- Page 1 Document 52181 04/28/2005 Rev: P/N 52181:A ECN 05-034...
- Page 2 Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system—typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, audible alarm only when heat on their sensors increases at a predeter- warning devices, and a fire alarm control panel with remote mined rate or reaches a predetermined level.
- Page 3 Installation Precautions Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected to light- sources of power before servicing.
- Page 4 Documentation Feedback Your feedback helps us keep our documentation up-to-date and accurate. If you have any com- ments or suggestions about our online Help or printed manuals, you can email us. Please include the following information: • Product name and version number (if applicable) •...
-
Page 5: Table Of Contents
Contents About This Manual Cautions and Warnings ....................9 Typographic Conventions................... 9 Supplemental Information..................9 Shortcuts to Operating Functions................11 1. Introduction Product Description....................13 Operating Features....................13 2. Use of the Controls Introduction ....................... 15 System Status Indicator LEDs ................. 16 Descriptions: ...................... - Page 6 How the Control Panel Indicates an Active Non-Fire Point ........33 Active Trouble Monitor Mode of Operation............34 How the Control Panel Indicates an Active Trouble Monitor ........ 34 How to Respond to an Active Trouble Monitor............34 Output Circuit Trouble Mode of Operation ............35 Overview .........................
- Page 7 Time, Date, and Holiday Functions ................. 59 Overview ......................... 59 How to View Time Control Selections ..............59 How to View Holiday Function Selections............. 60 How Time Control and Holiday Functions Work........... 60 NAC and Panel Circuit Coding................61 Overview of Coding ....................61 How to View Coding (F8) Selections ..............
- Page 8 Notes IQ-636X Operations Manual P/N 52181:A 04/28/2005...
-
Page 9: About This Manual
The table below provides a list of documents referenced in this manual, as well as documents for selected other compatible devices. The document series chart (DOC-ANS) provides the current document revision. A copy of this document is included in every shipment. Document Number (Ansul part no. if Compatible Conventional Devices (Non-addressable) applicable) Device Compatibility Document... - Page 10 Ansul LCD-80 Manual 50028 LCD-80TM Manual 51082 LDM Series Lamp Driver Annunciator Manual 15885 ANSUL-NCA Network Control Annunciator Manual 52185 SCS Smoke Control Manual (Smoke and HVAC Control Station) 15712 RPT-485W/RPT-485WF EIA-485 Annunciator Loop Repeater Manual 15640 DPI-232 Direct Panel Interface Manual...
-
Page 11: Shortcuts To Operating Functions
Shortcuts to Operating Functions About This Manual Shortcuts to Operating Functions To the left of each program function, you’ll find a keypad shortcut, which contains a series of keypad entries required to access the program function. All shortcuts start with the control panel in normal operation. - Page 12 Notes IQ-636X Operations Manual P/N 52181:A 04/28/2005...
-
Page 13: Introduction
1. Introduction Product Description The IQ-636X is a modular, intelligent Fire Alarm Control Panel (FACP) with an extensive list of powerful features suitable for most applications. Operating Features • Alarm Verification selection, to reduce unwanted alarms, for intelligent detector points •... - Page 14 Notes IQ-636X Operations Manual P/N 52181:A 04/28/2005...
