- Page 1 Integrator Series MULTI-CHANNEL POWER AMPLIFIERS IS-AMP8100 OPERATING INSTRUCTIONS IS-AMP1275 IS-AMP1650...
-
Page 2: Important Safety Instructions
17. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 2... -
Page 3: Table Of Contents
Important Safety Instructions ..........................2 Table of Contents..............................3 Introduction ................................4 Front Panel Features ...............................5 Rear Panel Features ...............................5 Speaker Connections ............................7 12 Volt Trigger .................................8 Ventilation ................................8 Specifications .................................9 Amplifier GUI Control Panel ..........................10 Warranty ................................14 MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 3... -
Page 4: Introduction
Congratulations and thank you for purchasing the Integrator Series multi-channel power amplifier! Since the time we started in 1926, ELAC has always striven to achieve the very best! The Integrator Series multi-channel power amplifier feature a combination of performance, flexibility and control to provide high value and great sound in different amplification arrangement. -
Page 5: Front Panel Features
12V TRIGGER - Use this connection to ON/OFF control the amplifier unit (5 ... 24V DC). AC MAINS - After all other connections have been made and confirmed, using the included power cord, connect the AC Mains on the amplifier to an AC outlet. MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 5... - Page 6 Before connecting the speaker wires, twist the ends of the speaker wire so there are no strays that can cause shorts. See section: Speaker Connections for additional information. MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 6...
-
Page 7: Speaker Connections
To reset the amp, power cycle the amplifier: unplug the amplifier from the wall jack for minimum 30 seconds and then plug it back in. If the amp does not return to normal operation, please contact ELAC at 714.252.8843 or at service@elac.us. MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 7... -
Page 8: Volt Trigger
The output trigger has a 12V voltage and 10 mA current. Ventilation The multi-channel power amplifier series IS-AMP8100, IS-AMP1275 and IS-AMP1650 require plenty of good ventilation to properly cool and work within the design parameters. There are thermal sensors to protest the amplifier from overheating. If overheat occurs, the amplifier is entering in compression mode which means, less output power. -
Page 9: Specifications
Via Web Interface (Mono/Stereo) Power Mode Switch Via Web Interface Via Web Interface Via Web Interface Amplifier Dimensions 17.0x3.9x14.9/ 17.0x3.9x14.9/ 17.0x3.9x14.9/ (WxHxD) [inch/cm] 43.18x9.84x37.8 43.18x9.84x37.8 43.18x9.84x37.8 Amplifier Weight [lb/kg] 16.32/7.4 18.96/8.6 20.4/9.25 MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 9... -
Page 10: Amplifier Gui Control Panel
Firmware Update - Allows you to update the amplifier firmware. Firmware update will also restart the amplifier. Password - Use these fields to enter the amplifier password. Ethernet - These fields are used to set up the IP settings for the amplifier. MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 10... - Page 11 Amplifier GUI Control Panel (cont.) Figure 6 Amplifier GUI Control Panel - Home Page Figure 7 Amplifier GUI Control Panel - Inputs and Outputs Page MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 11...
- Page 12 Output name - In these fields you can see the output name for each output. Volume - Use these controls to set the volume of each output individualy. Elac Speaker - Used this control to select the Elac Speaker model or custom speaker which is connected to the amplifier.
- Page 13 Amplifier GUI Control Panel (cont.) Figure 8 Amplifier GUI Control Panel - Names and Audio Routing Page Figure 9 Amplifier GUI Control Panel - Outputs EQ Page MULTI-CHANNEL POWER AMPLIFIER | www.elac.com | Page 13...
-
Page 14: Warranty
North America Limited Liability Warranty Amplifiers ELAC Americas Inc. warrants to the original purchaser that this product be free from defects and or workmanship for a period of 1 (One) year from the original date of purchase. During this time period, repair or replacement of parts will be free of charge to the original owner (see limitations below).
