STREET WISE SW3N1C28 Instruction Manual

6
2

CHARGING

The 3N1 Charger is equipped with Battery Life LED's (8) so you know how much battery power is
remaining. The four LED's represent 25% power each. (4 LED's 75%-100%, 3 LED's 50%-74%, 2
LED's 25%-49%, and 1 LED less than 24%) The rechargeable batteries are already installed.
Please do not attempt to open the unit, as this will void the warranty. IMPORTANT: Do not
charge for more than 12 hours at a time. Overcharging can damage the unit and void the
Warranty. When used infrequently the unit will need to be charged for 5 hours every 60 days. If the
flashlight is not as bright or if the electrical current becomes noticeably weaker, the unit will need
to be recharged. To charge follow the instructions below:
1. Plug the Mini USB plug into the Mini USB Charging Port (6) on the side of the 3N1 Charger.
2. Plug the other end into a USB charging device (wall plug, car plug, or computer).
3. Once connected the Battery Life LEDs (8) will flash indicating that the unit is charging.
4. To reduce charging time turn flashlight off.
5. When all four LEDs are showing a solid blue light the charging is complete and the battery is
fully charged.

USING AS A POWER BANK

1. If the device to be charged uses a mini USB plug you can use the included cord, if not you
will need to use the USB cord that came with your device.
2. Move the function Select Switch to the bottom (Off or Charging) position.
3. Plug the smaller end of the charging cord into the charging port of the device to be charged.
4. Plug the USB plug (larger end) into the USB Power Port (4) on the bottom of the 3N1
Charger.
5. To reduce charging time turn flashlight off.
SW3N1C28 3N1 Charger
Instruction Manual
1
4
8
1. Stun Contact Probes
2. LED Flashlight
3. Function Select Switch
7
(Top: Flashlight, Middle: Stun, Bottom: OFF)
4. USB Power Port
5. Stun Activation Button
6. Mini USB Charging Port
7. Stun Safety Cover
8. Battery Life LEDs
5
3
Revised 12/16/2019
