RFN-SMART915T-4NQ-xyz
RFN-SMART433T-4NQ-xyz
RFN-SMART915T-3GQ-xyz
RFN-Gate433T-4GQ-xyz
1
RF-Smart – User Manual Rev 1.1 – 12/11/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFN-SMART915T-4NQ-xyz and is the answer not in the manual?

Questions and answers

Summary of Contents for RF RFN-SMART915T-4NQ-xyz

  • Page 1 RFN-SMART915T-4NQ-xyz RFN-SMART433T-4NQ-xyz RFN-SMART915T-3GQ-xyz RFN-Gate433T-4GQ-xyz RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 2 User Manual Rev. 1.1 – 12/11/2019 Front View Back View RF-Smart – User Manual Rev 1.1 – 12/11/2019...

  • Page 3: Hardware Interface Description

    1. Overview The RF-Gate is a complete RF Terminal solution for RF 433/915 Mhz applications. Based on Quectel Cellular modems and CC1310 radio. 2. Hardware Interface Description 2.1 Main features of the RF-Gate Feature Implementation Incorporates combination of Short Range and CELLULAR...
  • Page 4 4: 4G, • GN: Global Narrow band LTE, • NA: North America, etc. • 3G: 3G global x: B for battery installed, 0 no y: G:GPS, 0 GPS not present z: SW related RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 5 2.2 Hardware block diagram 2.2.1 Option: RFN-SMART915T-4NQ-xyz RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 6 2.2.2 Option: RFN-SMART433T-4NQ-xyz RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 7 2.2.3 Option: RFN-GATE433T-4GQ-xyz RF-Smart – User Manual Rev 1.1 – 12/11/2019...

  • Page 8: Interface Description

    IEC 60950-1 or EN 60950-1 or UL 60950-1 with limited output current up to 2A. The type of the receptacle assembled on the RF-Gate Terminal is 4 pin Micro Mate-N-LOK 3mm (0.11 inch) from MOLEX.
  • Page 9 In STAR versions ▪ RF_B LED blinks on RF activity ▪ RF_A LED blinks when moving the data between the RF and the Smart or 3G Module o In Receiver versions ▪ RF_B LED blinks when receiving an RF tag data transmission ▪...

  • Page 10: Usb Connector

    In Smart Version the USB is connected to a USB Hub managed by the Linux, any standard USB2 device can be connected to this port (max current supply 500mA fuse protected) (Managed by Linux, required user SW and device drivers to operate it) RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 11 3.5 RS-232 Interface The serial interface of the RF-Gate is intended for the communication between the RF module and the host application. This RS-232 interface is a data and control interface for transmitting data. It accepts, AT commands and provides multiplexed channels. EMC immunity complies with the vehicular environment requirements according to EN 301 489-7.
  • Page 12 4 3 2 1 RELAY A RELAY B GND MAIN INPUT A OPTOCOUPLER INPUT B OPTOCOUPLER Male 8-pole plug. OPEN COLLECTOR To use with MOLEX MICRO FIT GND OPTOCOUPLER PART NUMBER 43025-0800. RF-Smart – User Manual Rev 1.1 – 12/11/2019...

  • Page 13: Usb Type A Interface

    (Managed by Linux, required user SW and device drivers to operate it) 4. Mechanical Characteristics 4.1 General mechanical description Weight 180g Dimensions (max) L x W x H 147mm x 71.5mm x 34mm Case material Aluminum RF-Smart – User Manual Rev 1.1 – 12/11/2019...

  • Page 14: Environmental Requirements

    (*)Functional: the module is able to make and receive data calls and SMS. 4.3 Protection class IP40 Avoid exposing the Terminal to liquid or moisture. 4.4 RoHS compliance All hardware components are fully compliant with the EU RoHS and WEEE Directives. RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 15 Class 4 (33dBm ±2dB) for GSM 850/900 Class 1 (30dBm ±2dB) for GSM 1800/1900 Approvals CE/FCC/GCF/PTCRB Data HSUPA Max.5.76Mbps HSDPA Max 7.2Mbps UMTS Max.384Kbps (DL)/Max.384Kbps (UL) EDGE Max.296Kbps (DL)/Max 236.8kbps (UL) GPRS Max.107Kbps (DL)/Max.85.6Kbps (UL) 14.4Kbps RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 16 375Kbps (DL), Max. 375Kbps (UL) Max. Max. 32Kbps (DL), Max. 70Kbps (UL) Cat NB1: Max. 296Kbps (DL), Max. 236.8Kbps (UL) EDGE: Max. 107Kbps (DL), Max. 85.6Kbps (UL) GPRS: GPS, GLONASS, BeiDou/Compass, Galileo, QZSS RF-Smart – User Manual Rev 1.1 – 12/11/2019...
  • Page 17 Wireless notice This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 18 (SAR), field strength, or power density, whichever is most appropriate. b. Statement in UM: RF Exposure - This device is only authorized for use in a mobile application. At least 20 cm of separation distance between the (Product Name) device and the user's body must be maintained at all times.

This manual is also suitable for:

Rfn-smart433t-4nq-xyzRfn-smart915t-3gq-xyzRfn-gate433t-4gq-xyz