-
Page 15: Use Of The Controls
2. Use of the Controls Introduction Listing of the controls and indicators and where to find information on their use: Operating Components Covered in Eight System Status Indicator LEDs “System Status Indicator LEDs” on page 16 Five Control Keys “Control Keys” on page 17 Programming Keypad “Programming Keypad”... -
Page 16: System Status Indicator Leds
2. Use of the Controls System Status Indicator LEDs System Status Indicator LEDs The control panel contains eight LEDs with labels as shown below: FIRE POWER PRE-ALARM SECURITY SUPERVISORY SYSTEM SIGNALS POINT ALARM TROUBLE SILENCED DISABLED NFS640-keypad1.cdr Figure 2 System Status Indicator LEDs Descriptions: Indicator Color... -
Page 17: Control Keys
Control Keys 2. Use of the Controls Control Keys The control panel provides five Control Keys as shown below: ACKNOWLEDGE SIGNAL DRILL SYSTEM LAMP SCROLL DISPLAY SILENCE RESET TEST HOLD 2 SECONDS NFS640-keypad2.cdr Figure 3 Control Keys Acknowledge/Scroll Display Use the key to respond to new alarm or trouble signals. -
Page 18: System Reset
2. Use of the Controls Control Keys System Reset Use the key to reset the control panel. When pressed, the control panel does the SYSTEM RESET following: • Clears ALL active inputs • Interrupts resettable power • Sends a “System Reset” message to the History buffer, and installed printers, CRT-2 terminals, and terminal mode LCD-80s If any alarm or trouble exists after you press the key, all NACs, control outputs, and... -
Page 19: Programming Keypad
Programming Keypad 2. Use of the Controls Programming Keypad The programming keypad includes: • Function keys: DETECTOR MODULE OUTPUT BATTERY LEVELS NEXT SELECTION PREVIOUS SELECTION RECALL LAST ENTRY AND INCREMENT NUMBER • ENTER • Cursor movement keys: /left arrow key, up key, right key, down key •... - Page 20 Notes IQ-636X Operations Manual P/N 52181:A 04/28/2005...
-
Page 21: Operation Of The Control Panel
3. Operation of the Control Panel Overview This section contains instructions for operating the control panel. Listed below are the topics detailed in this section: Section Refer to Page Normal Mode of Operation Fire Alarm Mode of Operation System Trouble Mode of Operation Security Alarm Mode of Operation Active Supervisory Signal Mode of Operation Pre-Alarm Warning Mode of Operation... -
Page 22: Normal Mode Of Operation
3. Operation of the Control Panel Normal Mode of Operation Normal Mode of Operation The system operates in Normal mode when no alarms or troubles exist. In Normal mode, the control panel displays a System Normal message as follows SYSTEM NORMAL 01:56P 071401 Sat Figure 5 Sample System Normal Message In Normal mode, the control panel does the following functions at regular intervals:... -
Page 23: Fire Alarm Mode Of Operation
Fire Alarm Mode of Operation 3. Operation of the Control Panel Fire Alarm Mode of Operation How the Control Panel Indicates a Fire Alarm When an initiating device (detector or monitor module) activates, the control panel does the following: • Produces a steady audible tone •... -
Page 24: Interpreting Fire Alarm Type Codes
3. Operation of the Control Panel Fire Alarm Mode of Operation Interpreting Fire Alarm Type Codes The Type Code that displays in the Alarm message indicates the function of the point that initiates the fire alarm. For example, a monitor module with a Type Code means that the monitor PULL STATION module connects to a manual pull station. -
Page 25: System Trouble Mode Of Operation
System Trouble Mode of Operation 3. Operation of the Control Panel System Trouble Mode of Operation How the Control Panel Indicates a System Trouble The system goes into system trouble when the control panel detects an electrical fault. If no fire alarms exist, the control panel does the following: •... - Page 26 3. Operation of the Control Panel System Trouble Mode of Operation If all troubles clear and no supervisory signals or fire alarms exist, the control panel does the following: • Returns to Normal operation (indicated by the “System Normal” message) •...
