BRKT Brand SLIM3770 Instruction Manual

Low profile tilting flat panel mount
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
BRKT SLIM3770
Low Profile Tilting Flat Panel Mount
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUAL D'INSTRUCTIONS
CAUTION: DO NOT EXCEED MAXIMUM
LISTED WEIGHT CAPACITY. SERIOUS
INJURY OR PROPERTY DAMAGE MAY
OCCUR!
Max Screen Size: 70"
Max Weight Capacity: 88 LBS
V3
P1

Advertisement

loading

Related Manuals for BRKT Brand SLIM3770

Summary of Contents for BRKT Brand SLIM3770

  • Page 1 BRKT SLIM3770 Low Profile Tilting Flat Panel Mount INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES MANUAL D’INSTRUCTIONS CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! Max Screen Size: 70” Max Weight Capacity: 88 LBS...

  • Page 2: Tools Needed

    BRKT BRAND no ofrece ninguna garantía, ni expresa ni implícita, respecto de la información aquí incluida. BRKT BRAND no se responsabiliza de la precisión de la información provista en este documento, ni tampoco de que sea completa o suficiente.

  • Page 3: Hardware Part Numbers

    HARDWARE PART NUMBERS Package M M5 x 14 M6 x 30 M8 x 30 Square Washer Large Spacer M6 x 14 M8 x 20 Small Spacer Package W ST6.3 x 55mm Concrete Anchors D6 Washers Lag Bolts PRODUCT COMPONENT PARTS TV Mounting Hole Pattern (W x H) Minimum: 100mm x 100mm Maximum: 800mm x 400mm...
  • Page 4 STEP 1- ATTACH VERTICAL RAILS TO BACK OF TV Connect Vertical Rails to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Spacers Optional Spacers (M-H and M-G) are to be used when back of TV is curved or when more clearance is required.
  • Page 5 STEP 2A- WOOD STUD INSTALLATION (CONCRETE INSTALLATION SKIP TO 2B) Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro. Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre. LEVEL WALL PLATE WITH BUBBLE LEVEL AND MARK HOLES FOR DRILL...
  • Page 6 STEP 2B – SOLID CONCRETE INSTALLATION Use wall plate to mark mounting locations / drill pilot holes Use la placa de pared para marcar el lugar donde se realizará la instalación Utilisez la plaque murale pour marquer l'emplacement de montage LEVEL WALL PLATE Solid Concete Drill pilot hole...
  • Page 7 STEP 3 – ATTACH TV TO THE WALL PLATE Attach TV to the Wall Plate Cuelgue con el TV adherido. Accrochez avec le TV installé. Heavy, Assistance Required TRES LOURD ! Cette etape requiert deux personnes !PESADO! Necesitara ayuda para realizar esta operacion Turn the lock plate downward to lock the Wall Plate.

  • Page 8: Warranty Information

    BRKT BRAND. To the maximum extent permitted by law, BRKT BRAND disclaims any other warranties, expressed or implied, including warranties of fitness for a particular purpose and warranties of merchantability. BRKT BRAND will not be liable for any damages arising out of the use of, or inability to use, BRKT BRAND.
