GE QuickClean JBS15F Specifications

GE Appliances
JBS15F – GE 5.0 Cu. Ft. Free-Standing QuickClean
Dimensions (in inches)
29-7/8
46-1/2
†
1/4
26-1/4*
46-1/4
Specification Created 4/02
Electric Range
™
For all 30" Free-Standing Range
models with coil heating elements
7-1/2
7
7-1/2
3-1/2
REAR
WALL
2-1/4
CENTER LINE
*Dimension from wall to front of closed oven door
without handle.
†The range may be placed with a 0" clearance (flush) at
the back wall and side walls if the range side trims
extend beyond the cabinet fronts at least 1/4".
Self Clean models only.
KW Rating
240V 11.5
5
208V 9.1
2-1/4
Receptacle Locations
Locally approved flexible service cord or conduit must be used because
terminals are not accessible after range installation. See shaded area in
drawing for location of electrical outlet box. Recommended outlet locations
allow range to be installed directly against wall.
Note: 30" Ranges conform to U.L. requirements for 0" spacing for adjacent
walls below countertops. Allow 1-1/2" spacing from the side of the range
to adjacent vertical walls above the cooktop surface.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
For answers to your Monogram,
GE appliance questions, visit our website at
GEAppliance.com or call
GE Answer Center ® service, 800.626.2000.
Listed by
Underwriters
Laboratories
R
® GE Profile ™ or
