TAT-SRV
TURN AROUND TESTER FOR
SAFETY RELIEF VALVES
WITH OPTIONAL HYDROSTATIC CIRCUIT
OPERATING MANUAL
ORIGINAL INSTRUCTIONS
P/N 98061
February 2021
Revision 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALDER TAT-SRV and is the answer not in the manual?

Questions and answers

Summary of Contents for Climax ALDER TAT-SRV

  • Page 1 TAT-SRV TURN AROUND TESTER FOR SAFETY RELIEF VALVES WITH OPTIONAL HYDROSTATIC CIRCUIT OPERATING MANUAL ORIGINAL INSTRUCTIONS P/N 98061 February 2021 Revision 2...
  • Page 3 CLIMAX. CLIMAX hereby grants permission to download a single copy of this manual and of any revision hereto onto an electronic storage medium to be viewed and to print one copy of this manual or any revision hereto, pro-...
  • Page 4 CLIMAX GLOBAL LOCATIONS Page B 7912-A1 Operating Manual...
  • Page 5 CE DOCUMENTATION P/N 98061, Rev. 2 Page C...
  • Page 6 CE DOCUMENTATION Page D 7912-A1 Operating Manual...
  • Page 7 CLIMAX will, at its option, either repair or replace the defective part and/ or correct any defect in the labor performed, both at no charge, and return the part or repaired machine shipping prepaid.
  • Page 8 This page intentionally left blank Page F 7912-A1 Operating Manual...

  • Page 9: Table Of Contents

    TABLE OF CONTENTS HAPTER ECTION 1 INTRODUCTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1 .
  • Page 10 TABLE OF CONTENTS (CONTINUED) HAPTER ECTION 5 MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 27 .
  • Page 11 LIST OF FIGURES IGURE 2-1 Upper console controls ............. 10 2-2 Lower front console controls .
  • Page 12 This page intentionally left blank Page iv 7912-A1 Operating Manual...
  • Page 13 LIST OF TABLES ABLE 1-1 Risk assessment checklist before set-up ..........5 1-2 Risk assessment checklist after set-up .
  • Page 14 This page intentionally left blank Page vi 7912-A1 Operating Manual...

  • Page 15: Introduction

    INTRODUCTION IN THIS CHAPTER: 1.1 H - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 OW TO USE THIS MANUAL 1.2 S - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1...

  • Page 16: General Safety Precautions

    ENERAL SAFETY PRECAUTIONS CLIMAX leads the way in promoting the safe use of portable machine tools and valve testers. Safety is a joint effort. You, the end user, must do your part by being aware of your work environment and closely following the operating procedures and safety precautions contained in this manual, as well as your employer’s safety...

  • Page 17: Machine - Specific Safety Precautions

    secure hair, clothing, jewelry, and pocket items to prevent them from becoming entangled in moving parts. ACHINE SPECIFIC SAFETY PRECAUTIONS Eye hazard – Always wear eye protection when operating the machine. Sound level – This machine produces potentially harmful sound levels. Hearing protection is required when operating this machine or working around it.

  • Page 18: Risk Assessment And Hazard Mitigation

    ISK ASSESSMENT AND HAZARD MITIGATION To achieve the intended results and to promote safety, the operator must under- stand and follow the design intent, set-up, and operation practices that are unique to valve testers. The operator must perform an overall review and on-site risk assessment of the intended application.

  • Page 19: Risk Assessment Checklist

    ISK ASSESSMENT CHECKLIST The following checklist is not intended to be an all inclusive list of things to watch out for when setting up and operating this valve testing machine. However, these checklists are typical of the types of risks the assembler and operator should con- sider.

  • Page 20: Labels

    ABELS The following warning and identification labels should be on your machine. If any are defaced or missing, contact CLIMAX immediately for replacements. 1-3. TAT-SRV ABLE LABELS P/N 59033 P/N 29154 Label: center of ID plate balance P/N 79328 P/N 80905...
  • Page 21 1-3. TAT-SRV ABLE LABELS P/N 89498 P/N 89499 Warning label: Warning label: do do not release not lift with valve the clamp the clamped valve is pres- surized P/N 89500 P/N 89548 Warning label: Warning label: do tip-over hazard not plug P/N 90533 P/N 90585 Label: clamp...
  • Page 22 This page intentionally left blank Page 8 7912-A1 Operating Manual...