-
Page 27: Security Alarm Mode Of Operation
Security Alarm Mode of Operation 3. Operation of the Control Panel Security Alarm Mode of Operation (Not Suitable for Canadian Applications) How the Control Panel Indicates a Security Alarm The system goes into Security mode when a monitor module point programmed with a Security Type Code activates. -
Page 28: Interpreting Security Type Codes
3. Operation of the Control Panel Security Alarm Mode of Operation Interpreting Security Type Codes The Type Code that displays in the security alarm message indicates the type of security alarm being generated by the monitor module that initiates the alarm. For example, a monitor module with a Type Code of indicates an intruder in a protected premises area. -
Page 29: Active Supervisory Signal Mode Of Operation
Active Supervisory Signal Mode of Operation 3. Operation of the Control Panel Active Supervisory Signal Mode of Operation How the Control Panel Indicates an Active Supervisory The system goes into Supervisory mode when a monitor module point programmed with a Supervisory type code activates. -
Page 30: If Non-Latching Type Code Displays
3. Operation of the Control Panel Active Supervisory Signal Mode of Operation If Non-latching Type Code Displays Some Supervisory Type Codes do not latch the control panel. (Refer to Table 6 for a list of these type codes). The control panel automatically returns to normal operation, when you correct the condition that activates the supervisory point. -
Page 31: Pre-Alarm Warning Mode Of Operation
Pre-Alarm Warning Mode of Operation 3. Operation of the Control Panel Pre-Alarm Warning Mode of Operation How the Control Panel Indicates a Pre-Alarm Warning The control panel activates a Pre-Alarm Warning if a detector exceeds the programmed Pre-Alarm Alert or Action level. When a detector activates a Pre-Alarm, the control panel does the following: •... -
Page 32: Disabled Points Mode Of Operation
3. Operation of the Control Panel Disabled Points Mode of Operation Disabled Points Mode of Operation The control panel indicates disabled points by displaying a screen for each disabled detector, monitor module, control/relay module, and Panel Circuit. Disabled points do not cause an alarm or any Control-by-Event activity. -
Page 33: Non-Alarm Mode Of Operation
Non-Alarm Mode of Operation 3. Operation of the Control Panel Non-Alarm Mode of Operation Purpose of Non-Alarm Points Non-Alarm points are addressable monitor modules programmed with one of the Non-Alarm Type Codes listed in Table 7. Non-Alarm points, except Non-Fire, operate like monitored system functions that can produce troubles—but with the differences shown in the following sections. -
Page 34: Active Trouble Monitor Mode Of Operation
3. Operation of the Control Panel Active Trouble Monitor Mode of Operation Active Trouble Monitor Mode of Operation How the Control Panel Indicates an Active Trouble Monitor Trouble Monitor Points are monitor modules programmed with the following Type Codes: Type Code Latching Device Function Point Function... -
Page 35: Output Circuit Trouble Mode Of Operation
Output Circuit Trouble Mode of Operation 3. Operation of the Control Panel Output Circuit Trouble Mode of Operation Overview Output circuits include NACs, Panel Circuits 1-64, Control/Relay Modules, and Transponder Points. This section contains a description of control panel operation for each type of output circuit. •... -
Page 36: How The Control Panel Indicates A Nac Trouble
3. Operation of the Control Panel Output Circuit Trouble Mode of Operation How the Control Panel Indicates a NAC Trouble A Trouble occurring on a NAC causes the control panel to do the following: • Produce a pulsed audible tone •... -
Page 37: How To Respond To A Nac, Panel Circuit Or Control/Relay Trouble
Output Circuit Trouble Mode of Operation 3. Operation of the Control Panel How to Respond to a NAC, Panel Circuit or Control/Relay Trouble If the control panel indicates an active NAC, Panel Circuit or Control/Relay Trouble, take the following action: Press the key to silence the panel sounder and switch the ACKNOWLEDGE... -
Page 38: Operation Of Special System Timers
3. Operation of the Control Panel Operation of Special System Timers Operation of Special System Timers What are System Timers? There are user-programmable time delays for three specific functions: the Auto Silence Timer, the Alarm Verification Timer, and the Silence Inhibit Timer. Figure 20 shows a sample System Function Selection screen with system timer settings. -
Page 39: Silence Inhibit Timer
Waterflow Circuit Operation 3. Operation of the Control Panel Silence Inhibit Timer A timer that disables the key function for the programmed time (0-300 seconds) when SIGNAL SILENCE a fire alarm occurs. A Silence Inhibit Timer starts at the first fire alarm and restarts with each new fire alarm. - Page 40 Notes IQ-636X Operations Manual P/N 52181:A 04/28/2005...
