How to adjust the Pneumatic system
Our Pneumatic system in charge of rise or lower the back-rest or the leg-rest depends
on model.
To adjust the angle of the back-rest / leg-rest just simply grasp it firmly and slightly
pull the lever upwards. being careful to maintain a firm hold on the back-rest /
leg-rest as you adjust it. Release the lever when you have the back-rest / leg-rest
at the required level and the back-rest / leg-rest will lock automatically in position.
How to adjust the head-rest
To adjust the head-rest, slightly hold the
head-rest and pull the lever upwards to
adjust the head-rest until the desired angle is
reached, release the lever and the head-rest
will lock automatically in position.
07
How to adjust the front arm-rest
To adjust the front arm-rest, slightly hold the
front arm-rest and pull the lever upwards to
adjust the front arm-rest until the desired
angle is reached, release the lever when you
have the front arm-rest at the required level
and the front arm-rest will lock automatically
in position.
No need to pull the lever when you only
need to raise the head-rest
Rapid diagnosis:
1.Tables that are equipped with double actuators:
If no actuators work when operating the foot, hand, or side controls, it is possible that the control box
is broken.
If one of the actuators doesn't work, it is more possible that this actuator is broken.
2.Tables that are equipped with a hand-control:
If the function LED on the hand control glows all the time, it may be possible that the hand control is
broken.
If the function LED on the hand-control doesn't glow when a key is pressed, it is more possible that
the hand-control or the control box is broken.
Before doing any work on the unit, disconnect the power cord from the power outlet.
Foot Control Replacement Instruction
blue yellow black red
