MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI
FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI
Manufactured by MILIC, LLC with marketing support from Flight Display Systems.
This product does not have FAA PMA approval.
TECHNICAL SUPPORT
470-239-7421, or
www.FlightDisplay.com
All manuals and user guides at all-guides.com
Rev:
B
Installation and Operation Manual
Blu-ray/DVD/CD/MP3 Player
Revision Date:
08/23/2013
Page 1 of 27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FD932DVD-BLU-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Flight Display Systems FD932DVD-BLU-2

  • Page 1 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 1 of 27 FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Installation and Operation Manual Blu-ray/DVD/CD/MP3 Player Manufactured by MILIC, LLC with marketing support from Flight Display Systems. This product does not have FAA PMA approval. TECHNICAL SUPPORT 470-239-7421, or www.FlightDisplay.com...
  • Page 2 All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 2 of 27 FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI BLU-RAY/DVD/CD/MP3 PLAYER © 2013 Flight Display Systems. All Rights Reserved. Flight Display Systems...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 3 of 27 Table of Contents General Information ........................4 1. Features ..........................4 2. Front View ..........................4 3. Discs Supported ........................5 Specifications ..........................6 Installation Instructions ......................6...

  • Page 4: General Information

     Selectable 720p/1080i/1080p video up conversion for DVD (up converted video available through HDMI output only)  Outputs for the FD932DVD-BLU-2 include (1) Composite Video and (1) HDMI  Outputs for the FD932DVD-BLU-2 Ver HDSDI include (1) Composite Video and (1) HD-SDI ...

  • Page 5: Discs Supported

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 5 of 27 Ventilation Slots and openings in the player are provided for ventilation, to ensure correct operation of the product. These openings protect the unit from overheating and must not be blocked or covered.

  • Page 6: Specifications

    The FD932DVD-BLU-2 player also includes a strain relief bracket which is used to secure the HDMI cable in place with a 3/16” cable tie. NOTE: Care should be taken to ensure the units are not installed in an area with poor ventilation, or in an area with excessive heat.

  • Page 7: Power

    Rear Panel Output/Mechanicals 1. VIDEO OUTPUT HDMI Video output to HD monitor with HDMI connector (FD932DVD-BLU-2) HD-SDI Video output to HD monitor or switch with BNC Connector (FD932DVD-BLU-2 Ver HDSDI) 2. POWER/GROUND INPUT & AUDIO OUT, IR Extension, CAN BUS, RS-485...

  • Page 8: Assembly Of Connector Spring Latch

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 8 of 27 Assembly of Connector Spring Latch (WPI Interconnect Products P/N 17-529) Unlocked Locked Spring Latch Assembly Spring Latch Assembly...

  • Page 9: Video Wiring Suggestions

    Recommended cable for composite is PIC 75 Ohm Coax, P/N V75268 for HD-SDI output and composite on FD932DVD-BLU-2 Ver HDSDI. This is a lightweight, flexible, and low signal loss cable which meets FAA requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).

  • Page 10: Power And Ground Wiring

    Right + and Right – connect to the receiving equipment’s Right channel input. The shield will be connected to the fuselage at one place only. NOTE: The FD932DVD-BLU-2/FD932DVD-BLU-2 Ver HDSDI has high impedance balanced outputs instead of the more popular low impedance inputs. This is usually not a problem.
  • Page 11 NOTE: On the following Pinout page, Pin 14, 15, 16 are reserved for CAN BUS integration. The FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI is only intended to easily integrate with the Flight Display Systems Select CMS. If more information regarding the CAN BUS integration with this device is required...

  • Page 12: Pinout For Db-25 Receptacle

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 12 of 27 Pinout for DB-25 Receptacle...

  • Page 13: Ship Kit Items

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 13 of 27 Ship Kit Items Product FD932DVD-BLU-2 Shipping Materials  (1) CD-MANUAL  (1) CD-BR REGION A  (1) CD-BR REGION B ...
  • Page 14 All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 14 of 27 Ship Kit Items Product FD932DVD-BLU-2 Ver HDSDI Shipping Materials  (1) CD-MANUAL  (1) CD-BR REGION A ...

  • Page 15: Rs485 Controls

    Page 15 of 27 RS485 Controls Full control of the FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI can be achieved through a standard RS485 port on the rear panel. All controls available on the front panel and all controls on the Blu-ray remote control are supported. Please refer to the DB25 connector diagram in the FD932DVD-BLU-2 &...

  • Page 16: Remote Control

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 16 of 27 Remote Control Available Commands Image for RS485 Control Reference with command number layover for Actual Remote for button reference...
  • Page 17 All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 17 of 27 RS485 Commands Cont’d PA Commands: “PA ON” will enable PA interrupt. “PA OFF” will disable PA interrupt. NOTE: “PA ON” command must be received every 9 seconds or interrupt will time out.

  • Page 18: Infrared Control

    Page 18 of 27 Infrared Control The FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI has the ability to use an infrared external eye, which is supplied by Flight Display Systems. The following guidelines should be met when using the external IR eye to insure correct and optimal operation.

  • Page 19: Operating Instructions

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 19 of 27 Operating Instructions Using Front panel and Remote Control Basic Playback Playback 1. Press the PWR button on the front panel to turn 1.

  • Page 20: Operating With Remote

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 20 of 27 Operating with the Remote About 7m 30° 30° Distance: Approximately 7m (23 feet) from The front of the remote sensor.

  • Page 21: Special Features

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 21 of 27 IMPORTANT NOTICE: THE FOLLOWING FUNCTIONS ARE APPLICABLE ONLY TO BD DISCS. IF OTHER DISC FORMATS ARE PLAYED, SCREEN DISPLAY AND OPERATION WILL BE DIFFERENT.

  • Page 22: Region Codes

    1. The first method uses the supplied firmware discs which will change the player’s firmware. This will allow the region code change to persist through a power cycle. Flight Display Systems recommends loading the appropriate firmware based on country where the Blu-ray discs are purchased. See the...

  • Page 23: Technical Drawing

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 23 of 27 Technical Drawing...
  • Page 24 All manuals and user guides at all-guides.com Rev: Revision Date: 08/23/2013 MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 24 of 27...

  • Page 25: Troubleshooting

    • Replace battery in remote control. Will not Physically Accept Discs The FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI may be in Standby Mode. Even though you may be able to hear a cooling fan blowing air, the Blu-ray player may still be in standby mode.

  • Page 26: Technical Support/Airworthiness

    MAN – FD932DVD-BLU-2 & FD932DVD-BLU-2 Ver HDSDI Page 26 of 27 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems 6435 Shiloh Road, Suite D...

  • Page 27: Warranty

    If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion.
