Phoenix Gaming Hub II 45506171 Manual

Download this manual

Item#: 45506171

Customer Service:

800-747-2660

Ver. 01 04/13/21

Need help?

Do you have a question about the Gaming Hub II 45506171 and is the answer not in the manual?

Page 1 Item#: 45506171 Customer Service: 800-747-2660 Ver. 01 04/13/21...
Page 2: Assembly Tips
Assembly Tips: Become familiar with the instructions and all parts. Make sure that all parts are in the box and in good condition. Assemble the product on the open flat carton or a rug to protect the product and your floor. Some heavy products need a second person to assist in the assembly.
Page 3 Parts List/ Lista de Piezas Item Components Item Components Philips screwdriver needed 2 Velcro cable ties included (not included). Herramanientas requeridas Velcro cable tie size 8.66 in. (no incluidas).
Page 4 Q x 4 O x 4 R2 x 4 Combine panels (D), (G) and (C) using 4 dowels (Q). On back, using 4 screws (R2), screw in back panel (E) with Phillips screwdriver. Take 4 cam locks (O) and insert them into inside top of panels (D) and (C).
Page 5 S x 8 Attach metal panels (F) and (K) on each side of frame with screws (S) using a Philiips screwdriver. Fije los paneles metálicos (F) y (K) a cada lado del marco con tornillos (S) utilizando un destornillador Phillips. T x 8 S x 8 U x 8...
Page 6: Product Warranty
N x 4 Insert 4 pegs (N) into holes inside frame at desired height. Then place shelf (H) into place. Inserte 4 clavijas metálicas (N) en los agujeros del interior del marco a la altura deseada. A continuación, coloque el estante (H) en su lugar.