-
Page 41: Read Status Operation
4. Read Status Operation Introduction This section contains instructions and sample screens to show how to access all Read Status functions and menus. For information on Read Status using a CRT-2 refer to Appendix C: Remote Terminal Access. What is Read Status? Read Status is a control panel function that lets you view system program information—but not change any programmed settings. -
Page 42: Viewing And Printing A Read Status
4. Read Status Operation Viewing and Printing a Read Status Viewing and Printing a Read Status To view or print Read Status information follow the instructions below: Option Press Lets you Read Point View information for a detector, module, NAC, 0 key, ENTER Panel Circuit, or zone... -
Page 43: How To View Read Status Of Devices, Zones, And System Settings
Viewing and Printing a Read Status 4. Read Status Operation How to View Read Status of Devices, Zones, and System Settings Overview Read Point options 0, 2, and 4 in the Read Status Screen let you display and view information for devices and zones programmed into the control panel, as well as view system and annunciator settings. -
Page 44: How To View Read Status For A Detector
4. Read Status Operation Viewing and Printing a Read Status How to View Read Status for a Detector From the “Read Status” screen, press 0, then press the key. ENTER You can now view Read Status for a detector as follows: press SLC number followed by three , enter the SLC number followed by the three digit DETECTOR... -
Page 45: How To View Read Status For A Control/Relay Or Monitor Module
Viewing and Printing a Read Status 4. Read Status Operation How to View Read Status for a Control/Relay or Monitor Module From the “Read Status” screen, press 0, then press the key. ENTER You can now view Read Status for a monitor or a control/relay module as follows: press , enter the SLC address, then MODULE... -
Page 46: How To View Read Status For A Nac Or Panel Circuit
4. Read Status Operation Viewing and Printing a Read Status How to View Read Status for a NAC or Panel Circuit From the “Read Status” screen, press 0, then press the key. ENTER You can now view Read Status for a NAC or Panel Circuit as follows: press , enter the device address, then press the OUTPUT... -
Page 47: How To View Read Status For A Software Zone (Z01-Z99)
Viewing and Printing a Read Status 4. Read Status Operation How to View Read Status for a Software Zone (Z01-Z99) From the “Read Status” screen, press 0, then press the key. ENTER You can now view Read Status for a Software Zone as follows: press Software , enter the zone number (01-99), then press the key. -
Page 48: How To Read Status For System Functions
4. Read Status Operation Viewing and Printing a Read Status How to Read Status for System Functions The “System Functions” screen specifies global settings for the control panel. From the “Read Status” screen, press 0, then press the key. ENTER You can now view Read Status for System Functions as follows: press Z, enter S0, press the key. -
Page 49: How To Read Status For Annunciator Selections
Viewing and Printing a Read Status 4. Read Status Operation How to Read Status for Annunciator Selections Annunciator Selection screens specify the information that displays on ACS annunciators. From the “Read Status” screen, press 0, then press the key. You can now view Read Status for System Functions as ENTER follows: press Z, enter S, enter annunciation selection number (1-4), press key. -
Page 50: How To Read Status For Battery Levels
4. Read Status Operation Viewing and Printing a Read Status Continued on the next page... An example of ACS selections in Annunciator Selection Screen 1: ANNUN SELECTION1: A1=H A2=C AC=M A4=* A5=* A6=* A7=* A8=* A9=* A10=* A11=* Figure 30 Annunciator Selection Screen 1 Example Note: An ACS selection marked with an asterisk (*) indicates no annunciator selection. -
Page 51: How To View Read Status For Event And Alarm History
