- Page 1 User Guide Kasa Smart Wi-Fi Plug Slim, Energy Monitoring KP115 1910012845 REV1.0.0 © 2022 TP-Link...
-
Page 2: Table Of Contents
Contents About This Guide ································································ 1 Introduction ··········································································· 2 Appearance ··········································································· 3 Set Up Your Smart Wi-Fi Plug Slim ···························· 4 Main Device Controls ······················································· 5 Configure Your Smart Wi-Fi Plug Slim ····················· 6 Create Scenes······································································ 8 Smart Actions ···································································· 10 Voice &... -
Page 3: About This Guide
• Specific product information can be found on the product page at https://www.tp-link.com/. • A Technical Community is provided for you to discuss our products at https://community.tp-link.com/. • Our Technical Support contact information can be found at the Help center of the Kasa Smart app and the... -
Page 4: Introduction
Introduction Kasa Smart Wi-Fi Plug Slim is a compact home device that turns your typical electrical wall outlet into a controllable, customizable and multi-functional outlet, enabling you to easily control your lights and household electronic devices via Kasa Smart app on your iOS or Android devices, no matter where you find yourself. -
Page 5: Appearance
Smart Wi-Fi Plug Slim has a control button to turn on/off devices plugged in, and LED to show you the current status. For detailed information, see the explanation below: *KP115 (US version) is used for demonstration in this guide. Press to turn the socket ON or OFF. -
Page 6: Set Up Your Smart Wi-Fi Plug Slim
Device Go to Google Play or the App Store or scan Open the app and use your TP-Link ID to log the QR code below to download and install the in. If you don’t have a TP-Link ID, tap Create to add your new Smart Plug. -
Page 7: Main Device Controls
Main Device Controls After you successfully set up your smart plug, you will see the home page of the Kasa Smart app. Here you can view and manage all devices that you've added to Kasa. Tap a smart plug to control and manage it. Home Page Device Status... -
Page 8: Configure Your Smart Wi-Fi Plug Slim
Configure Your Smart Wi-Fi Plug Slim Device Status page, you can set Schedule, set Timer, preset Away Mode, check Usage and change the settings of your smart plug. Set Schedule Set Timer to set a schedule for your smart to set the timer and your smart plug will plug to simplify your daily routine by creating automatically be turned on/off after the time automatic On/Off action. - Page 9 Preset Away Mode Check Usage Device Settings to preset the Away Mode and your to view and track energy consumption. to view and change the settings of smart plug will be randomly turned on/off your smart plug. during this time. Note: The start and end time must be on the same day.
-
Page 10: Create Scenes
Create Scenes A scene is a preset group of smart devices that can be programmed, customized and activated simultaneously at the touch of a button from your smartphone or tablet, allowing you to easily set your mood, activity or fit any special occasion. This page allows you to preset how your smart home devices should act automatically at a specific occasion. - Page 11 4. Name your scene. 5. Tap Save. Then your scene is created 6. Your scene is displayed in the scene list. successfully. Just tap the scene to activate it.
-
Page 12: Smart Actions
Smart Actions Smart Actions is a function that enables device interconnections and home automations. With Smart Actions, your Kasa devices can work together to create a smarter smart home. From the moment you wake up to the moment you drift asleep, Smart Actions make your home safer and more comfortable. - Page 13 Configure Motion Sensing If you already have a Kasa Smart Camera E.g. I want to turn the light on when my Kasa camera senses a motion. 1. Tap Motion Sensing then select a camera. 2. Select your Smart Plug.
- Page 14 3. Set the time for the actions. You can choose Always or tap Custom to choose time according to your needs. E.g. I want the motion to trigger the light on from 8:00 PM to 7:00 AM every day.
- Page 15 4. (Optional) Set an auto-off timer then tap Complete. Then your light will be turned off after the time you set if no motion is detected.
- Page 16 5. Name your action for easy identification. 6. The Smart Action is created successfully and displayed in the Smart Actions list.
