Leak detector VAKUMATIK
Type: IVF R34
Vacuum leak detector –
Low pressure
Installation and
Operation Manual
Corresponding with EN 13160-2:2003 – Class I
Tank with Lining
Vacuum
Alarm ≥ -34mbar
max. -85mbar
Suction line down to
tank bottom
Pump
Only
FP>55°C, AIII
Document: 49001013.17.02
State: 04/2017
Advertisement
Table of Contents
Summary of Contents for Gardner Denver THOMAS ASF VAKUMATIK IVF R34
- Page 1 Leak detector VAKUMATIK Type: IVF R34 Vacuum leak detector – Low pressure Installation and Operation Manual Corresponding with EN 13160-2:2003 – Class I Only Suction line down to Tank with Lining FP>55°C, AIII tank bottom Vacuum Alarm ≥ -34mbar Pump max.
-
Page 2: Assembly Instructions Leak Detection Type Vakumatik Ivf-R34
Assembly instructions leak detection type Vakumatik IVF R34 Installation clearance... - Page 3 Scope of delivery (standard device) Leak detector Wall mounting material Installation and operation manual Components list: Pos. Description Other note / replacement part no. Section 7.4 Electric connection line Alarm lamp red Part no.49003550 Power lamp green Part no.49003559 ...
-
Page 4: System Design - Example Vacuum Leak Detector
Leak detector Vakumatik IVF R34 System design - example vacuum leak detector at single-walled steel tank with flexible leak protection lining... - Page 5 Leak detector Vakumatik IVF R34 Part description system design 1. Vacuum leak detector (e.g. type IVF-low pressure) 2. Visual display, green power lamp, red alarm lamp 3. Switch "Disable acoustic Alarm" 4. Measuring line - connection and test valve 5. Suction line - connection and test valve 6.
-
Page 6: Table Of Contents
Leak detector Vakumatik IVF R34 Outline Page Assembly instructions leak detection type Vakumatik IVF-R34 ........2 System design - example vacuum leak detector ..............4 1. General information – authorised service company ............7 2. Safety advice ........................7 3. Technical specification ..................... 7 4. -
Page 7: General Information - Authorised Service Company
Leak detector Vakumatik IVF R34 1. General information – authorised service company Assembly, starting up, maintenance and repair of this leak detector have to be carried out by specialists with proven knowledge of the construction and operation of systems for handling liquids that are hazardous to water, as well as special knowledge in leak detection systems. -
Page 8: Type / Intended Use
Leak detector Vakumatik IVF R34 4. Type / intended use The functional principle of the vacuum leak detector type Vakumatik IVF R34 (low pressure) with integrated pump is assessed as a Category 1 device pursuant to DIN EN 13160-2:2003. The device is exclusively designed for installation in vacuum leak detection systems at double-walled tanks or single-walled tanks with leak protection lining storing liquids hazardous to water with a flash point >55°C. -
Page 9: Other Suitable Tanks
Leak detector Vakumatik IVF R34 Other suitable tanks 5.3. - Double walled tanks / containers of a cylindrical, rectangular or spherical construction made from metallic or non-metallic material having a general building authority certification or at least with a statement by an authorized test department for leak detection systems, indicating that the interstitial spaces are suitable when used in connection with the leak detector and its switching values (see 4.1). - Page 10 Leak detector Vakumatik IVF R34 Material designation AdBlue Methylene glycol AHL ammonium nitrate urea sulution Methylester (biodiesel) E DIN 51606 (≤30%N)* (Adaptation required for leak detector components in contact with medium) ASL ammonium sulphate solution (36-40%)* Petroleum products with flash point Ethyl glycol, ethyl glycol monoethyl ether >55°C * Drilling oils...
