- Page 1 Econovedades All the power of ORTHO-OXYHYDROGEN TECHNOLOGY at your service Mobile station for your garage Decarbonise - Decontaminate - Regenerate 4600 & 2300 LPH MODEL...
- Page 3 4600 LPH COMPACT PRO MODEL 2300 LPH COMPACT PRO MODEL Page 1...
- Page 4 THE FIRST START UP MUST BE DONE BY THE COMPANY AUTHORISED PERSONNEL. Warning- For your own safety it is forbidden to open the machine. Any rupture or sign of tampering in the safety seal will automatically void the warranty. VERY IMPORTANT: * NEVER APPROACH FLAME SOURCES CLOSE TO THE FILL PLUGS OR GAS DELIVERY TUBE, NOT EVEN WHEN THE MACHINE IS SWITCHED OFF AND NOT BEING USED IN SEVERAL DAYS.
- Page 5 AND WITH THE POTENTIOMETERS AT MINIMUM. IT SHOULD ALSO BE TURNED ON WITH THE PONTENTIOMETER AT MINIMUM. IMPORTANT - FOR THE 4600 LPH COMPACT PRO MODEL: IF THE ENGINE THAT IS BEING DECARBONISED STOPS DURING THE DECARBONISATION (AND THE MACHINE, FOR ANY TECHNICAL FAILURE,...
-
Page 6: Vehicle Preparation
FOR THE 4600 LPH COMPACT PRO MODEL VEHICLE PREPARATION If the vehicle have latent errors in the diagnosis, we will delete as far as possible. Before the cleaning with our machine, any type of engine should be at the correct working temperatura (warmed engine between 80ºC and 90ºC). - Page 7 If the main tank LED is in red, refill with the external filter recovered water and complete with distilled or osmosis water (never tap or bottled water). INTRODUCE WATER IN THE MAIN TANK UNTIL THE MAIN TANK LED TURNS GREEN. WARNING: ALWAYS USE THE ADEQUATE FUNNEL.
-
Page 8: Manual Override
WARNING: FIX THE TUBE WITH A FLANGE OR ADHESIVE TAPE, IN ORDER THAT THE TUBE IS NOT ASPIRED IN CASE OF POWERFUL TURBO ASPIRATIONS. 5) Once all is properly located and prepared, with green LEDs flashing, start up the engine and, previously placed the starting sensor will order the decarbonising machine to start the cleaning cycle. -
Page 9: Pressure Switch
The decarbonising machine will start the programmed cleaning cycle until completing the cycle. *The only way to start a new cleaning cycle, after the last cycle, is turning off the machine (switches position 0). PRESSURE SWITCH BEGINNING EVERY CLEANING PROCESS INDISPENSABLE THAT THE USER HAS UNDER CONTROL THE PRESSURE GAUGE. - Page 10 Reasons might be: 1- Obstructed tube. 2- The outlet valve does not open correctly. HOW TO ADJUST THE PRESSURE SWITCH: Remove the plastic cap. With a 3mm thin flat screwdriver CAUTION: setting very sensitive, wiht only ¼ turn, the pressure rises or drops from 1 Psi or more.
- Page 11 FOR THE 2300 LPH COMPACT PRO MODEL VEHICLE PREPARATION If the vehicle have latent errors in the diagnosis, we will delete as far as possible. Before the cleaning with our machine, any type of engine should be at the correct working temperatura (warmed engine between 80ºC and 90ºC).
-
Page 12: Very Important
VERY IMPORTANT START UP THE VEHICLE ENGINE BEFORE SWITCHING ON THE MACHINE 1) Place the gas outlet tube into the intake. The aim is to introduce the Ortho-Oxyhydrogen gas into the combustion chamber, ensuring that there where you place the tube, there is aspiration and there is no leakage. - Page 13 FOR ALL THE MODELS EXTERNAL FILTER LEVELS WARNING – FILL IN WITH DISTILLED OR OSMOSIS WATER UNTIL THE BLUE LINE Over time, this bubbler will also be filled with water, resulting from the recovery of the gas condensation. After each cleaning cycle the filter will have to be emptied until the blue line (MINIMUM).
- Page 14 REGULATE THE POTENTIOMETERS At the end of each cleaning cycle, and before switching off the machine, it is important to lower the potentiometers to the minimum. At the beginning of a new cleaning cycle, and once the machine is with the switches turned on, we always recommend to regulate the potentiometers to the maximum.
- Page 15 TIMER The 2300 LPH COMPACT PRO model has a pre-programmed 60 minutes timer. (ONLY FOR 4600 LPH COMPACT PRO MODEL) The timer comes with a 60 minutes cycle factory preset. Restart the machine and check the levels every 60 minutes cycle.
- Page 16 MANOMETER CONTROL ESSENTIAL THAT, BEGINNING EVERY CLEANING CYCLE, USER KEEP MANOMETER UNDER CONTROL. IF THE PRESSURE EXCEEDS THE RED LINE, THE MACHINE MUST BE SHUT DOWN IMMEDIATELY. IF THIS HAPPENS PLEASE CONTACT THE TECHNICAL SERVICE. IF EVERYTHING IS CORRECT, THE ORTHO-OXYHYDROGEN WILL FLOW INTO THE VEHICLE INTAKE AND THE POTENTIOMETRES CAN BE REGULATED AS NEEDED.
