- Page 1 9/17/2017 HS-RX500 YH,AH SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM: 7ZM-1 P4NF CASSETTE PLAYER • Replace this Service manual with “Revision Publishing” when it is issued. S/M Code No. 09-004-432-3T1 Digitized in Heiloo Netherland...
-
Page 2: Electrical Main Parts List
www.freeservicemanuals.info 9/17/2017 ELECTRICAL MAIN PARTS LIST - 1/3 NOTE: The characters in the suffix column indicate the part usage. YH .....XX........A....AH .....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-828-080 CHIP CAPACITOR,U 0.033-25F AB....87-012-273-080 C-CAP,U 820P-50 B AB....87-012-273-080 C-CAP,U 820P-50 B AB.... - Page 3 www.freeservicemanuals.info 9/17/2017 ELECTRICAL MAIN PARTS LIST - 2/3 87-012-196-080 C-CAP,U 120P-50 CH AB....87-012-274-080 CHIP CAP,U 1000P-50B AB....87-012-286-080 CAP, U 0.01-25 AB....87-012-286-080 CAP, U 0.01-25 AB....87-012-286-080 CAP, U 0.01-25 AB....87-012-286-080 CAP, U 0.01-25 AB....87-A10-039-080 C-CAP,U 470P-50 J CH AB....
- Page 4 www.freeservicemanuals.info 9/17/2017 ELECTRICAL MAIN PARTS LIST - 3/3 87-010-196-080 CHIP CAPACITOR,0.1-25 AB....87-001-166-080 DIODE,1SS301 AB....87-001-166-080 DIODE,1SS301 AB....87-A40-883-040 C-ZENER,02DZ13-Y AB....87-A50-367-080 C-COIL, 10UH LQG21F AB....87-A50-631-080 C-COIL, DD-CONV AB....87-A30-085-040 C-TR,CSA1362GR AB....89-413-284-080 TR,2SD1328T AB....89-413-284-080 TR,2SD1328T AB....87-010-805-080 CAP, S 1-16 AB....
-
Page 5: Mechanical Parts List
www.freeservicemanuals.info 9/17/2017 MECHANICAL PARTS LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. YH .....XX........A....AH .....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-HK5-003-010 WINDOW,CASS AB....8A-HR5-001-010 LID,CASS ASSY AB....87-HK5-237-010 S-SCREW,1.4-2 CR NL AB....8Z-HK4-206-110 HLDR,ARM ASSY AB.... -
Page 6: Accessories / Package List
www.freeservicemanuals.info 9/17/2017 ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. YH .....XX........A....AH .....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-HR5-902-010 IB,H(ECC)S .B....8A-HR5-903-010 IB,YHS(EC)S A....87-B30-298-010 BAT,NB-5G(S) AB....87-B30-341-010 CHARGER,RB-107 H (L) .B.... - Page 7 www.freeservicemanuals.info 9/17/2017 SCHEMATIC DIAGRAM Digitized in Heiloo Netherland...
- Page 8 www.freeservicemanuals.info 9/17/2017 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630469 Printed in Singapore Digitized in Heiloo Netherland...