-
Page 11: Functional Characteristics
Leak detector Vakumatik IVF R34 6. Functional characteristics - The leak detector (1) operates per the vacuum principle. A built-in vacuum pump (1.21) evacuates air from the interstitial space (12) via the suction line (6) and compensates for minor leaks in the system. The interstitial space is formed by the space between the two tank walls or between the leak protection lining and the tank wall (11, 14). -
Page 12: Instructions For Assembly
Leak detector Vakumatik IVF R34 7. Instructions for assembly General information / Assembly site 7.1. - The leak detector may only be assembled outside an ex-zone. - The conditions for use have to be observed as stated in section 5. - The maximum ambient temperature (see section 3) must not exceed. -
Page 13: Electrical Connection
Leak detector Vakumatik IVF R34 - The total length of the connecting lines between leak detector and tank may not exceed 50 m at an internal diameter of 6 mm. - Plastic connecting lines laid underground or Conduit aboveground must be laid in conduits. Conduits encasing connecting lines laid aboveground must also be impact- and weather-resistant. -
Page 14: Electrical Diagram
Leak detector Vakumatik IVF R34 Electrical diagram 7.5. Option Relay K1 External Alarm Max 240VDC 8A Phase LMP1 Power lamp green Microswitch pump Neutral line LMP3 Alarm lamp red Microswitch alarm PE Protective earth conductor LMP4 Lamp acoustic alarm Switch acoustic alarm AAH / AAL optional connection exterior SG1 Buzzer... -
Page 15: Starting Up
Leak detector Vakumatik IVF R34 8. Starting up Please ensure that the leak detector has been assembled and connected correctly as detailed in section 7. During evacuation, starting up and operation, harmful gases may leak from the interstitial space via the pump's outlet (exhaust) opening. Do not inhale, ensure sufficient ventilation. - Page 16 Leak detector Vakumatik IVF R34 Continuity test leak detector, connecting lines and interstitial space; leak test of the entire leak detection system: - Connect appropriate test device (e.g. THOMAS VDM300) to the test valve of the measuring line (1.13), establish a connection to the measuring device by turning the valve head. - Slowly turn valve head at the test valve of the suction line (1.15) in the specified direction;...
- Page 17 Leak detector Vakumatik IVF R34 - Verification of setting values of the leak detector (see Section 4.1): „Alarm On“ P and „Pump Off“ P If these values are incorrect then the correct values can be set by means of the pressure switch (1.23). Microswitch - Verification of the values "Pump On"...
- Page 18 Leak detector Vakumatik IVF R34 Completion of functional test: Bring the 3-way valves into the operation position shown on the left. Otherwise, the service flap will not close properly. Tightly connect any disconnected connecting lines. Under no circumstances leave the system in this condition;...
-
Page 19: Instructions For Use
Leak detector Vakumatik IVF R34 9. Instructions for use General advice 9.1. During evacuation, starting up and operation, harmful gases may leak from the interstitial space via the pump's outlet (exhaust) opening. Do not inhale, ensure sufficient ventilation. Proper monitoring of the system and/or the tank requires proper installation, starting up and regular functional tests as well as leak detector checks. -
Page 20: Advice In The Event Of A Fault Or A Alarm Situation
Leak detector Vakumatik IVF R34 Advice in the event of a fault or if the alarm is triggered 9.3. In the event of any fault and if the leak detector's alarm has been activated, the indicator lamp "Alarm red" (1.2) lights up and the inbuilt buzzer sounds (1.18). Qualified staff or authorised specialists should be called immediately in order to identify the fault. - Page 24 Hersteller: Firmenanschrift: Vertrieb Leckanzeiger / Produktion: Gardner Denver Thomas GmbH Gardner Denver Thomas GmbH Livry-Gargan-Str. 10 Karatasstrasse 4 82256 Fürstenfeldbruck bei München 87700 Memmingen Deutschland Deutschland Telefon: +49 (0) 8331 9570 1132 Fax: +49 (0) 8331 9570 1179 Mail: info@asf-leckanzeiger.de Internet: www.asf-leckanzeiger.de...
