Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect yourself and others by observing all
safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. Please
retain instructions for future reference.
UNPACKING
After unpacking unit, inspect carefully for any
damage that may have occurred during transit.
Check for loose, missing, or damaged parts. If any
damage is observed, a shipping damage claim must
be filed with carrier. Do not use the DURALAST
Spray Gun if broken, bent, cracked or damaged parts
(including labels) are noted. Any HVLP Spray Gun that
appears damaged in any way, operates abnormally
or is missing parts should be removed from service
immediately. If you suspect that the HVLP Spray Gun
was subjected to shock load (a load that was dropped
suddenly, unexpectedly, etc.) immediately discontinue
use until it has been checked by a factory authorized
service center.
WARNING
The following safety information is provided as a guideline to help you operate your HVLP Spray Gun under the safest possible conditions. Any tool or piece
of equipment can be potentially dangerous to use when safety or safe handling instructions are not known or not followed. The following safety instructions
are to provide the user with the information necessary for safe use and operation. Please read and retain these instructions for the continued safe use of
your tool. Failure to follow instructions listed below may result in serious injury. In addition, make certain that anyone that uses the equipment understands
and follows these safety instructions as well.
Explanation of Safety Signal Words
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property
damage.
NOTES: Provide clarity and helpful information.
05/15
2015 DURALAST
®
HVLP
®
80-376
HVLP
SPRAY GUN
®
Advertisement
Table of Contents
Summary of Contents for Duralast HVLP
- Page 1 WARNING The following safety information is provided as a guideline to help you operate your HVLP Spray Gun under the safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are not known or not followed. The following safety instructions are to provide the user with the information necessary for safe use and operation.
-
Page 2: Important Safety Instructions
Tools may be dangerous in the hands of untrained users. injury. 11. Maintain tools with care. 2. Do not disassemble the HVLP Spray Gun. Take it to a qualified 12. Keep tools dry and clean. professional when service or repair is required. -
Page 3: Spray Gun
7. Always lubricate and maintain the tool in safe operating condition. perform. 8. Only use accessories which are specifically designed for use with a 8. DO NOT carry the HVLP Spray Gun by the air hose, or yank the hose HVLP Spray Gun. from the air supply. - Page 4 First, prepare the HVLP Spray Gun according to the instructions under HVLP Spray Gun Setup on page 3. FAN DIRECTION Keep the HVLP Spray Gun upright and at a right angle to the Lock Ring workpiece- See Figures G and H.
-
Page 5: Maintenance
Follow the paint manufacturer’s recommendations for cleaning, solvent type and disposing of used solvent. Flush the HVLP Spray Gun a full hose length from the air compressor. If collecting flushed solvents in a metal container, transfer to a nonmetal container and flush the metal container. -
Page 6: Troubleshooting
Operating Instructions and Parts Manual 80-376 HVLP ® SPRAY GUN TROUBLESHOOTING GENERAL Problem Possible Causes Likely Solutions Sputtering Spray 1. Low paint level. 1. Refill. 2. Cup tipped. 2. Hold upright. 3. Clogged Air Vent. 3. Clean Air Vent hole. -
Page 7: Parts List
Vent Cap 80-376-20 Air Inlet 80-376-21 Fixing Screw Parts Diagram NOTE: Not all components of the HVLP Spray Gun are replacement items, but are illustrated as a convenient reference for location and position in the assembly sequence. 05/15 ® 2015 DURALAST... - Page 8 ® If for up to three years from the date of purchase of this DURALAST product, you find any defect in material or workmanship through normal usage, return it to the place of purchase, or to customer service for repair or replacement at our discretion. In order to obtain this service send your tool and proof of purchase, transportation pre-paid, to Q.A.
