Toshiba 32LV17 Service Manual

Lcd color television
Hide thumbs Also See for 32LV17:
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
This model is classified as a
This Service Manual describes replacement parts for the green product. When repairing this
green product, use the part(s) described in this manual and
For (*1) and (*2), refer to
SOLDER.
© TOSHIBA CORPORATION
file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-...
LCD Color Television
32LV17
green product
(*1), as indicated by the underlined serial number.
GREEN PRODUCT PROCUREMENT
Ver. 1.01
lead-free solder
(*2).
and
LEAD-FREE
Стр. 1 из 1
30.04.2015

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 32LV17

Summary of Contents for Toshiba 32LV17

  • Page 1 This Service Manual describes replacement parts for the green product. When repairing this green product, use the part(s) described in this manual and lead-free solder (*2). For (*1) and (*2), refer to GREEN PRODUCT PROCUREMENT LEAD-FREE SOLDER. © TOSHIBA CORPORATION file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 2: Green Product Procurement

    Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.

  • Page 3: Lead-Free Solder

    Great care should be made to ensure high-quality soldering when servicing this product especially when soldering large components, through-hole pins, and on PCBs as the level of heat required to melt lead-free solder is high. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 4: Important Notice

    Through WEB, ver. 6.5 has been released but with it, the linking function in this manual may not work properly. If ver. 6.5 has been installed, uninstall it and reinstall ver. 6.0. To get ver. 6.0, click the icon, or contact to the nearest Toshiba Service Centre for further assistance. Freezing windows opened (Cannot close the open windows) This may happen occasionally.
  • Page 5 With this condition, the menu indication color may stick to the GRAY color or Windows may freeze if clicking other menu. To avoid such things, do not operate any others while menu turns GRAY color. If entering this, re-open the service manual or refresh the left frame. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 6 In that case, perform the Internet Explorer setting using the following procedure to restore normal operation. 1. Windows version check [My Computer (right-click)] - [Properties] 2. Internet Explorer setting [Tools] - [Internet Options] file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 7: Operating Environment

    Стр. 2 из 4 Operating Environment : Pentium III or higher recommended Monitor : 1024 x 768 or higher resolution recommended file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 8 Connecter destinations can also be searched in the same way. When two or more search results are provided, their drawing names are displayed, allowing you to choose a desired drawing to display. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 9 Specified Area Printing Function The Autodesk DWF Viewer enables to print the displayed drawing region as it is on a printer. It also allows to print a large-sized drawing in multiple pieces (tile printing). file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 10 WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.

  • Page 11: Service Mode

    1. Set VOLUME to minimum and press MUTE button twice on Control. ↓ 2. Press MUTE button again and hold button down. ↓ Service Mode display 3. While holding the MUTE button, press MENU button on TV set. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 12 [ SERVICE MODE ] ADJUSTING ITEMS AND DATA IN THE SERVICE MODE: Note: (1) The image system data may be different for each image format chosen. The factory preset data value is indicated in the table. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 13 R-DRV R DRIVE G-DRV G DRIVE B-DRV B DRIVE *BRTC BRIGHTNESS CENTER *COLC COLOR CENTER *UVTT BASE BAND TINT *CNTX CONTRAST MAX SHRC SHARPNESS CENTER VBIS VBI Setting Closed Caption VBID Gemstar BYBK B-Y OFF SET file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 14 ALOF Reduce in ALL (wow, TruSurround) off VSTB Reduce Volume For Stable Sound VS3D Reduce Volume For SRS3D VFCS Reduce Volume For FOCUS VTBH Reduce Volume For TruBass High VTBL Reduce Volume For TruBass Low file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 15 2. Whenever using new signal board to the set, setting the SET-ID data according to panel option data. Panel Maker OPT4 Set Size OPT3 OPT5 SET-ID Running change TOP Running change LV67 26 SAMSUNG SHARP SAMSUNG LV37 32 SHARP SAMSUNG LV17 32 SHARP SAMSUNG file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 16: Exit From Service Mode