Viewing and Printing a Read Status 4. Read Status Operation How to View Read Status for Event and Alarm History Overview The control panel maintains a History buffer of the last 800 events, each with a time and date stamp. History events include the following: •... -
Page 52: How To View Read Status For Alarm History
4. Read Status Operation Viewing and Printing a Read Status How to View Read Status for Alarm History Option 4 ( =4) lets you view the total number of alarms in the ALARM HIST History buffer (up to 200), then view each alarm in chronological sequence. From the “Read Status”... -
Page 53: How To Print Points, Event And Alarm History
Viewing and Printing a Read Status 4. Read Status Operation How to Print Points, Event and Alarm History Overview Read Point options 1, 3, and 5 in the “Read Status” screen let you print points, event history, and alarm history. This section contains instructions for printing, as well as sample point, event history, and alarm history printouts. -
Page 54: How To View And Print Hidden Event And Alarm History
4. Read Status Operation Viewing and Printing a Read Status How to View and Print Hidden Event and Alarm History The control panel maintains a copy of the preceding History buffer. For instance, if someone clears the History buffer using Status Change programming option 4, the control panel retains a copy of the History buffer. -
Page 55: Appendix A: Special Zone Operation
Appendix A: Special Zone Operation Overview This section contains information for operating the control panel as detailed in the topics listed below: Section Special Zone Refer to Page Releasing Zones (R0-R9) R0-R9 Time, Date, and Holiday Functions F5, F6, F7 NAC and Panel Circuit Coding Presignal and Positive Alarm Sequence (PAS) Operation... -
Page 56: Releasing Zones (R0-R9)
Appendix A: Special Zone Operation Releasing Zones (R0-R9) Releasing Zones (R0-R9) Purpose of Releasing Zones WARNING When used for CO releasing applications, observe proper precautions as stated in NFPA 12. Do not enter the protected space unless physical lockout and other safety procedures are fully completed. -
Page 57: How Releasing Zones Operate
Releasing Zones (R0-R9) Appendix A: Special Zone Operation How Releasing Zones Operate The figure below contains an illustrated example of how Releasing Zones work, using cross zone selections with four detectors and a NAC mapped to Releasing Zone 1 (listed as ZR1 in the CBE list). Table 15 lists the cross zone selections and the conditions that activate the Releasing Zone: PROGRM SMOKE(PHOTO) DETECTOR ADDR 2D101 01 R1 __ __ __A8P8** 2D101... - Page 58 Appendix A: Special Zone Operation Releasing Zones (R0-R9) Listing of each Cross Zone option and the conditions required to activate the Releasing Zone, according to the example shown in Figure 43. Cross Zone Condition(s) Required to Activate the Releasing zone Selection (Cross=) Cross=N An alarm from any detector activates the releasing circuit.
-
Page 59: Time, Date, And Holiday Functions
Time, Date, and Holiday Functions Appendix A: Special Zone Operation Time, Date, and Holiday Functions Overview The control panel includes a real-time clock that displays the time-of-day, the date, and the day-of-week. The clock includes a lithium battery backup. Time displays in a USA format (12-hour time format with month/day/year) or a EUR (European) format as shown below:. -
Page 60: How To View Holiday Function Selections
Appendix A: Special Zone Operation Time, Date, and Holiday Functions How to View Holiday Function Selections You can use the Read Status Entry option to view the current selection for the Holiday function. To do so, press the following keys in sequence: Note: For instructions on programming the Holiday function, refer to the IQ-636X Programming Manual. -
Page 61: Nac And Panel Circuit Coding
NAC and Panel Circuit Coding Appendix A: Special Zone Operation NAC and Panel Circuit Coding Overview of Coding A Coding selection is the Code Type that pulses when the control panel activates a NAC or Panel Circuit mapped to Special Zone F8. Special Zone F8 provides seven coding selections (see Table 17) that you can list in the CBE of a NAC or a Panel Circuit (ICM-4 or CRM-4). -
