Nose Video Gimbal
Video Gimbal
Nose
Astar / Twinstar
Installation Manual
Tyler - Nose Video Gimbal
For Eurocopter AS-350 / AS-355 Series Helicopters
FAA STC # SR00851LA
PLEASE RETURN THIS MANUAL WITH EQUIPMENT
This manual is available for download from our web site.
Tyler Camera Systems 14218 Aetna Street Van Nuys, Ca 91401 • USA
www.tylermount.com
(818) 989-4420
Fax (818) 989-0423

Advertisement

loading
Need help?

Need help?

Do you have a question about the AS-350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tyler AS-350

  • Page 1 For Eurocopter AS-350 / AS-355 Series Helicopters FAA STC # SR00851LA PLEASE RETURN THIS MANUAL WITH EQUIPMENT This manual is available for download from our web site. Tyler Camera Systems 14218 Aetna Street Van Nuys, Ca 91401 • USA www.tylermount.com • (818) 989-4420 •...
  • Page 2 REPORT #: U.M. INST-001 MODEL: A-S 350-355 DATE: 6/25/97 JOB #: __________ NOSE VIDEO GIMBAL (MODEL NVG-AS) INSTALLATION MANUAL FOR ASTAR / TWINSTAR HELICOPTERS PREPARED BY: Chris Tyler____ # OF PAGES: 26___________ _____________ CHECKED BY: George Wood _ # OF DRAWINGS: _____________ _____________ APPROVED BY: Jeff Fox D.E.R.
  • Page 3 (AS) NOSE VIDEO GIMBAL - PARTS LIST AIRFRAME BRACKETS LEFT SIDE - AIRFRAME BRACKET (two pieces) RIGHT SIDE - AIRFRAME BRACKET (two pieces) (ALTERNATE) AIRFRAME BRACKETS (2) AIRFRAME TABS [part #ASN-002] See: Page 4A of 8 BELLYPAN BELLYPAN TEMPLATE BELLYPAN (optional) SUPPORT TUBE SUPPORT TUBE SKID-GEAR CLAMP (two pieces) VIDEO GIMBAL...
  • Page 4 AIRFRAME BRACKETS ASSEMBLY INSTRUCTIONS (Pages 1-10) INSTALL AIRFRAME BRACKET ON HELICOPTER Typically install one on left (shown) or right side of helicopter. Page 1 of 10...
  • Page 5 Also, check to see if there is a hole near the rear of the left side (approx. 2 inches in diameter). If “Yes,” continue with step 03, if “No” continue with step 02. Note: Tyler’s Astar BELLYPAN, if used, may require adjusting the latches for proper fit. Also see page 3 for specifics on the BELLYPAN.
  • Page 6 Picture: • Hand Saw • 1-1/4” Hole Saw • 2” Hole Saw Using the ASTAR BELLYPAN TEMPLATE & TOOLS, and following the additional instructions on the template... • Mark and cut out a slot to allow the AIRFRAME BRACKET to protrude. •...
  • Page 7 Typically the Video Gimbal is installed on the left side of the helicopter (as shown). Hardware: (4) AN6-16ABOLTS (8) AN960-616L WASHERS (4) MS21083N6 NUTS Insert the two halves of the AIRFRAME BRACKET around the airframe counterweight, and connect the two halves by securely fastening the hardware. Note: The brackets are labeled “LEFT”...
  • Page 8 NOTE: THE AIRFRAME TABS MAY BE USED INSTEAD OF THE AIRFRAME BRACKETS. The AIRFRAME TAB requires the removal of the blue “factory” bottom plate. (Page 4, Picture A) The AIRFRAME TAB takes the place of the blue “factory” bottom plate. Attach and fasten one AIRFRAME TAB to the airframe counterweight, using the original six (6) bolts, on the blue “factory”...
  • Page 9 NOSE VIDEO GIMBAL ASSEMBLY INSTRUCTIONS Page 5 of 10...
  • Page 10 Note: The Main Tube is available in two types: • 1-Piece (as seen on page 8A) • 2-Piece (shown below). If using the 2-Piece type Main Tube, connect the two halves, and fasten with the L-Pin & Safety-Clip, as shown below. Page 6 of 10...
  • Page 11 Install forward skid-gear clamps. Insert 3/8” bolt and fasten lightly (to be fastened tightly later). Page 7 of 10...
  • Page 12 Install main tube, insert 3/8” bolt and fasten lightly (to be fastened tightly later). new style Slide the front support bracket over tube, install in forward tang and tighten bolt. Now, tighten bolts in the first and second steps. Note: If using the new style of “split” support bracket (above), also make sure to securely tighten its hardware.
  • Page 13 If necessary, utilize a Tyler Extension Adapter to raise the position of the Video Gimbal. Shown here, is the Cineflex type of Video Gimbal adapter. Install Video Gimbal adapter (Cineflex type shown, on a 1-Piece Main Tube) and fasten with 7/16” pin and safety clasp.
  • Page 14 Install Video Gimbal and fasten with 7/16” pin and safety clasp. Connect Video Gimbal cables. Page 9 of 10...
  • Page 15 Secure Video Gimbal cables to tube with tie-wraps or Velcro straps. Route cable into helicopter through belly pan and secure cables as necessary. Page 10 of 10...
  • Page 25 ASTAR – SAMPLE WEIGHT & BALANCE WEIGHT & BALANCE DATA AND EQUIPMENT LIST a-s st. tube Weight x Arm = Moment 6/23/98 AIRCRAFT MODEL REGISTRATION AIRCRAFT S/N PILOT SAMPLE SHEET AS 350 B/A N31621 2130 LONGITUDINAL LATERAL ITEM: WEIGHT MOMENT MOMENT AIRCRAFT EMPTY WEIGHT &...
  • Page 26 TWINSTAR – SAMPLE WEIGHT & BALANCE WEIGHT & BALANCE DATA AND EQUIPMENT LIST a-s st. tube mt. Weight x Arm = Moment 6/23/98 AIRCRAFT MODEL REGISTRATION AIRCRAFT S/N PILOT SAMPLE SHEET AS 355 F1 N5802W 5221 LONGITUDINAL LATERAL ITEM: WEIGHT MOMENT MOMENT AIRCRAFT EMPTY WEIGHT &...
