  • Page 1 User manual Automatic money detector PRO CL-200E...
  • Page 2 PRO CL-200E specially designed for verifying EURO banknotes. The present detector automatically carries out a complex analysis for authentication and gives a well-defined result, what enables operator to test banknotes quickly, without any special knowledge about false banknote protection types. By means of this device you can test a banknote in less than 1 sec, see the total sun and quantity of verified banknotes.
  • Page 3 Appearance Figure 1 1. Receiving tray. 2. Opening top cover. In case of banknote jam open the cover and remove the jammed banknote. 3. ‘+’ button switches on ‘Add’/ off ‘onE’ mode of summing up nominal values. If hold ‘+’ button for 3 seconds, banknote supply mode switches (forward/backward).
  • Page 4 Figure 2 Figure 3 Figure 4 from the right side (as shown on Fig.2). To set forward and backward supply mode hold ‘+’ button for 3 seconds. The upper green indicator corresponds to forward mode and the lower indicator – backward mode. 4.
  • Page 5 Orientation to: Center Right edge Left edge Figure 5 Figure 6 Incorrect orientation of notes Correct orientation of notes Attention! If a banknote is placed in receiving tray incorrectly, the banknote is not detected as an authentic one and any error code is displayed. In case of error check banknote orientation (Fig.4) and try to place the banknote into receiving tray once again.

  • Page 6: Troubleshooting

    Troubleshooting Error Code Reason Solution Magnetic marks location error Infra-red marks location error Banknote image detection 1. Check correctness error placement banknote into detector (see Fig.4) Paper quality error 2. Count the banknote again. If an error occurs again, the banknote Banknote size is incorrect can not be detected as authentic Colour printing quality error...
  • Page 7 Warranty Manufacturer guarantees proper functioning of the device during warranty period since the date of sale under condition of compliance with maintenance and storage procedures described in this manual. After unpacking the device please keep the package and technical description. Warranties are canceled in case the device was not transported in the original package or maintenance procedures were violated.