  • Page 23: Overview

    OVERVIEW IN THIS CHAPTER: 2.1 F - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 EATURES AND COMPONENTS 2.2 C - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -10...

  • Page 24: Controls

    ONTROLS The controls are all located on the control console and the clamp fixture console. PCV-02 PI-03 PI-02 PI-01 WATER PCV-04 SUPPLY CLAMP TEST VESSEL CLAMP PRESSURE PRESSURE PRESSURE PRESSURE PRESSURE GAUGE GAUGE GAUGE CONTROL CONTROL V-03 VESSEL V-02 DIVERTER CLAMP VALVE RELEASE...

  • Page 25: Dimensions

    SUPPLY VALVE AIR LUBRICANT AIR INLET FILL 100-150 PSI (7-10 BAR) AIR INLET WATER 6,000 PSI SUPPLY (413 BAR) VALVE MAXIMUM WATER INLET 70 PSI (5 BAR) MAX 2-2. L IGURE OWER FRONT CONSOLE CONTROLS 2-2. L ABLE OWER CONSOLE CONTROLS IDENTIFICATION Console Number Component...
  • Page 26 2-3. TAT-SRV IGURE DIMENSIONS Page 12 7912-A1 Operating Manual...

  • Page 27: Specifications

    This machine should only be used with ambient gas or liquid. No corrosive liquids or gas should be used in the system. TEMS REQUIRED BUT NOT SUPPLIED The following items are required but not supplied in your CLIMAX product kit: • Shop air (100–150 psi [6.9–10.3 bar]) •...
  • Page 28 This page intentionally left blank Page 14 7912-A1 Operating Manual...

  • Page 29: Setup

    This section describes the setup and assembly procedures for the TAT-SRV. ECEIPT AND INSPECTION Your CLIMAX product was inspected and tested prior to shipment, and packaged for normal shipment conditions. CLIMAX does not guarantee the condition of your machine upon delivery.

  • Page 30: Lifting And Rigging

    IFTING AND RIGGING Lift the TAT-SRV by using the forklift pockets, as seen in Figure 3-1. FORKLIFT POCKET HOLE TO SECURE THE TESTER TO THE VEHICLE (4 TOTAL) 3-1. L IGURE IFTING AND SECURING POINTS 3-1. L ABLE IFTING AND SECURING POINT IDENTIFICATION Number Component Forklift pocket.

  • Page 31: Filling The Reservoirs And Lubricator

    3.4 F ILLING THE RESERVOIRS AND LUBRICATOR Do the following before operating: 1. Fill the hydraulic reservoir with hydraulic oil (AW-32 or AW-46) to half of the sight gauge. 2. Fill the lubricators with air tool oil (generic purpose, such as AW-32) and adjust the knob to set it to one drop per 25 strokes of the pump.

  • Page 32: Lamping Procedure

    3.6 C LAMPING PROCEDURE Do the following (refer to Figure 2-3 on page 11 as needed): 1. Check the integrity of the o-rings on the seal plates. Replace any damaged o-rings. NOTICE Any imperfections to the o-ring surface may cause a loss of pressure during testing.
  • Page 33 NOTICE Precision in this operation is important to prevent overshooting the designated pressure, which could damage the valve under test. WARNING Check Table 3-2 for recommended clamping pressures. Excess clamp pressures may damage the workpiece and machine and may result in serious personnel injury.
  • Page 34 If using ring type joint (RTJ) plates, refer to Figure A-31 on page 63 and Table A- 3 on page 63. WARNING To minimize the risk of damage to the machine, workpiece, and personnel injury, use technical judgment and discretion when increasing the clamping pressure above the recommendations listed in Table 3-2.

  • Page 35: Operation

    OPERATION IN THIS CHAPTER: 4.1 P - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -21 OPERATION CHECKS 4.2 C TAT-SRV P...

  • Page 36: Conducting Hydrostatic Tests ( Only With Tat-Srv Plus )

    NOTICE Follow any pressure ratings indicated on the load chart on the console, as shown in Table 3-2 on page 19. Exceeding the rated pressures could result in equipment damage. WARNING High-pressure valve testing may result in the sudden, unexpected release of stored energy with the potential to cause property damage or personnel injury.

