Simply Power Cooling Anywhere
USER GUIDE
Original Instructions
Product Models
| PC series (POWER COOL)
| PCH series (POWER COOL&HEAT)
| PCM series (POWERCOOL MULTI-SPLIT)
| SPC series (SINGLE-BOX POWERCOOL)
Portable Split Air Conditioner | Portable Single-packaged Air Conditioner
• For installation and operation details, please read this carefully before use for the convenient and safe use.
• The user shall be responsible for any problems caused by operation and use which are not described
in this manual, and the free warranty service will not be provided in this case.
• The product warranty is included in the user manual.
POWERCOOL Co., Ltd. (Korea)
+82-55-715-8868
www.powercoolair.com
Advertisement
Table of Contents
Summary of Contents for Powercool PC Series
- Page 1 Simply Power Cooling Anywhere USER GUIDE Original Instructions Product Models | PC series (POWER COOL) | PCH series (POWER COOL&HEAT) | PCM series (POWERCOOL MULTI-SPLIT) | SPC series (SINGLE-BOX POWERCOOL) Portable Split Air Conditioner | Portable Single-packaged Air Conditioner • For installation and operation details, please read this carefully before use for the convenient and safe use.
-
Page 2: Table Of Contents
Table of Contents Precautions for safety Name of each part How to operate How to clean the filter How to connect the connection hose How to store the product Checklist before reporting failures Product specification Product Warranty... -
Page 3: Precautions For Safety
Precautions for safety | Tips for installation The appliance shall be installed in accordance with If the supply cord is damaged, it must be replaced national wiring regulations. by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. If a problem occurs with the product, turn it off Unpacking and installation shall be done at a flat immediately and contact the dealership or customer... - Page 4 Precautions for safety | Tips for installation The dimensions of the space necessary for correct Do not shake the product. installation of the appliance including the minimum (Otherwise, it may cause injury or failure of the permissible distance to adjacent structures. product.) (Install at least 500mm from the wall)
- Page 5 Precautions for safety | Tips for use Install the product so that it does not come in direct Be sure to install the product in a space that is contact with salt or salt water (e.g., sea breeze, etc.) protected from rain. The Ingress Protection rating of (Otherwise, it may cause failure of the product.).
- Page 6 Precautions for safety | Tips for use Do not use the product in a situation of heavy rain, If a strange sound, smell or smoke occurs from the storm or typhoon. If the product gets wet, you must product, turn the power off immediately and contact contact the dealership or customer service center.
- Page 7 Precautions for safety | Tips for use Do not place obstacles near the inlet and outlet of The heat exchanger of the product has a sharp the product. surface, so be careful when cleaning it. (Otherwise, it may cause malfunction of the product (Otherwise, it may cause injury.) and fire.) Clean and remove dust from the surface and filter of...
- Page 8 Precautions for safety | Tips for use This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 9: Name Of Each Part
Name of each part PC, PCH series Grille Digital Control Panel Air Exhaust Portable Flexible Ducts Outdoor Unit Portable Drain Line Indoor Unit (Optional) Condensate Tank Filter Castor Wheels Front Panel Cover Connector Castor Wheels Power Plug Flex Connection Hose •There may be some differences depending on the model. - Page 10 Name of each part PCM series Air Exhaust Digital Control Panel Grille Portable Outdoor Unit Drain Line (Optional) Condensate Tank Castor Wheels Filter of the Portable Connector Indoor Unit Power Plug Portable Indoor Unit Flex Connection Hose •There may be some differences depending on the model. •The appearance of the product may be slightly different to improve functions.
- Page 11 Name of each part SPC series Air Exhaust Grille Exhaust Duct (Optional) Digital Control Panel Flexible Ducts Power Plug Front Panel Cover Filter Condensate Tank Castor Wheels •There may be some differences depending on the model. •The appearance of the product may be slightly different to improve functions.
-
Page 12: How To Operate
How to operate Name of each part of the Digital Control Panel and how to operate Select air volume Display 3 levels of air volume Display current temperature Select operation mode Models for cooling only: Cooling, ventilation Models for cooling & heating: Cooling, heating, ventilation Button for selecting air Button for operation mode volume... -
Page 13: How To Clean The Filter
How to clean the filter | PC, PCH, SPC series Filter Front Panel Cover PC, PCH Disassemble the front panel cover with both hands Remove internal filter, wash and dry it. (magnetic contact type). •There may be some differences depending on the model. •The appearance of the product may be slightly different to improve functions. - Page 14 How to clean the filter | PCM series Remove bolts on the side panel cover. Filter of the Portable Indoor Unit Front Panel Cover Disassemble the front panel cover with both hands. Remove internal filter, wash and dry it. •There may be some differences depending on the model. •The appearance of the product may be slightly different to improve functions.
-
Page 15: How To Connect The Connection Hose
How to connect the connection hose Connect the Flex connection hose to the connector. After connecting, assemble it with dedicated tools. How to store the product 연결 방법 When the product is not in use, disconnect the Store the product in a place with low humidity and power before storage. -
Page 16: Checklist Before Reporting Failures
Checklist before reporting failures Current status Things to be checked Measures It is not cool when the Is the cooling area of the product suitable Check if the model is for suitable cooling for cooling? (refer to the cooling area listed in the cooling mode is set. -
Page 17: Product Specification
Product specification Product Name SINGLE-BOX POWER COOL SPC-5000 Product Model Serial No. Power Source AC 230V 50Hz Cooling Capacity 5,200 ㎉/h Running Current 9.0 A 0.82 MPa 3.1 MPa Pressure (LOW) Pressure (HIGH) Refrigerant R-410A Charging 1.1 kg Manufacturer Power Cool Date(DD/MM/YY) . -
Page 18: Product Warranty
Product warranty Thank you very much for purchasing the POWERCOOL products. The warranty period for this product is calculated from the date of purchase, so make sure to get the purchase date for satisfactory service. You can get warranty as below. - Page 19 Address: 35, Sanmakgongdannam11-gill, Yangsan-si, Gyeongsangnam-do, 50568 South Korea TEL: 055-715-8868 FAX: 055-715-8878 E-mail: powerair@powercoolair.com PCUG(EN2)-21-04...
