GE JGBP36BELBB Dimensions And Installation Information

30" free-standing self-clean gas range

Advertisement

Quick Links

JGBP36WEL/CEL/BEL
GE
30" Free-Standing Self-Clean Gas Range
®
Dimensions and Installation Information (in inches)
Note: Dimension from the wall to the front
of the closed door handle is 29". Depth to
front edge of cooktop 25-1/4".
Optional Gas Range Accessory Drip Pans
for Sealed and Standard Burner Models:
(Available at additional cost)
To order these accessory drip pans,
call toll-free 800-626-2002.
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed
with product for current dimensional data.
For answers to your Monogram,
®
GE
appliance questions, visit our website at
®
ge.com or call GE Answer Center
800.626.2000.
47-1/2
26-1/4*
46-3/8
Installation Information (Dimensions in inches)
30
47-1/2
26-1/4*
46-3/8
GE Profile
or
service,
®
36-1/4 ± 1/4
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
36-1/4 ± 1/4
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
Recommended common
area for gas outlet and
electrical outlet
30
2-1/2
8
4
24
2
9
C L
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
30
8
and shut-off valve
4
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
9
Specification Created 5/06
Recommended co
area for gas outlet
electrical outlet
2-1/2
24
2
C L
Recommended area for
330577
thru the floor connection
of pipe stub and shut-off v

Advertisement

loading
