Edge Stand
H-Universal Stand
Assembly Instructions
Introduction
Assembly for the Edge™ Stand or H-Universal™ Stand
includes the base, column, and system platform.
You can install optional peripherals and accessories on
the stand; refer to their separate installation
instructions. Each product is packaged separately. If
installing multiple products on the stand, you may
receive duplicate tools, cords, and instructions across
kits. Please disregard any duplicates.
Install products in the order listed on the enclosed
insert Installation sequence of products on the stand.
Assembly is easiest with more than one person.
See the stand's user guide for information on setting
up the ultrasound system to use accessories and
peripherals and for information on cleaning and
disinfecting.
Assembled H-Universal Stand. Shown with M-Turbo®
ultrasound system and optional basket, black-&-
white printer, and Triple Transducer Connect.
Contents
See also "Cables and connectors" on page 4.
Description
Illustration
(Quantity)
Column
(1)
Base
(1)
System
platform
(1)
Storage cup
(4)
Cord catch
pre-installed
(4)
Cord hook
(2)
Back plate for
cord hook
(2)
Stand hook
(2)
1
Advertisement
Table of Contents
Summary of Contents for SonoSite Edge Stant H-Universal Stand
- Page 1 Edge Stand Contents See also “Cables and connectors” on page 4. H-Universal Stand Assembly Instructions Description Illustration (Quantity) Column Introduction Assembly for the Edge™ Stand or H-Universal™ Stand includes the base, column, and system platform. You can install optional peripherals and accessories on the stand;...
- Page 2 Orient the back of the column with the back of the base. Insert the four cups: Align the grooves and press The back of the base has the SonoSite logo. into place. The back of the column has a lever at the top.
- Page 3 b Place the ultrasound system on the system b Insert the back plate of the cord hook into the platform, ensuring that the transducer cable is lower opening of the column side, oriented as positioned between the handles of the stand. below.
- Page 4 S-video out S-video in DVI video out Edge, H-Universal, M-Turbo, SonoSite, and the SonoSite logo are registered (in some jurisdictions) and unregistered trademarks Composite video out owned by SonoSite, Inc. Non-SonoSite product names may be trademarks or registered Audio out trademarks of their respective owners.
