Janome MEMORY CRAFT 15000 Manual

System Update Version 2.10 for Memory Craft 15000
Updates are supplied to improve and upgrade your MC15000. You will benefit from
the latest developments in technology by installing these updates.
Before starting the update procedure, check the system version of your Memory
Craft 15000.
Turn your Memory Craft 15000's power switch ON. The version of the system will
be displayed for 2 seconds on the bottom right corner of the screen as shown in
the image to the right.
Update your Memory Craft 15000 if the current version of the system is less than
2.10.
* When updating to version 2.10 from version earlier than 2.00, it is necessary to
delete stored data for all favorite design settings. If stored data is not deleted,
problems with sewing may occur after the update is carried out.

1. Preparation

Please read articles 1 to 7 of these instructions and carry out updates after fully understanding the required
procedure.
To change the language displayed, use the "Language" option box to the top right. (The first language to be
displayed will be English.)
You will need a formatted USB flash drive to update your Memory Craft 15000. (Visit the link below for the
formatting procedures:
http://www.janome.co.jp/e/e_downloads/soft/update/how_to_format_the_USB_flash_drive.pdf)
Note: Be sure that your Memory Craft 15000 can detect the USB flash drive when it is inserted into the USB
port.
* A USB flash drive of Ver. 2.0 or later is recommended.

2. Using the USB Flash Drive

Insert the USB flash drive into your computer port.
Note: Please make sure that it is properly inserted and the PC
detects the USB flash drive.

3. Selecting USB drive

Open the "System Update for MC15000" option box, and select the
USB flash drive.

4. Copy Update Data

Click the "Copy" button and wait until the update files have been copied to the USB flash drive.
After all files have been copied to the USB flash drive, safely remove the flash drive from your computer.
