Marecoluce Indus Series Use And Maintenance Instructions

Rev. 01-19/12/2019
Use and maintenance instructions
INDUS with water-tight terminal block
Street lighting luminaire for installation on poles or brackets Ø60mm on top
TECHNICAL DETAILS: please refer to the product label
The EU declaration of conformity can be downloaded from our website www.marecoluce.it
IP66
Protection degree against dust ingress, solid particles, moisture
Insulation Class II
The lighting source of this luminaire must be replaced by the manufacturer only
This product must not be disposed as a normal household waste
ENEC 05 certified luminaire

GENERAL MAINTENANCE RECOMMENDATIONS:

• CLEAN THE FITTING PERIODICALLY TO REMOVE POSSIBLE DIRT DEPOSITS ON THE LUMINAIRE.
• DO NOT USE HARSH DETERGENTS TO CLEAN THE DIFFUSER.
• CHECK THE TIGHTNESS OF THE SCREWS SECURING THE LUMINAIRE TO ITS SUPPORT.
• CHECK THE INTEGRITY OF THE COMPONENTS AND REPLACE THEM IN CASE OF ANY DAMAGE
BY USING ORIGINAL MARECO LUCE SPARE PARTS.

WARNINGS:

• THE SAFETY OF THIS PRODUCT IS GUARANTEED ONLY WITH THE RESPECT OF THE EXISTING RULES FOR
THE ELECTRICAL SYSTEMS, AND WITH THE APPROPRIATE USE OF THESE
INSTALLATION INSTRUCTIONS, THEREFORE IT IS NECESSARY TO KEEP THEM.
• THE IMPROPER USE OF THIS PRODUCT IS FORBIDDEN; ANY TAMPERING WITH THE PRODUCT OR
MODIFICATION OF THE PRODUCT THAT IS NOT AUTHORIZED BY MARECO LUCE CAN CAUSE DAMAGE TO
PEOPLE, ANIMALS OR THINGS, AND WILL VOID ANY WARRANTY OR LIABILITY.
• SWITCH OFF THE ELECTRICITY BEFORE CONDUCTING ANY KIND OF MAINTENANCE.
• THE PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH BEST PRACTICE.
• THE LIGHTING SOURCE OF THIS LUMINAIRE MUST BE REPLACED BY THE MANUFACTURER ONLY
• DAMAGED COMPONENTS MUST BE REPLACED WITH MARECO LUCE ORIGINAL SPARE PARTS BEFORE
REUSING THE PRODUCT.
9
11
15 Nm
12
15
13
10
8
Indus 34,2W-53,8W
The luminaire is suitable for indoor use
The luminaire is suitable for pole mounting at a maximum recommended height of 8 meters
Suitable for mounting
Luminaire weight
Maximum projected surface area subject to wind pressure
Dimensions of the compartment housing the connection box
(the box holding the connections)
Torque value (in Nm) to apply in tightening all bolts
and screws securing the luminaire on its support
Power factor
Indus 89,2W
The luminaire is suitable for indoor use
The luminaire is suitable for pole mounting at a maximum recommended height of 15 meters
Suitable for mounting
Luminaire weight
Maximum projected surface area subject to wind pressure
Dimensions of the compartment housing the connection box
(the box holding the connections)
Torque value (in Nm) to apply in tightening all bolts
and screws securing the luminaire on its support
Power factor
Pict.A
SIZE OF THE CONNECTION BOX
65/50
235/185
90/75
195/165
14
16
Via S.Croce n°121 z.i.
47032 Berinoro (FC) Italia
On pole and bracket
4,1 Kg
0,112 m²
Pict.A
15 Nm
>0,95
On pole and bracket
6,8 Kg
0,186 m²
Pict.A
15 Nm
>0,95
15