  • Page 37: Adjusting The Valve On The Seal Plate

    4.2.3 Adjusting the valve on the seal plate If the valve (device under test) needs to be adjusted, do the following while refer- ring to Figure 2-1 on page 10: 1. Reduce the water supply pressure control to zero. 2. Open seal plate drain valve slowly to release all remaining pressure within the system and to drain water from the test piece as needed from the valve under test.

  • Page 38: Adjusting The Valve On The Seal Plate

    3. Open the seal plate block valve and vessel outlet block valve. 4. Turn the gas vessel diverter valve upward). 5. Turn the gas supply pressure regulator clockwise and monitoring the test pressure gauge, until it reaches the desired test pressure. Increase pressure gradually.

  • Page 39: Releasing The Clamp

    9. Turn the vessel diverter valve to upward. 10. Turn the gas supply pressure regulator clockwise while monitoring the test pressure gauge, until it reaches the desired test pressure. Increase pressure gradually. ELEASING THE CLAMP WARNING Do not release the clamp pressure while the valves under test is pressurized.

  • Page 40: Preparing The Machine For Transport

    4. Rotate the clamp pressure control to zero. 5. Check that clamp pressure gauge shows 0 psi/bar. 6. Open the clamp release valve to release the test piece from the test table. 7. Slide the clamp bars away from the test piece and remove from the table. REPARING THE MACHINE FOR TRANSPORT When transporting the machine to a different location, do the following: 1.

  • Page 41: Maintenance

    MAINTENANCE AINTENANCE CHECKLIST Table 5-1 lists maintenance intervals and their associated tasks. 5-1. M ABLE AINTENANCE INTERVALS AND TASKS Interval Task Inspect the testing unit, including all hose connections, inlet supply lines, and outlet lines. Before each use Check the o-rings on the seal plates for cracks or nicks. Replace if necessary. Check the lubricator to ensure one drip to every 25 strokes of the pump.
  • Page 42 WARNING To minimize the risk of damage to the machine, workpiece, and personnel injury, use technical judgment and discretion when increasing the clamping pressure above the recommendations listed in Table 3-2 on page 19. Page 28 7912-A1 Operating Manual...

  • Page 43: Storage And Shipping

    STORAGE AND SHIPPING IN THIS CHAPTER: 6.1 S - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -29 TORAGE 6.1.1 S - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -29...

  • Page 44: Shipping

    HIPPING Check that the machine’s legs are adjusted to the lowest height (see Section 4.6 on page 26). ECOMMISSIONING To decommission the TAT-SRV before disposal, remove the air tool oil and hydraulic fluid before dismantling machine components. Refer to Appendix A for component assembly information.

  • Page 45: Appendix Aassembly Drawings

    APPENDIX A ASSEMBLY DRAWINGS Drawing list A-1. TAT-SRV (P/N 96229) - - - - - - - - - - - - - - - - - - - - 32 IGURE ASSEMBLY WITH HYDRO FRONT DETAIL A-2. TAT-SRV (P/N 96229) - - - - - - - - - - - - - - - - - - - - - 33 IGURE ASSEMBLY WITH HYDRO BACK DETAIL A-3.

  • Page 46: Igure A-1. Tat-Srv Assembly With Hydro Front Detail (P/N 96229)

    A-1. TAT-SRV (P/N 96229) IGURE ASSEMBLY WITH HYDRO FRONT DETAIL Page 32 7912-A1 Operating Manual...

  • Page 47: Igure A-2. Tat-Srv Assembly With Hydro Back Detail (P/N 96229)

    A-2. TAT-SRV (P/N 96229) IGURE ASSEMBLY WITH HYDRO BACK DETAIL P/N 98061, Rev. 2 Page 33...

  • Page 48: Igure A-3. Tat-Srv Assembly With Hydro Back Detail 2 (P/N 96229)

    A-3. TAT-SRV 2 (P/N 96229) IGURE ASSEMBLY WITH HYDRO BACK DETAIL Page 34 7912-A1 Operating Manual...

  • Page 49: Igure A-4. Tat-Srv Assembly With Hydro Parts List (P/N 96229)

    ITEM P/N: DESCRIPTION 29154 PLATE SERIAL YEAR MODEL CE 2.0 X 3.0 46531 (NOT SHOWN) CRATE 79 X 54 X 48 ECORRCRATE TAT-8-25 59033 LABEL WARNING - CENTER OF BALANCE 1.5" DIA 64045 (NOT SHOWN) SLEEVE WELD COVER- 2.0 DIA W/VELCRO CLOSURE 77489 FTG CONNECTOR 3/8NPTM X 3/8 TUBE 78414...