Page 62: Presignal And Positive Alarm Sequence (Pas) Operation
Appendix A: Special Zone Operation Presignal and Positive Alarm Sequence (PAS) Operation Presignal and Positive Alarm Sequence (PAS) Operation Overview This section describes the Presignal and PAS selection, and provides instructions on how to do the following: • View Presignal and PAS selections •... -
Page 63: How To View Presignal And Pas Selections
Presignal and Positive Alarm Sequence (PAS) Operation Appendix A: Special Zone Operation How to View Presignal and PAS Selections You can use the Read Status Entry option to view the current selection for the Presignal function. To do so, press the keys in sequence: Note: For instructions on programming the Presignal function, refer to the IQ-636X Programming Manual. -
Page 64: How To Respond To An Alarm With A Presignal Delay Timer (Pas Selected)
Appendix A: Special Zone Operation Presignal and Positive Alarm Sequence (PAS) Operation If the Presignal Delay Timer reaches its programmed value, without operator intervention, the control panel activates all outputs programmed to F0. How to Respond to an Alarm with a Presignal Delay Timer (PAS selected) If an alarm occurs with a Presignal Delay Timer (60-180 seconds) and PAS selected, the control panel displays an Alarm screen that shows the type of device and the SLC address of the device causing the alarm. -
Page 65: Appendix B: Intelligent Detector Functions
Appendix B: Intelligent Detector Functions Note: For instructions on selecting Intelligent Detector Functions, refer to the IQ-636X Programming Manual. Descriptions for Intelligent Detector Functions Function Description Analog Display The control panel reads and displays analog information from the 318 analog detectors (159 per SLC). The display shows the sensed air at the detector as a percentage of the alarm threshold for each detector. - Page 66 Notes IQ-636X Operations Manual P/N 52181:A 04/28/2005...
-
Page 67: Appendix C: Remote Terminal Access
Appendix C: Remote Terminal Access General Description The control panel can communicate with a remote terminal or computer connected to the EIA-232 PC/Terminal port. Refer to the IQ-636X Installation Manual for installation information. Note: See the IQ-636X Programming Manual for instructions on enabling the CRT. This port may be set up for interactive operation or for monitoring only. -
Page 68: Local Terminal Mode (Loct)
Appendix C: Remote Terminal Access Operating Modes Local Terminal Mode (LocT) Functions, passwords, and special requirements of Local Terminal Mode (LocT) are: Functions: Read Status, Alter Status, and Control Functions (Table 19). Passwords: User-defined password for Alter Status functions. Requirements: The terminal must be mounted in a UL 864 listed enclosure or positioned to provide equivalent protection against unauthorized use. -
Page 69: Local Monitor Mode (Locm)
Operating Modes Appendix C: Remote Terminal Access Local Monitor Mode (LocM) Functions, passwords, and special requirements of Local Monitor Mode (LocM) are: Functions: Read Status, Alter Status, and Control Functions (Table 20). Passwords: User-defined password for Alter Status and Control functions. Requirements: Password security feature for Control Functions eliminates the need for mounting the CRT-2 in an enclosure. -
Page 70: Remote Terminal Mode (Remt)
Appendix C: Remote Terminal Access Operating Modes Remote Terminal Mode (RemT) Functions, passwords, and special requirements of Remote Terminal Mode (RemT) are: Functions: Read Status only. See Table 21. Passwords: None Requirements: Use with UL ITE-listed terminals, including personal computers with the VeriFire™... -
Page 71: Using The Crt-2 For Read Status
Using the CRT-2 for Read Status Appendix C: Remote Terminal Access Using the CRT-2 for Read Status Overview This section shows how to perform Read Status functions from a CRT-2. Note: See the IQ-636X Programming Manual for instructions on enabling the CRT port. For more information see the “Read Status”... -
Page 72: Read Point