- Page 17 PROCEDURE FOR THE CLEANING: HOW DOES OUR GAS ACTS INSIDE A ENGINE: Our units use a high efficiency electrolysis system (pulsed electronics) and are equipped with own development security and control systems, legally protected, distinguishing from any other of the market. After multiple tests carried out by ourselves and by high specialized centers, we have achieved and verified that the Ortho-Oxyhydrogen gas has chemical and electrical affinity with the deposited carbon, wich makes them tend to join together, and that is...
- Page 18 Our technical-commercial service will explain and demonstrate the best method to obtain better results. If we have a latent damage of particulate filter that is not deleted, we will try to delete it during the cleaning cycle. If we are successful deleting it, that will provoque the vehicle to turn into an automatic regeneration or to allow making a forced regeneration later.
- Page 19 MANUAL FOR THE WELDING TORCH IN MACHINES WITH ELECTRONICS: 1) Place the manual override on the jack. 2) Turn the switches on and set the potentiometers to the maximum value. 3) Press manual ignitor both buttons simultaneously. 4) Conect the welding torch spear to the machine while pulling the spear trigger to let the gas flow constantly.
- Page 20 EXAMPLES OF POSSIBLE THEMES WITH OUR WELDING TORCH/WELDER Welds and melts gold and silver. Welds and melts copper with copper, with or without input. Welds and melts copper with stainless steel. Welds and melts copper with alpaca. Welds and melts copper with bronze. Welds and melts bronze with bronze, with or without input.
-
Page 21: Maintenance
* DO NOT SMOKE – DO NOT APPROACH FLAMES OR SPARK SOURCES * IN CASE OF DOUBTS ALWAYS CONTACT THE TECHNICAL SERVICE * DO NOT OPEN THE MACHINE WITHOUT CONSENT OF THE MANUFACTURER * CLEAN WITH A CLOTH DAMPENED AND ALCOHOL * DO NOT COVER THE VENTILATION GRILLES VERY IMPORTANT: - NEVER APPROACH FLAME SOURCES CLOSE TO THE FILLING CAPS,... - Page 22 THIS EQUIPMENT HAS BEEN DESIGNED FOR AN INTENSIVE USE. Features of EACH MODEL: * Adjustable timer from 0 to 99 minutes. * Temperature sensor with automatic start and stop of ventilation. * Solenoid Viton valve between the tank and the bubbler. * Solenoid Viton valve between the internal bubbler and the exterenal diesel bubbler.
-
Page 23: Digital Screen
- Restores the initial engine performance and consumption (savings between 5% to 15% of the consumption). - Reduces acceleration gaps, noises and vibrations of the engine. - Increases engines life-time. - Reduces the pollutant gas emissions resulting from the fuel combustion. - Facilitates and allows to pass the vehicle inspection regarding with HC emissions (uncombusted hydrocarbons). - Page 24 LPH 4600 COMPACT PRO MODEL UNLADEN WEIGHT 90KG – TANK CAPACITY 50 L Page 22...
- Page 25 LPH 2300 COMPACT PRO MODEL UNLADEN WEIGHT 55KG – TANK CAPACITY 30 L Page 23...
- Page 26 PROBLEMS AND SOLUTIONS THE MACHINE DOES NOT START • Check the emergency stop button (unlock). • Check the plug connection. • Check the line (network), circuit breaker and differential. THE SCREEN LIGTHS UP, BUT THE SOURCE DOES NOT START • Check that the machine breaker(s) are down.
- Page 27 THE PRESSURE RAISES ABOVE THE INDICATED VALUE AND THE MACHINE DOES NOT STOP • Turn immediately the machine off and check if the pressure switch is out of adjustment, in accordance with the manual instructions. After the relevant reviews and if the pressure switch continues to fail, may be that was broken or disconnected.
- Page 28 1 YEAR MANUFACTURER WARRANTY LIFETIME EXPANDABLE Econovedades I-D-i SL, investigation, development and manufacturer of Ortho- Oxyhydrogen gas generation equipments company: Certifies and guarantees that the units are lack of manufacturing defects and consequently is commited to repair or replace, under the conditions mentioned below, those elements damaged during a period of 12 months, from the machine purchase date, provided that these damages are to a manufacturing defects attributables and not to an inappropriate use of the same.
- Page 29 5- In the event that confirmation of defects during the guarantee validity period, Econovedades I-D-i SL will decide the the way to carry out the repairs. Econovedades I-D-i SL, freely and discretionaly, can opt by replacing the damaged product for one free of defects instead of making repairs. The guarantee does not grant the right to claim the replacement for a free of defects product or the purchase contract resolution and the refund of the paid amount.
- Page 30 11- Transport of pieces and machine replacement are covered by the guarantee. 12- The lifelong guarantee is extended when the maintenance services is yearly hired, wich will enter into force from the second year. See conditions. *Ver condiciones Page 28...
-
Page 31: Declaration Of Conformity
DECLARATION OF CONFORMITY THE MANUFACTURER: ECONOVEDADES IDI S.L. CIF: B-27786086 Parque Tecnológico Porto do Molle Rúa da Madanela 16, Nave 7C ES-36350 Nigran (Pontevedra) -SPAIN- Declares that the ORTHO-OXYHYDROGEN production equipments MODELS: LPH 4600 COMPACT PRO LPH 2300 COMPACT PRO LPH 300 COMPACT Comply with the EC current security regulations and directives, specified below:... - Page 32 Page 30...
- Page 33 34 | P á g i n a...
- Page 34 35 | P á g i n a...
- Page 36 www.ecodecarbonizer.com www.oxyhydrogen-technologies.com Fabricante: Econovedades I+D+i Econovedades info@econovedades.com...