    (5) Total brightness hour of TV. : Display 4 bytes data. (6) Operation hour of TV in LOW mode : Display 4 bytes data. (7) Operation hour of TV in HIGH BRIGHT mode : LCD Model not used. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 17: Led Indication

    1 Green and Yellow are off. Power supply OFF. (AC) 2 Green and Yellow are off. Power supply OFF. (Stand by) 3 Green is on (solid). The TV is operating properly. 4 Yellow is on (solid). A disk is in the disk slot. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 18 Wait several seconds until the yellow LED stops blinking. 9 Green is on (solid). Upgrading in progress. Yellow is on (solid). 10 Green is on (solid). Upgrading succesful. Yellow is off. 11 Green is off. Upgrading failed. Yellow is on (solid). file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 19 Стр. 1 из 2 FUNCTION AND OPERATION TV Front and Side Panel Control and Connection file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 20 Стр. 2 из 2 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 21: Function And Operation

    Стр. 1 из 3 FUNCTION AND OPERATION Learning about the Remote Control file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 22 Стр. 2 из 3 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 23 Стр. 3 из 3 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 24 Стр. 1 из 4 FUNCTION AND OPERATION Programming Channel into the TV's Channel Memory Programming Channel Automatically file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 25 Стр. 2 из 4 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 26 Стр. 3 из 4 Manually Adding and Deleting Channel in the Channel Memory file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 27 Стр. 4 из 4 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 28: Safety Instruction

    LCD cover and fasten with screws. Do not strongly push on the module because any impact can adversely affect the performance. Also use caution when handling the polarized screen because it can easily be damaged. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 29 Immediately remove any type of fluid from the screen. 5. Glass is used in the panel, so do not drop or strike with hard objects. Such actions can damage the panel. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 30 Failure to do so could result in freezing of the liquid crystal due to cold air or loss of resilience or other damage. 9. Do not disassemble the LCD module. Such actions could result in improper operation. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 31 Стр. 4 из 4 10. When transporting the LCD module, do not use packing containing epoxy resin (amine) or silicon resin (alcohol or oxim). The gas generated by these materials can cause loss of polarity. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 32 U03D U02A LOW-B U01A POWER U03E DVD-Key U04A SEINE U03B U03A TUNER-AV DVD Unit Front-AV U03F DVD-IF U03C LED...

  • Page 33: Safety Precaution

    6. Always use the replacement parts specified for the particular model when making repairs. The parts used in products require special safety characteristics such as file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 34 0.15 µF capacitor. Reverse the AC plug at the AC outlet and repeat AC voltage measurements for each exposed metallic part. Voltage measured must not exceed 0.3 volts rms. This corresponds to 0.2 milliamp. AC. Any value exceeding this file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 35: Product Safety Notice

    Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement parts which do not have the same safety characteristics as specified in the parts list may create electrical shock, fire, or other hazards. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 36: Specification

    Стр. 1 из 3 SPECIFICATION file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 37 Стр. 2 из 3 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 38 Стр. 3 из 3 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 56: Schematic Diagram

    10 W : Cement of 10 watt : ±10 % : ±2 % : ±1 % 2. CAPACITOR Unless otherwise noted in schematic, all capacitor values less than 1 are expressed in µF, and the values more than 1 in pF. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 57 AC volts. 5. Waveforms are taken receiving color bar signal with enough sensitivity. 6. Voltage reading shown are nominal values and may vary ±20 % except H.V. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 156 Стр. 1 из 2 CABINET Stand Exploded View A425 A426 A427 A428 A429 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 157 Стр. 2 из 2 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 158 Accessory Стр. 1 из 1 Accessory Location Parts No. Description K902 75005729 REMOCON HAND UNIT, CT-90275 Y102 75006562 MANUAL, OWNERS MANUAL E/F Y109 23945015 BAG, POLYETHYLENE COVER 250X400 Y170 23845800 HOLDER, WIRE, NYLON66 D6.8 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 159 LEG SCREW CAP PP 5*12 SBN A429 75007210 LEG STAND WRENCH A430 75005733 CLAMP HOLDER A461 23950113 LABEL, SERIAL NUMBER, TTX3 A532 23717240 SCREW, BITTB3X10SZN A541 75005738 PANEL PIECE DVD ASSY A545 75005735 PIECE, CASE DVD file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 160 CABLE, 20624 ASFBNCD-TN2-P=0.5-K1-45-172 Z 4/15BL UL MZ01 75005837 WIRE HARNESS, LVDS, V90A00064200 P801 75002678 POWER CORD, INQ2682(1) PP08 23974994 BAND, KESSOKU PP12 23974994 BAND, KESSOKU PP13 23845834 LEAD CLAMPER W661 75005717 SPEAKER ASSY, SPK1493AO, 60X120 8-OHM 10W file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 161 Location Parts No. Description A701 75006563 CARTON TOP CASE, TOP CASE A702A 75006548 PAD TOP PACKING, TOP PACKING A702B 75006549 PAD BOTTOM PACKING, BOTTOM PACKING A703 23945143 BAG, PROTECTIVE A706 75006551 CARTON O/M CASE, O/M CASE file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...