Appendix C: Remote Terminal Access Using the CRT-2 for Read Status Read Point From the “Read Status” menu, select option 1 - Read Point. The CRT-2 displays the following: Press Type (n)D(nnn), (n)M(nnn), P(nn), Z(nn), F(n),, R(n) or S(n) then hit Enter Address (01-159) Number SLC Number... -
Page 73: Display The Status Of All Programmed Points
Using the CRT-2 for Read Status Appendix C: Remote Terminal Access Display the Status of all Programmed Points From the “Read Status” menu, select option 3 - Read All Points. The CRT-2 displays a list of the status of all addressable detectors, modules, panel circuits, system parameters and software zones: Press NORMAL SMOKE(PHOTO) DETECTOR ADDR 1D001 Z03 Z Z Z Z 000%A5 PA:0 ** L1D001 NORMAL SMOKE(ION) -
Page 74: Send The Alarm History Buffer To The Crt-2
Appendix C: Remote Terminal Access Using the CRT-2 for Read Status Send the Alarm History Buffer to the CRT-2 From the “Read Status” menu select option 7 - History-All. This option sends the entire History buffer to the CRT-2, from most recent event to oldest event: Press ************************** ALARM HISTORY START *************************************... -
Page 75: Using The Crt-2 For Alter Status
Using the CRT-2 for Alter Status Appendix C: Remote Terminal Access Using the CRT-2 for Alter Status Overview This section shows how to do Alter Status functions from a CRT-2 Note: The panel must be in Local Terminal Mode (LocT) or Local Monitor Mode (LocM). Note: See the IQ-636X Programming Manual for instructions on enabling the CRT port. -
Page 76: Enable Or Disable Detectors, Modules, Or Panel Circuits
Appendix C: Remote Terminal Access Using the CRT-2 for Alter Status Enable or Disable Detectors, Modules, or Panel Circuits From the “Alter Status” menu select option 1 - Disable. Disable lets you enable or disable detectors, modules, panel circuits, or zones: SLC number Press Address (01-159) -
Page 77: Change Alarm And Pre-Alarm Levels
Using the CRT-2 for Alter Status Appendix C: Remote Terminal Access Change Alarm and Pre-Alarm levels This option lets you change the Alarm and Pre-Alarm levels of any addressable detector in the system. To do so, follow these steps. From the “Alter Status” menu select option 2 - Alarm/Pre-Alarm: Press Det. -
Page 78: Set The Pre-Alarm For Alert Or Action
Appendix C: Remote Terminal Access Using the CRT-2 for Alter Status Set the Pre-Alarm for Alert or Action Set Action/Alert lets you set the Pre-Alarm for Alert or Action. For example, Change Pre-Alarm from “Alert” to “Action” as follows: Press Set Pre-alarm Alert(NO)/Action(YES). -
Page 79: Appendix D: Point And System Troubles Lists
Appendix D: Point and System Troubles Lists There are a variety of point or system trouble types that may appear in a trouble message. The tables below give lists of the troubles and indications of their cause. Point (Device) Troubles A message from the “Trouble Type”... -
Page 80: System Troubles
Appendix D: Point and System Troubles Lists System Troubles System Troubles A message from the “Trouble Type” column in the following table will appear in the panel display when a system trouble occurs. Use this table to help determine the cause of the trouble. SYSTEM TROUBLES TROUBLE MESSAGE TYPE TROUBLE DESCRIPTION... - Page 81 INDEX fire alarm type codes 24 Functions 65 Abort 56 Read Status 44 Acknowledge/Scroll Display control key 17 supervisory alarm type codes 30 – Active Supervisory Signal 29 Disabled Points 32 panel indication 29 Drill control key 17 response to 29 Type Codes 30 Alarm Verification Timer 38 EDP-listed equipment, see also ITE-listed equipment 67...
- Page 82 INDEX Type Codes 35 Releasing Zone (R0-R9), read status 47 – NAC Circuit, read status 46 Releasing Zones (R0-R9) 56 – Non-Alarm Points 33 Remote Terminal Access 67 Non-Fire Point, active, panel indication 33 RemT, Remote Terminal Mode 67 Non-latching Supervisory Type Code 30 Normal Mode of Operation 22 Security Alarm 27 Not Suitable for Canadian Applications 27...
- Page 83 INDEX Warning When used for CO2 releasing applications... 21 Waterflow Circuit operation 39 IQ-636X Operations Manual P/N 52181:A 04/28/2005...