  • Page 50: A-5. (P/N 97861)

    ADD 6 INCHES OF 73786 NOTES: 1. REFER TO 97964 SCHEMATIC FOR DESIGN PRESSURE OF SYSTEM. 6000 PSI MAXIMUM DETAIL A 2. DESIGN TEMPERATURE AND SCALE 1 / 4 OPERATING TEMPERATURE RANGE OF THIS MACHINE IS 0°F(-18°C) - 130°F(55°C). A-5. C A (P/N 97861) IGURE ONSOLE ASSEMBLY DETAIL...

  • Page 51: Igure A-6. Console Assembly Detail Andc (P/N 97861)

    DETAIL B DETAIL C SCALE 1 / 4 SCALE 1 / 2 2 INSTANCES 3 INSTANCES A-6. C C (P/N 97861) IGURE ONSOLE ASSEMBLY DETAIL P/N 98061, Rev. 2 Page 37...

  • Page 52: Igure A-7. Console Assembly Interior (P/N 97861)

    CONSOLE ASSEMBLY SCALE 1:5 A-7. C (P/N 97861) IGURE ONSOLE ASSEMBLY INTERIOR Page 38 7912-A1 Operating Manual...

  • Page 53: Igure A-8. Console Assembly Detaile (P/N 97861)

    DETAIL E SCALE 1 / 4 A-8. C E (P/N 97861) IGURE ONSOLE ASSEMBLY DETAIL P/N 98061, Rev. 2 Page 39...

  • Page 54: Igure A-9. Console Hose Assembly (P/N 97861)

    LENGTH 13" LENGTH 35" LENGTH 21" LENGTH 18" LENGTH 18" LENGTH 22" A-9. C (P/N 97861) IGURE ONSOLE HOSE ASSEMBLY Page 40 7912-A1 Operating Manual...

  • Page 55: Igure A-10. Console Low Pressure Hose Assembly (P/N 97861)

    LOW PRESSURE HOSE ASSEMBLY SCALE 1:5 A-10. C (P/N 97861) IGURE ONSOLE LOW PRESSURE HOSE ASSEMBLY P/N 98061, Rev. 2 Page 41...

  • Page 56: Igure A-11. Console 6 Ksi Hose Assembly And Detail

    6 KSI HOSES (PURPLE) SCALE 1:10 34 110 HOSE TO DRAIN DETAIL H SCALE 1 / 4 A-11. C 6 KSI H (P/N 97861) IGURE ONSOLE HOSE ASSEMBLY AND DETAIL Page 42 7912-A1 Operating Manual...

  • Page 57: Igure A-12. Console Interlock Assembly (P/N 97861)

    INTERLOCK ASSEMBLY SCALE 1 / 2 A-12. C (P/N 97861) IGURE ONSOLE INTERLOCK ASSEMBLY P/N 98061, Rev. 2 Page 43...

  • Page 58: Igure A-13. Console Assembly Parts List 1 (P/N 97861)

    PARTS LIST ITEM P/N: DESCRIPTION 12579 FTG PLUG 1/2 NPTM SOCKET 15472 FTG CROSS 1/2 NPTF 17105 SCREW 10-32 X 3 SHCS 27551 WASHER THRUST .984 ID X 1.654 OD X .039 35692 FTG ELBOW 1/2 NPTM X 1/2 NPTF ST 90 DEG BRASS 59342 FTG ELBOW 1/4 NPTMS X 1/4 TUBE F PRESTOLOCK NP 59438...

  • Page 59: Igure A-14. Console Assembly Parts List 2 (P/N 97861)

    ITEM P/N: DESCRIPTION 88733 FTG ADAPTER 10000 PSI 3/4 NPTF X 1/4 NPTF 88735 FTG 1/4 NPTM X 1/4 NPTM SS ELBOW 89377 PUMP AIR DRIVEN 5800 PSI OIL SERVICE 89460 VALVE PRESSURE RELIEF SET @ 6200 PSI CE CERTIFIED 89497 LABEL WARNING DO NOT EXCEED MAX RATING OF DUT 89498...

