Getting Started Before installation, please get yourself familiar with the components of the S409. Front View 1/4" Thread and VESA mount Blackbody Calibrator Thermal camera...
Page 9 Getting Started Rear View LED Indicator Status Power LED Network LED Thermal Detection LED...
Page 10 Getting Started Bottom View 1/4" Thread and VESA mount Power connector LAN port USB port Side View SIM Card and Memory Card slots...
Page 11 Dimension 196.5 177.2...
Page 12: Installation Advice
Installation Advice Before proceeding to install the S409, please follow the guidelines below to get the optimal performance of the system: Install the S409 indoor with ambient temperature of 15~30°C. • For the person to be detected, it’s suggested to stand at a distance •...
Page 13 Installation Advice The S409 is capable of detecting multiple human temperatures. • However, avoid overlaps between people to ensure the measurement. For optimal performance, it's suggested that you allow only one person appear in the field of view at a time. Optional tripod...
Page 14: Installations
Installations Installing the S409 – Vehicle Please follow the steps as below to install the S409 in vehicle: 1. Locate the VESA hole in the bottom of the S409 mounting plate, and install 4 M3*L9 screws on the S409. 2. Tighten 4 M6*30 screws for two pairs of pipe clamps.
Page 15 Installations 3. Tighten 2 M6*10 screws for racket/device on the pipe to secure the position. 4. Adjust the angle of S409 to 15 degrees to screen passengers in the vehicle. Then tighten the screws in the picture as left. Cautions: DO NOT expose the S409 to direct sunshine, water, oil, dust or •...
Page 16 Installations Mounting the S409 – Tripod Mount 1. Locate the threaded hole in the bottom of the S409 mounting plate. 2. Mount your tripod head to S409 plate. Tighten the screw-head from the bottom of the tripod head to secure the assembly. Then mount it to your tripod.
Page 17 Installations 4. Connect the power cord of the provided power adapter to the power connector on S409. Then plug the power adapter into a power outlet. (use a coordinate plug adapter for your territory) The power of S409 will startup automatically. (Please note that S409 will cause auto shut down after 10 seconds by itself if the power is unplugged.)
Page 18 Installations Power Connection 1. The S409 come with a Type-U (or M8 to DC) power cord for power source. 2. Attach the correct plug according to your location to the power adapter. Then plug the power adapter into a standard AC power outlet.
Page 19 Using S409 When a person's temperature is detected under 37.5°C, "PASS" will be displayed; otherwise, "OUT OF TEMP" will be displayed and a sound alert will be sent. If the person did not wear the mask, the screen would show "NO MASK" and a sound alert will be sent. When S409 detects the mask and the temperature is under 37.5, the monitor will...
Page 20: Adjust The Volume
Adjust the Volume If usrs need to adjust the volume of the audio, follow the insutreuction as below: Slide down the menu •...
Page 21 Adjust the Volume...
Page 22 Adjust the Volume •...
Page 23: Screen Mirroring
Screen Mirroring Wireless screen Mirroring is available for the S409. It's a suitable in- vehicle environment. Please follow the instruction for the screen mirroring.
Page 24 Screen Mirroring...
Page 25 Screen Mirroring Then choose your devices. The screen on the S409 can be mirrored on your display device. (Please note that screen mirroring may not be supported depending on your model or brand of display devices.)
Page 26: Specifications
Specifications Specifications Highlight Measuring Distance 1M ~1.5M Accuracy ±0.5ºC System Power 5V/2A Touch Screen 5" Capacitive touch screen Control Power button Android 11.0 Thermal Imaging Lepton 2.5 Array Format 80 x 60 Calibration Blackbody, ±0.3ºC Dimension 196.36 x 132.86 x 157.61 mm (W x H x D) Weight 920g Working Temp.
Page 27 Q & A 1. Q: What will the device do A: When users are not in mask when subjects not in masks and have fever simultaneously, the device will say "Abnormal temperature". 2. Q: Can the device scan a real- A: S409 needs to connect the name system QR code?.