  • Page 162: Parts List

    Abbreviations Capacitors CD : Ceramic Disk Resistors : Carbon film OMF : Oxide Metal Film : Plastic Film : Carbon Composition : Variable Resistor file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 163 Стр. 2 из 2 : Electrolytic : Metal Film : Fusible Resistor All CD and PF capacitors are ±5 %, 50 V and all resistor, ±5 %, 1/6 W unless otherwise noted. file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 164 76092569 CAPACITOR, CERAMIC DISC, AC250V E 2200PF M CE14 76092569 CAPACITOR, CERAMIC DISC, AC250V E 2200PF M CE15 76092337 CAPACITOR, CERAMIC DISC, 2KV 220PF K CE16 76073181 CAPACITOR, ELECTROLYTIC, 35V 56UF M CE17 76092339 CAPACITOR, CERAMIC DISC, 2KV 330PF K file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 165 DE12 23357512 DIODE, AL01Z DE13 23357512 DIODE, AL01Z DE14 23357512 DIODE, AL01Z DE15 23357892 DIODE, ZENER, MTZJ27B DE16 23357880 DIODE, ZENER, MTZJ20B DE17 23357512 DIODE, AL01Z DE19 23357854 DIODE, ZENER, MTZJ10B DE72 23357366 DIODE, FR105-B5 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 166 23713759 PLUG, 8P 2.5MM G, B8B-EH-F1-TV4 PG03 23165495 EARTH TERMINAL, MET31-0332 PG04 23165495 EARTH TERMINAL, MET31-0332 Q801 75001933 IC, STRZ4517 Q826 23000823 IC, PHOTO COUPLER, TLP421F(GR) Q851 23205463 TRANSISTOR, 2SC2712-Y(TE85L, F) Q852 23205463 TRANSISTOR, 2SC2712-Y(TE85L, F) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 167 76871681 RESISTOR, CHIP, 1/8W 680 OHM J RE43 76011753 RESISTOR, CHIP, 1/20W 75K OHM J RE44 76000593 RESISTOR, CHIP, 1/16W 10K OHM F RE46 76000605 RESISTOR, CHIP, 1/16W 6.8K OHM F RE48 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 168 U01A POWER (PE0246) Стр. 5 из 5 RE50 76011821 RESISTOR, CHIP, 1/20W 820 OHM J SR81 23146597 RELAY, DC5V 0.25W, DG5D1-O(M)-2 T801 23211920 COIL, LINE FILTER, TRF3258AD T862 75004576 TRANSFORMER, ST-3243 TE62 23217840 TRANSFORMER, CONVERTER, TPW3585AD file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 169 DIODE, ZENER, MTZJ12C D863 23357866 DIODE, ZENER, MTZJ12C DE51 75005719 DIODE, D1NS4-5060 DE52 23357703 DIODE, 1SS355 DE53 23357842 DIODE, ZENER, MTZJ6.8B DE54 23357703 DIODE, 1SS355 DE55 23357748 DIODE, ZENER, MA8062-M DE56 23362133 DIODE, ZENER, UDZS 30B file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 170 IC, MP1591DS-LF-Z QE52 75005726 IC, PQ070XF01SZH QE52B 23717240 SCREW, BITTB3X10SZN QE53 23205330 TRANSISTOR, RN1403(F) QE54 23205567 TRANSISTOR, RN2403(TE85L, F) QE64 23085415 IC, BD4746G QE65 23085415 IC, BD4746G QE66 23205327 TRANSISTOR, RN1406(F) QE71 75001881 IC, CE-1059 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 171 RESISTOR, CHIP, 1/8W 2.2K OHM J RE54 76871222 RESISTOR, CHIP, 1/8W 2.2K OHM J RE55 76019388 RESISTOR, CHIP, 1/16W 10K OHM F RE56 76011221 RESISTOR, CHIP, 1/20W 220 OHM J RE57 76019386 RESISTOR, CHIP, 1/16W 5.6K OHM F file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 172 RESISTOR, CHIP, 1/20W 47K OHM J RE95 76553122 RESISTOR, OXIDE METAL FILM, 1W 1.2K OHM J RE96 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RE97 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RE98 76011104 RESISTOR, CHIP, 1/20W 100K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 173 76092883 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K C635 76815473 CAPACITOR, CERAMIC CHIP, 50V B 0.047UF K C640 76105030 CAPACITOR, CERAMIC CHIP, 50V CJ 3PF C C641 76105030 CAPACITOR, CERAMIC CHIP, 50V CJ 3PF C file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 174 76105330 CAPACITOR, CERAMIC CHIP, 50V CH 33PF J CA40 76092883 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K CA41 76092883 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K CA42 76092883 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 175 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K CN70A 23713819 SOCKET, TWG-P23X-A1 