  • Page 60: Igure A-15. Tat-Srv

    PARTS LIST ITEM P/N: DESCRIPTION 79935 FTG NIPPLE 1 NPTM X 1 NPTM SS 91977 FTG ADAPTER PIPE 1 NPTM X 1/2 NPTF 92023 FTG TEE 1 NPTF SS 95334 FTG ELBOW 1 NPTF X 1 NPTF 90 DEG SS 97829 FTG ADAPTER 4 JICM X 1/2 NPTM SS 97833...

  • Page 61: Igure A-16. Tat-Srv Without Hydro Assembly Front Detail (P/N 98222)

    A-16. TAT-SRV (P/N 98222) IGURE WITHOUT HYDRO ASSEMBLY FRONT DETAIL P/N 98061, Rev. 2 Page 47...

  • Page 62: Igure A-17. Tat-Srv Without Hydro Assembly Back Detail 1 (P/N 98222)

    A-17. TAT-SRV 1 (P/N 98222) IGURE WITHOUT HYDRO ASSEMBLY BACK DETAIL Page 48 7912-A1 Operating Manual...

  • Page 63: Igure A-18. Tat-Srv Without Hydro Assembly Back Detail 2 (P/N 98222)

    A-18. TAT-SRV 2 (P/N 98222) IGURE WITHOUT HYDRO ASSEMBLY BACK DETAIL P/N 98061, Rev. 2 Page 49...

  • Page 64: Igure A-19. Tat-Srv Assembly With Hydro Parts List (P/N 98222)

    PARTS LIST ITEM P/N: DESCRIPTION 29154 PLATE SERIAL YEAR MODEL CE 2.0 X 3.0 46531 (NOT SHOWN) CRATE 79 X 54 X 48 ECORRCRATE TAT-8-25 59033 LABEL WARNING - CENTER OF BALANCE 1.5" DIA 64045 (NOT SHOWN) SLEEVE WELD COVER- 2.0 DIA W/VELCRO CLOSURE 77489 FTG CONNECTOR 3/8NPTM X 3/8 TUBE 78414...

  • Page 65: Igure A-20. Console Assembly Detaila (P/N 98223)

    NOTES: 1. REFER TO 97964 SCHEMATIC FOR DESIGN PRESSURE OF SYSTEM. 6000 PSI MAXIMUM DETAIL A 2. DESIGN TEMPERATURE AND SCALE 1 / 4 OPERATING TEMPERATURE RANGE OF THIS MACHINE IS 0°F(-18°C) - 130°F(55°C). A-20. C A (P/N 98223) IGURE ONSOLE ASSEMBLY DETAIL P/N 98061, Rev.

  • Page 66: Igure A-21. Console Assembly Detail Andc (P/N 98223)

    DETAIL B DETAIL C SCALE 1 / 4 SCALE 1 / 2 2 INSTANCES 3 INSTANCES A-21. C C (P/N 98223) IGURE ONSOLE ASSEMBLY DETAIL Page 52 7912-A1 Operating Manual...

  • Page 67: Igure A-22. Console Assembly Interior (P/N 98223)

    CONSOLE ASSEMBLY SCALE 1:5 A-22. C (P/N 98223) IGURE ONSOLE ASSEMBLY INTERIOR P/N 98061, Rev. 2 Page 53...

  • Page 68: Igure A-23. Console Assembly Detaile (P/N 98223)

    DETAIL E SCALE 1 / 4 A-23. C E (P/N 98223) IGURE ONSOLE ASSEMBLY DETAIL Page 54 7912-A1 Operating Manual...

  • Page 69: Igure A-24. Console Hose Assembly (P/N 98223)

    LENGTH 31" LENGTH 23" LENGTH 17" LENGTH 22" A-24. C (P/N 98223) IGURE ONSOLE HOSE ASSEMBLY P/N 98061, Rev. 2 Page 55...

  • Page 70: Igure A-25. Console 3 Ksi And 6 Ksi Hose Assembly (P/N 98223)

    33 101 6 KSI HOSES (PURPLE) 3 KSI HOSES (ORANGE) SCALE 1/8 A-25. C 3 KSI 6 KSI (P/N 98223) IGURE ONSOLE HOSE ASSEMBLY Page 56 7912-A1 Operating Manual...

  • Page 71: Igure A-26. Console Interlock Assembly (P/N 98223)

    INTERLOCK ASSEMBLY SCALE 1 / 2 A-26. C (P/N 98223) IGURE ONSOLE INTERLOCK ASSEMBLY P/N 98061, Rev. 2 Page 57...

