- Page 1 XD05 PLUS Quick Start Guide About us For more product information, please visit our official website： http://www.xduoo.com Or scan us directly to enter the official website...
- Page 2 Introduction XD05 PLUS is an upgraded version of the previous generation XD-05 , which contains high performance USB, optical, coaxial audio decoding and headphone amp in a tiny body, also compatible with 05BL.The output power has been increased to 1000mW (at 32Ω...
- Page 3 10、1 Bass boost ON/OFF Switch. 11、One 2-Setting Gain Switch to set GAIN according to the headphones. Parameter Power Source: built-in 3.8V/5000mAh rechargeable lithium polymer battery Screen: 0.91 inch OLED screen Compliant OS: Windows XP/7/8/10, Mac OS X, IOS, Android system Output power: 1000mW (32Ω...
-
Page 4: Parts And Controls
Parts and Controls 1、6.5mm headphone jack Applies to 16-600Ω headphones. 2、boost switch, Increased thrust, adapt to different impedance headphones. 3、Bass boost switch Boost up + 6 dB. 4、Gain switch Gain Switch, boost up + 3/+11 dB, for drives high impedance headphone. 5、Power/Volume knob Turn right to turn on the power, brighten the display, continue to increase the volume;... -
Page 5: Screen Information
USB IN PCM3 Input soucre DAC filter Listening to Music 1. Connect headphone to the unit. *Note: The XD05 PLUS only supports dual channel Headset, does not support the mono Headset or Headset with remote control function or microphone function. - Page 6 2. Connect audio device with the unit. For details, see "Connecting to the Audio Device”. 3. Turn the power/ volume knob to right to turn on the unit. For the first time the unit connect with the computer would be taking some time. 4.
- Page 7 3. Use supplied typec to typec cable, connect to Android mobile phone / player with the OTG function. Remember to press INPUT key to USB IN position. 4. Use the Coaxial cable, connect with a Coaxial audio output device. Remember to press INPUT key to Coaxial in position.
-
Page 8: Install Usb Driver
MAC.) 2, you can downloaded the Driver from the official website, link: (http://ww- w.xduoo.com/xduoo/EnDownload.asp), choose XDUOO USB Drive, guiding is inside the package. 3, When using the device to play a high resolution audio files on the computer, we recommend using Jriver or Foobar2000 player. -
Page 9: Package List
→Charge the battery of the unit. →When battery life reduces to half, the battery is approaching the end of its service life. Consult your nearest xDuoo dealer for replacement. The battery cannot be charged →Check that the charge switch of unit is turned on. -
Page 10: Warranty Information
Our products can enjoy 12-month free warranty services from the date of the sale, if the warranty period is expired, our company will charge parts cost depend on the product fault conditions. Accessories are not covered under warranty. xDuoo Technology Co., LTD ADD: Room F1510,MingYueHuaDu Building, GongHe Industrial Road, XiXiang Town, Bao'an District,ShenZhen,China Tel：+86-0755-29799189...