CN71A 23713819 SOCKET, TWG-P23X-A1 CN72A 23713819 SOCKET, TWG-P23X-A1 CR01 76105470 CAPACITOR, CERAMIC CHIP, 50V CH 47PF J CR02 76105470 CAPACITOR, CERAMIC CHIP, 50V CH 47PF J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 176 76092731 CAPACITOR, CERAMIC CHIP, 16V B 1UF K CS103 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CS104 76092731 CAPACITOR, CERAMIC CHIP, 16V B 1UF K CS105 76092726 CAPACITOR, CERAMIC CHIP, 10V B 2.2UF K file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 177 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K CV121 76073015 CAPACITOR, ELECTROLYTIC, 10V 47UF M CV122 76105100 CAPACITOR, CERAMIC CHIP, 50V CH 10PF D CV123 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K CV124 76666101 CAPACITOR, ELECTROLYTIC, 16V 100UF M file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 178 DA02 23357745 DIODE, ZENER, MA8056-M DA03 23357745 DIODE, ZENER, MA8056-M DA04 23357745 DIODE, ZENER, MA8056-M DA05 23357745 DIODE, ZENER, MA8056-M DA06 23357745 DIODE, ZENER, MA8056-M DA07 23357745 DIODE, ZENER, MA8056-M DA08 23357745 DIODE, ZENER, MA8056-M file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 179 TUNER, ENG36E02KF IC01 75005728 IC, TMP91FY42FG(JZ) IC02 75001222 IC, BR24L16F-WE2 IC05 23009978 IC, NJM2804U1-3342(TE1 IC20 23085100 IC, TC7W66FU(LF) IC200 75005720 IC, TB1328FG(DRY) IC201 75005722 IC, MM1731XVBE IC203 23085392 IC, MM1501XN L101 23248398 COIL, CHOKE, TLN3278D file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 180 LV121 23103272 EMI FILTER, TEM2034AD LV122 23103272 EMI FILTER, TEM2034AD LV123 23103272 EMI FILTER, TEM2034AD LV124 23103272 EMI FILTER, TEM2034AD P601 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4 P811B 23023384 PLUG, TWG-P13P-A1 P812B 23023385 PLUG, TWG-P15P-A1 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 181 TRANSISTOR, FET, 2SK2035(TE85L, F) QA11 75001961 TRANSISTOR, FET, 2SK2035(TE85L, F) QG01 75005721 IC, AN5832SA-E1V QS01 23205347 TRANSISTOR, KTC4075Y/P QS02 23205347 TRANSISTOR, KTC4075Y/P QS03 23205424 TRANSISTOR, KTC2875B/P QS04 23205424 TRANSISTOR, KTC2875B/P QS05 23205325 TRANSISTOR, RN2404(F) QS101 23085950 IC, NJW1180AFP1 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 182 RESISTOR, CHIP, 1/20W 150K OHM J R624 76011154 RESISTOR, CHIP, 1/20W 150K OHM J R625 76000445 CHIP JUMPER, 1608TYPE R626 76011333 RESISTOR, CHIP, 1/20W 33K OHM J R645 76011473 RESISTOR, CHIP, 1/20W 47K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 183 RESISTOR, CHIP, 1/20W 10K OHM J R6603 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RA10 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RA11 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RA12 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 184 RESISTOR, CHIP, 1/20W 100 OHM J RA68 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RA70 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RA71 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RA73 76011101 RESISTOR, CHIP, 1/20W 100 OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 185 RESISTOR, CHIP, 1/20W 100 OHM J RA231 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RA232 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RA234 76000445 CHIP JUMPER, 1608TYPE RA236 76011474 RESISTOR, CHIP, 1/20W 470K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 186 RESISTOR, CHIP, 1/20W 33 OHM J RR07 76000445 CHIP JUMPER, 1608TYPE RR08 76000445 CHIP JUMPER, 1608TYPE RR09 76000445 CHIP JUMPER, 1608TYPE RS01 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RS02 76011101 RESISTOR, CHIP, 1/20W 100 OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 187 RESISTOR, CHIP, 1/20W 100 OHM J RS105 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RS106 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RS107 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RS108 