Open Text Tableau Forensic T8u Quick Reference Manual

QUICK
REFERENCE GUIDE
Tableau Forensic T8u USB Bridge

GETTING STARTED

TABLEAU FORENSIC USB 3.0 BRIDGE
Menu
Enter
Confirm that the bridge is off before beginning.
1. Connect one USB source device* to the right side of T8u
* T8u supports USB devices that conform to the USB Mass Storage
Bulk-Only specification.
2. Connect the bridge to the host computer using the host USB port
3. Connect the power supply to the bridge's DC In
4. Press the power button
Before you remove the connected USB device or power down the T8u, safely eject
or unmount the device on your host computer.

LCD MENU OPTIONS

Device Info Displays the connected USB device mfg, model, serial number
and firmware version
Select LUN If the drive has multiple LUNs, select a LUN to mount
Bridge Info Displays T8u firmware version, serial number and DIP switch
configuration
Show Status Displays information related to current status
Use the Menu and Enter buttons to navigate through these LCD menus:
Menu Advance to next main menu screen
Enter
Advance to the first/next informational screen
DC IN
Power
Host
Device
Wrt. Block
Activity
and begin operation