- Page 17 Configure Control With a Switch If you already have a Kasa Smart Switch E.g. I want to turn the light on when I turn on my switch, and turn the light off when I turn off the switch. 1. Tap Control With a Switch.
- Page 18 3. Name your action for easy identification. 4. Now Your Smart Action is created successfully and displayed in the Smart Actions list.
- Page 19 Configure Schedule a Scene E.g. I want to turn on the scene I have created automatically at scheduled time. 1. Tap Schedule a Scene. 2. Select a scene you have created.
- Page 20 3. Set the time and frequency at which you want your scene to be turned on . 4. Name your action for easy identification.
- Page 21 5. Now Your Smart Action is created successfully and displayed in the Smart Actions list.
- Page 22 Configure Auto-Off Timer E.g. I want to turn off my light after 30 minutes when it is turned on. 1. Tap Auto-Off Timer, then select your Smart Plug.
- Page 23 2. Set the time.
- Page 24 3. Name your action for easy identification. 4. The Smart Action is created successfully and displayed in the Smart Actions list.
-
Page 25: Voice & Third-Party Support
Voice & Third-Party Support Use the Kasa Smart app to pair your smart Wi-Fi plug with with Amazon Alexa or Google Home Assistant, and enjoy a full hands-free experience. Kasa helps manage the rest of your smart home too, working with Samsung SmartThings to trigger changes when you arrive home or leave for the day. Launch the Kasa Smart app. - Page 26 Set up Amazon Alexa 1. Tap Amazon Alexa. 2. Tap Connect. 3. Sign in with your amazon account.
- Page 27 4. After sign-in, tap LINK. 5. Your TP-Link ID has been successfully linked with your amazon account. You can use Alexa voice commands to control your Smart Plug.
- Page 28 Set up Google Assistant 1. Tap Google Assistant. 2. Follow instructions to connect your device to your Google Home. Or find the FAQ at https://www.tp-link.com/en/support/faq/1534/.
-
Page 29: Authentication
Authentication FCC compliance information statement Product Name: Kasa Smart Wi-Fi Plug Slim, Energy Monitoring Model Number: KP115 Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: sales.usa@tp-link.com... - Page 30 We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
- Page 31 UKCA Mark UKCA Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca...
- Page 32 Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
- Page 33 前述合法通信，指依電信管理法規定作業之無線電通信。 低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 BSMI Notice 安全諮詢及注意事項 • 請按照本產品注明的電源類型使用本產品。 • 清潔本產品之前請先切斷電源。請勿使用液體、噴霧清潔劑或濕布進行清潔。 • 注意防潮，請勿將水或其他液體潑灑到本產品上。 • 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 • 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 • 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。 限用物質含有情況標示聲明書 設備名稱：Kasa Smart Wi-Fi Plug Slim, Energy Monitoring 型號（型式）：KP115 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Unit Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium chromium biphenyls...
- Page 34 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值。 Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition. 備考 2. " ○ " 系指該項限用物質之百分比含量未超出百分比含量基準值。 Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. 備考 3. " — " 系指該項限用物質為排除項目。 Note 3：The “−” indicates that the restricted substance corresponds to the exemption. Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам, що передбачені чинними законодавчими актами України. Safety Information • The automatic operation feature is Type 1.B action according to UL 60730-1. •...
- Page 35 Supported Load Type: For US Version: 100-120V~, 50/60Hz, 15A General/Resistive Load; 100-120V~, 50/60Hz, 1/6 HP Motor Load 100-120V~, 50/60Hz, Heater: ≤1500 W 100-120V~, 50/60Hz, Iron: ≤1500 W 100-120V~, 50/60Hz, Toaster: ≤850 W 100-120V~, 50/60Hz, Humidifier: ≤260 W 100-120V~, 50/60Hz, Tower Fan: ≤50 W Construction of Switch: Micro-Disconnection(μ) For EU Version: 100-240V~, 50/60Hz, 16A max, Resistive Load;...
- Page 36 Explanation of the symbols on the product label AC voltage Indoor use only μ Switch of micro-gap / micro-disconnection construction RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