76011333 RESISTOR, CHIP, 1/20W 33K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 188 RESISTOR, CHIP, 1/20W 560 OHM J RV167 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RV168 76011561 RESISTOR, CHIP, 1/20W 560 OHM J RV169 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RV170 76011561 RESISTOR, CHIP, 1/20W 560 OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 189 RESISTOR, CHIP, 1/20W 100 OHM J RV200 76000445 CHIP JUMPER, 1608TYPE RV201 76000445 CHIP JUMPER, 1608TYPE RV202 76000445 CHIP JUMPER, 1608TYPE RV203 76000445 CHIP JUMPER, 1608TYPE RV204 76000445 CHIP JUMPER, 1608TYPE RV205 76000445 CHIP JUMPER, 1608TYPE X501 23153607 CRYSTAL, 3.58MHZ file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 190 PV25B 23713939 CONNECTOR, B6B-PH-K-S(LF) PV60 23365275 PHONO JACK, 3P V-L-R, YKC21 RC11 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RC12 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RV220 76011750 RESISTOR, CHIP, 1/20W 75 OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 191 RESISTOR, CHIP, 1/20W 47 OHM J RB10 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RB15 76011221 RESISTOR, CHIP, 1/20W 220 OHM J RB16 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB17 76011102 RESISTOR, CHIP, 1/20W 1K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 192 SA01 23344507 SWITCH, PUSH, SKHHLMA010 SA02 23344507 SWITCH, PUSH, SKHHLMA010 SA03 23344507 SWITCH, PUSH, SKHHLMA010 SA04 23344507 SWITCH, PUSH, SKHHLMA010 SA05 23344507 SWITCH, PUSH, SKHHLMA010 SA06 23344507 SWITCH, PUSH, SKHHLMA010 SA07 23344507 SWITCH, PUSH, SKHHLMA010 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 193 SA01 23344507 SWITCH, PUSH, SKHHLMA010 SA02 23344507 SWITCH, PUSH, SKHHLMA010 SA03 23344507 SWITCH, PUSH, SKHHLMA010 SA04 23344507 SWITCH, PUSH, SKHHLMA010 SA05 23344507 SWITCH, PUSH, SKHHLMA010 SA06 23344507 SWITCH, PUSH, SKHHLMA010 SA07 23344507 SWITCH, PUSH, SKHHLMA010 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 194 RESISTOR, CHIP, 1/20W 10K OHM J RD78 76000445 CHIP JUMPER, 1608TYPE SA11 23344505 SWITCH, PUSH 1C1P SA12 23344505 SWITCH, PUSH 1C1P SA13 23344505 SWITCH, PUSH 1C1P SA14 23344505 SWITCH, PUSH 1C1P SA15 23344505 SWITCH, PUSH 1C1P file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 195 75005713 CONNECTOR, FH12-45S-0.5SV(55) QD01 23205327 TRANSISTOR, RN1406(F) QD05 75005782 IC, PQ012FZ01ZPH RD01 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RD02 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RD04 76011103 RESISTOR, CHIP, 1/20W 10K OHM J file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 196 RD60 76000445 CHIP JUMPER, 1608TYPE RD61 76000445 CHIP JUMPER, 1608TYPE RD62 76000445 CHIP JUMPER, 1608TYPE RD63 76000445 CHIP JUMPER, 1608TYPE RD64 76000445 CHIP JUMPER, 1608TYPE RD65 76000445 CHIP JUMPER, 1608TYPE RD66 76000445 CHIP JUMPER, 1608TYPE file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 197 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C134 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C135 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C136 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C137 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C138 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 198 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C301 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C302 V03GD0000828 CHIP CERAMIC CAPACITOR (1005) C303 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C304 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C305 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 199 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C609 V03GD0000842 CHIP CERAMIC CAPACITOR (1005) C610 V03GD0000842 CHIP CERAMIC CAPACITOR (1005) C611 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C612 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C613 