TERRA MCLK

OWNER'S MANUAL

V1.0

16th Sept 2021

Table of Contents

Need help?

Do you have a question about the TERRA MCLK and is the answer not in the manual?

Questions and answers

Summary of Contents for DENAFRIPS TERRA MCLK

Page 2: Table Of Contents
INSTALLATION & SAFETY INSTRUCTIONS ................2 INTRODUCTION ........................3 OPERATING INSTRUCTION ....................4 Quick Start Guide ......................4 Front Panel ........................5 Rear Panel ........................0 SPECIFICATIONS ........................1 WARRANTY ......................... 2 © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 3: Installation & Safety Instructions
 The electronics in modern hi-fi equipment is complex and may, therefore, be adversely affected or damaged by lightning. For protection of the audio system during electrical storms, disconnect the mains plugs. © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 4: Introduction
2. INTRODUCTION Thank you for purchasing the DENAFRIPS TERRA MCLK. The TERRA MCLK is our premium MASTER CLOCK GENERATOR. Equipped with the advanced FPGA, and the dual OCXO operating at audio frequencies 45.1584Mhz, 49.152Mhz, encapsulated in a metal shielded casing, located at the centre of the MCLK.
Page 5: Operating Instruction
 Output: 75ohms BNC outputs of various clock frequencies are available. Please refer to the details in section 3.2 & 3.3. WARNING  Please power off all equipment prior connection/disconnection of cables. © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 6: Front Panel
The LEDs display the main output frequency 45.1584MHz, 49.152MHz. (4) GROUP 1 / GROUP 2 LED The LEDs display the configured frequency of GROUP 1 / GROUP 2 as detailed in the following Table 1. © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 7 3. Leave the LED at 44K1. Press SETUP button once to confirm the setting and exit configuration mode. 4. Output frequencies of BNC Connectors “MCLK1 and MCLK4” will be 44.1kHz and 48kHz respectively. © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 8: Rear Panel
Connected the BNC 75ohms clock cable from the output to the external device. Please note that the clock frequency must be matched. Refer to Table 1. Output Frequency Configuration © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 9: Specifications
340W x 260D x 66H mm (Feet +18mm) Weight 6 Kg Color Silver / Black Warranty 36 Months Highlight Ultra Low Jitter OCXO Adjustable Output Frequencies Small Form Factor © DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE) ALL RIGHTS RESERVED...
Page 10: Warranty
5. WARRANTY DENAFRIPS TERRA purchased from the Authorized Distributor comes with 36 months of warranty from the date of purchase / delivery (whichever later). Defective Warranty Policy Within First 30 Days DENAFRIPS to bear both way shipping fee. Within 1st Year Customer to bear one-way shipping fee.
