Ultimate Support BOX 5 Instructions

Assembling keyboard tray

Included Parts with the Keyboard Tray - BOX 5

Additional Parts Needed from other boxes - BOX 1 & 2

Please check to see you have all parts before

starting. Once all parts are confirmed begin assembly.

Instructions for

Assembling Keyboard Tray

Keyboard Tray

Assembly

Keyboard Tray

#8 x .75" Pan Head Wood Screw

Assembled core table with legs (Instructions

for assembling core table and legs are

included in box 1 & 2)

x14

970.776.1920 . www.ultimatesupport.com

Table of Contents

Do you have a question about the BOX 5 and is the answer not in the manual?

Page 1 Instructions for Assembling Keyboard Tray Included Parts with the Keyboard Tray - BOX 5 Keyboard Tray Assembly Keyboard Tray #8 x .75" Pan Head Wood Screw Additional Parts Needed from other boxes - BOX 1 & 2 Assembled core table with legs (Instructions for assembling core table and legs are included in box 1 &...
Page 2 Keyboard tray assembly Core Table Pushed keyboard tray forward. Line-up the back four center holes of the core table with the back holes of Push For ward the keyboard tray assembly. Use four pan head wood screws to attach. 4 Pan Head Wood Screws Push keyboard tray back to access the other four keyboard tray assembly...