V03GD0000767 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 200 V03GD0000822 CHIP CERAMIC CAPACITOR (1005) C921 V03GD0001319 CHIP CERAMIC CAPACITOR (3216) C922 V03GD0001319 CHIP CERAMIC CAPACITOR (3216) C923 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C924 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C925 V03GD0000800 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 201 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C1001 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C1002 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1003 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C1004 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1005 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 202 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1043 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1044 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1045 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1046 V03GD0000828 CHIP CERAMIC CAPACITOR (1005) C1048 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 203 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1200 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1201 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1202 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1203 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1204 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 204 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1243 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1244 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1245 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C1246 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C1247 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 205 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C6423 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) C6434 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C6435 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C6471 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C6472 V03GD0000763 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 206 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8091 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8092 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8093 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8094 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8095 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 207 V03GD0000715 CHIP CERAMIC CAPACITOR (1608) C8528 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8529 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8530 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8531 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) C8532 V03GD0000786 CHIP CERAMIC CAPACITOR (1005) file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 208 V13GD0000249 CHIP BEADS INDUCTOR (2012) FL951 V13GD0000249 CHIP BEADS INDUCTOR (2012) FL952 V13GD0000249 CHIP BEADS INDUCTOR (2012) FL953 V13GD0000249 CHIP BEADS INDUCTOR (2012) FL954 V13GD0000249 CHIP BEADS INDUCTOR (2012) FL955 V13GD0000249 CHIP BEADS INDUCTOR (2012) IC100 75005767 file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 209 IC804 75005771 IC810 75005772 IC921 V47GD0001102 DC/DC CONVERTER IC922 V47GD0001102 DC/DC CONVERTER IC951 V47A00006100 IC LOW VOLTAGE REGULATOR L300 75002132 CHIP INDUCTOR L301 75002132 CHIP INDUCTOR L600 V05GD0000486 CHIP INDUCTOR(3225) L819 V13GD0000246 CHIP BEADS INDUCTOR file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
  • Page 210 U04AS SEINE (PE0249) Стр. 14 из 14 L820 V13GD0000246 CHIP BEADS INDUCTOR L821 V13GD0000246 CHIP BEADS INDUCTOR L831 75002132 CHIP INDUCTOR file://D:\Documents and Settings\Admin\Рабочий стол\toshiba_32lv17_sm\32LV17-... 30.04.2015...
