DAD-504 (13-0096) BREATHABLE AIR RETRO FIT KIT
IMPORTANT: Read and follow all IN-
STRUCTIONS and SAFETY PRECAU-
TIONS before installing, operating or main-
taining this equipment. Keep this manual
for future reference.
DESCRIPTION
The DAD-504 is designed to attach to an
existing DeVilbiss DAD-500 Desiccant Air
Dryer. The DAD-504 offers appropriate
filtration and a connection for the attach-
ment of a DeVilbiss Breathable Air Hose
TM
and Air Vizor supplied air breathing
system.
SPECIFICATIONS
Charcoal Filter:
Air Inlet 1/2" NPT(F)
Air Outlet 1/2" NPT(F)
Air Flow Capacity 75 CFM
Maximum Operating
Pressure 150 PSIG (10.3 Bar)
Maximum Temperature 150° F (65.6°C)
Manual Mechanical Drain Standard
Pressure Differential
Indicator Standard
Aerosol Filter .003 ppm./wt.
Particulate Filter 3.0 micron
Flow Thru Regulator:
Flow Thru Ports 1/2" NPT(F)
Regulated Ports 1/4" NPT(F)
Air Flow Capacity (regulated)
with 100 PSI Inlet 28 CFM @ 60 PSI
Maximum Inlet Pressure 300 PSIG
Regulated Pressure 0-125 PSIG
Maximum Temperature 175° F (79.4°C)
This manual contains important information that all users must know and understand before using the equipment. This
information relates to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.
To help you recognize this information, we use the following terms to draw your attention to certain equipment labels and
portions of this manual. Please pay special attention to any label or information that is highlighted by one of these terms:
Important information to alert you to a
situation that might cause serious injury
if instructions are not followed.
Risk of explosion or fire.
Improper use can cause
personal injury.
• This product is designed and in-
tended for use in industrial com-
pressed air systems only. Do not use
for liquids or gasses other than air.
• Do not use where pressure or tem-
perature can exceed rated operating
conditions (see specifications).
• Regulated outlet pressure must
never be set higher than the maxi-
mum operating pressure of the
downstream air tool or equipment.
An outlet pressure gauge should
always be used.
Risk of illness or death. Carbon mon-
oxide can cause nausea, fainting or
death. Stop using if carbon monox-
ide is present. This unit does not
remove carbon monoxide. A carbon
monoxide monitor should be incor-
porated into your air supply line
to warn of the presence of carbon
monoxide.
SAFETY PRECAUTIONS
Important information that tells how to
prevent damage to equipment, or how to
avoid a situation that might cause minor
injury.
SERVICE BULLETIN
SB-6-176
Risk of injury. Do not place unit in
service without metal bowl guard
installed. Filter units are sold only
with metal bowl guards. To mini-
mize the danger of flying fragments
in the event of plastic bowl failure,
guard must not be removed. If the
unit is in service without the metal
bowl guard installed, manufacturer's
warranties are void and the manu-
facturer assumes no responsibility
for any resulting loss. If unit has
been in service and does not have a
metal bowl guard, order one and
install before placing back in service.
Certain compressor oils, cleaning
agents and solvents may attack the
plastic and rubber components used
in the construction of this product.
This product should not be used in
conjunciton with or in the vicinity of
these materials. Read and follow
material labels carefully. Please con-
sult DeVilbiss if in doubt.
Note
Information that you should pay special
attention to.
