- Page 1 LS-BHA Baby Ballhead Adapter INSTRUCTIONS...
- Page 2 Add functionality to a light stand or combo stand by using the LS-BHA to attach a standard photo or video head with a 3/8-16 mounting thread. By removing the locking knob, the adapter’s receiver quickly converts into a 1 ⁄...
- Page 3 Overview 1. 3/8-16 mounting thread 2. Setscrews (×3) 3. Locking knob 4. 1 ⁄ in. junior pin 5. Alternate locking knob position 6. 5/8 in. baby receiver...
- Page 4 Setup Baby Pin Installation Loosen the locking knob, and slide the adapter onto a 5/8-inch baby pin. Tighten the knob until secure. Junior Receiver Installation Remove the locking knob, and insert the adapter into a ⁄ -inch junior receiver.
-
Page 5: Specifications
Attaching a Ballhead 1. Screw a head onto the 3/8-16 mounting thread. Make sure the head is tight and flush with the baseplate. 2. Use a slotted screwdriver to tighten the three set screws and secure the head to the baseplate. Specifications Top Mount 3/8-16 male... -
Page 6: One-Year Limited Warranty
One-Year Limited Warranty This Impact product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely to repair...