  • Page 72: Igure A-27. Console Assembly Parts List 1 (P/N 98223)

    ITEM P/N: DESCRIPTION 12579 FTG PLUG 1/2 NPTM SOCKET 15472 FTG CROSS 1/2 NPTF 17105 SCREW 10-32 X 3 SHCS 27551 WASHER THRUST .984 ID X 1.654 OD X .039 35692 FTG ELBOW 1/2 NPTM X 1/2 NPTF ST 90 DEG BRASS 57062 SCREW 1/4-28 X 1/2 BHSCS 59342...

  • Page 73: Igure A-28. Console Assembly Parts List 2 (P/N 98223)

    PARTS LIST ITEM P/N: DESCRIPTION 88735 FTG 1/4 NPTM X 1/4 NPTM SS ELBOW 89377 PUMP AIR DRIVEN 5800 PSI OIL SERVICE 89497 LABEL WARNING DO NOT EXCEED MAX RATING OF DUT 89498 LABEL WARNING DO NOT RELEASE CLAMP WHILE VALVE IS PRESSURIZED 89499 LABEL CAUTION DO NOT LIFT WITH VALVE CLAMPED 89500...

  • Page 74: Igure A-29. Tat-Srv

    PARTS LIST ITEM P/N: DESCRIPTION 79935 FTG NIPPLE 1 NPTM X 1 NPTM SS 2.77 LG 83139 FTG NIPPLE 1/2 NPTM X 1/4 NPTM SS 91977 FTG ADAPTER PIPE 1 NPTM X 1/2 NPTF 92023 FTG TEE 1 NPTF SS 95334 FTG ELBOW 1 NPTF X 1 NPTF 90 DEG SS 97386...

  • Page 75: Igure A-30. Clamp Arm Assembly (P/N 97981)

    PARTS LIST ITEM P/N: DESCRIPTION 80905 LABEL WARNING - HAND CRUSH / FORCE FROM ABOVE GRAPHIC 1.13 TALL TRIANGLE YELLOW 82666 SCREW 3/8-16 X 3 SHCS SS 84986 SCREW 5/16-18 X 5/8 SHCS SS 85923 SCREW 1/2-13 X 1 SHCS 316 STAINLESS 89421 BLOCK CONTACT CLAMP ARM 89483...

  • Page 76: Able A-1. O- Rings Kit P/N 90025

    A-1. O- P/N 90025 ABLE RINGS KIT Part Description Quantity number 77589 O-RING 3-5/8 ID X 3-7/8 OD X 1/8 W NITRILE 90 DUROMETER (2-239) 77590 O-RING 4-5/8 ID X 5 OD X 3/16 W NITRILE 90 DUROMETER (2-350) 78456 O-RING 5-5/8 ID X 6 OD X 3/16 W NITRILE 90 DUROMETER (2-358) 78457 O-RING 6-3/4 ID X 7-1/8 OD X 3/16 W NITRILE 90 DUROMETER (2-364)

  • Page 77: Igure A-31. Rtj Clamp Pressure Chart

    A-31. RTJ IGURE CLAMP PRESSURE CHART A-3. RTJ (P/N 99936) ABLE ADAPTERS KIT Part Description Quantity number 100004 SEAL PLATE TAT RTJ R29 AND R37 100071 SEAL PLATE TAT RTJ R31 AND R36 100741 CRATE 12.5 ID X 12.5 ID X 5 ID ECORRCRATE W/ SPACER P/N 98061, Rev.
  • Page 78 This page intentionally left blank Page 64 7912-A1 Operating Manual...

  • Page 79: Appendix Bschematics

    APPENDIX B SCHEMATICS Schematics list B-1. S (P/N 97964) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66 IGURE CHEMATIC B-2.
  • Page 80 B-1. S (P/N 97964) IGURE CHEMATIC Page 66 7912-A1 Operating Manual...
  • Page 81 B-2. S (P/N 98245) IGURE CHEMATIC P/N 98061, Rev. 2 Page 67...
  • Page 82 This page intentionally left blank Page 68 7912-A1 Operating Manual...

  • Page 83: Appendix Csds

    APPENDIX C Contact CLIMAX for the current list of Safety Data Sheets. P/N 98061, Rev. 2 Page 69...
  • Page 84 This page intentionally left blank Page 70 7912-A1 Operating Manual...
