Trouble Shooting
If any functional abnormality is encountered, unplug the
unit from the mains socket and reconnect it again. Replace
your mobile device on the unit.
1. The LED indicator flash in red.
a) Mobile device is not placed in a correct position.
b) Placing any metal or other item with electric field
may cause short circuit, such as credit card, key,
memory card, coin, etc.
c) The charging system is malfunction.
Specifications
Power Supplies
Input: 5V
2A or 9V
Output: max. 10W
Charging Distance
3 mm (max.)
Frequency Band(s)
108.8 - 173.56 kHz
Max. Radio Frequency
19.61 dBuA/m @3m distance
Power Transmitted
Dimension (L x W x H)
86 x 86 x 8.2 mm
Net Weight
72 g
Features and specifications are subject to change without
prior notice.
Declaration of Conformity (RER)
Hereby, Currys Group Limited declares that the radio
equipment type [GP10WC20] is in compliance with Radio
Equipment Regulations 2017 (S.I. 2017/1206).
The full text of the UK declaration of conformity is
available at the following internet address:
https://www.currys.co.uk/
Click on HELP & SERVICES/Repairs & maintenance/
Product Manuals and enter the model number.
IB-GP10WC20-211201V3
10W Qi Wireless Charging
2A
Pad with Mains Charger
Instruction Manual
GP10WC20
Advertisement
Table of Contents
Related Manuals for Goji GP10WC20
Summary of Contents for Goji GP10WC20
- Page 1 Declaration of Conformity (RER) Hereby, Currys Group Limited declares that the radio equipment type [GP10WC20] is in compliance with Radio Equipment Regulations 2017 (S.I. 2017/1206). The full text of the UK declaration of conformity is available at the following internet address: https://www.currys.co.uk/...
- Page 2 Charging Your Digital Devices 4. Both Qi sensors must overlap. Thank you for purchasing your new 1. Connect the USB charging cable to the product. product. We recommend that you spend some time reading 2. Connect the other end of the USB charging cable to a this instruction manual in order that you fully powered USB device.
- Page 3 Väggladdare Vegglader Wall Charger Direktiv för Energirelaterade Produkter (ErP) Økodesigndirektivet (ErP) Energy related Products (ErP) Directive Modell GP10WC20 Modell GP10WC20 Model GP10WC20 Ingångsspänning AC 100-240 V Inngangsspenning AC 100-240 V Input voltage AC 100-240 V Ingångsfrekvens 50-60 Hz Vekselstrøm- 50-60 Hz...
- Page 4 Verkkovirtalaturi Vægoplader Energiaan liittyvien tuotteiden (ErP) direktiivi Direktiv for energirelaterede produkter (ErP) Malli GP10WC20 Model GP10WC20 Ottojännite AC 100-240 V Indgangsspænding AC 100-240 V Otto-AC-taajuus 50-60 Hz Indgangsfrekvens 50-60 Hz (vekselstrøm/AC) Antojännite / Antovirta / DC 5,0V 3,0A 15,0W or Antoteho Udgangsspænding /...
- Page 5 Safety Warnings Wireless Charging • Read all the instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. • Do not drop, tamper, disassemble or attempt to repair the unit by yourself.
- Page 6 • AC voltage: This symbol indicates that the rated voltage marked with the symbol is AC voltage. • DC voltage: This symbol indicates that the rated voltage marked with the symbol is DC voltage. The symbol on the product or its packaging indicates that this product must not be disposed of with your other household...
- Page 7 Safety Warnings Wall Charger • This unit is designed for indoor use only. • Always insert the USB device in the correct direction. Failure to do so may result in damage to the USB device and this unit. • Only use with products designed to be powered or charged via a USB socket.
- Page 8 The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
