Summary of Contents for MeiDong Diamond
- Page 1 User’s Guide Diamond FCC ID:2AB5T-DIAMOND...
-
Page 2: Table Of Contents
Contents 1. Introduction 2. Battery Precaution 3. Getting Started 4. Cable Connection 5. Bluetooth Connection and disconnection 6. NFC Connection 7. Microphone usage 8. LED Display Status 9. Battery Charging 10. Product Care Please read the following safety warning and precaution before using your device. -
Page 3: Introduction
Rechargeable battery can be charged by USB cable Operating range up to 20 meters 1. Introduction Thank you for purchasing the Diamond Audio system-a music player, an innovative portable Bluetooth speaker with built-in battery. This device can be easily connected with audio or video devices for your traveling and daily needs. -
Page 4: Battery Precaution
2. Battery Precautions The device can be powered by built-in rechargeable lithium battery. Please charge the battery for at least 8 hours before your first use of device. If the device is not used for a long period of time, the battery may be out of power. -
Page 5: Getting Started
3. Getting Started General controls Play/Pause Previous Next Volume Down Volume UP Bluetooth pairing key Power switch Micro USB/Only for Charging. -
Page 6: Cable Connection
4. Cable Connection 3.5mm stereo jack 5. Bluetooth Connection and disconnection Pairing Diamond with your smartphone ( should be within 20 meters) a. Activate pairing mode on Diamond by switching “ON/OFF” button to “ON”. The LED will flash in red and blue color. - Page 7 After completing the steps above, a message on your smartphone will appear cofirming that your device is now . paired/connected. then you will see the blue LED light stay solid, which means that this speaker pairs with your smartphone succeessfully. In case of unsuccessfully pairing, push this speaker to “OFF”...
-
Page 8: Nfc Connection
6. NFC Connection NFC: Near Field Communication, is a set of standard for Smartphone and this speaker establish Bluetooth radio communication with each other by touching them together or bringing them into close proximity, usually no more than a few centimeters. Please activate the NFC function (subjects to tablets own setting) of your Bluetooth device. -
Page 9: Battery Charging
9. Battery Charging The device has built-in rechargeable lithium battery that can be charged by connecting to the USB port of your computer or into an AC adapter with USB port. When charging is completed, the red light will go off. 10. - Page 10 FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
