Summary of Contents for AKKU SYS a-TroniX 1kVA-EBP
- Page 1 EXTENDED BATTERY PACK User Manual 1kVA bis 3kVA Tower UPS Model Article number a-TroniX Extended battery Pack 24V 9885152 a-TroniX Extended battery Pack 48V 9885154 a-TroniX Extended battery Pack 72V 9885155 09/2021 Page 1...
- Page 2 All rights reserved. AKKU SYS Akkumulator- und Batterietechnik Nord GmbH cannot be held responsible for any inaccuracies or inappropriate information in this instruction manual. The information in this document is subject to change without notice, but there is no obligation to update it on an ongoing basis.
-
Page 3: Table Of Contents
User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA Table of Contents Page 1. Important Safety Warning 2. Symbols and abbreviations used in this guide 3. Installation 4. Operation 5. Maintenance 6. Specifications 1. Important Safety Warning This manual contains important notes and instructions that you have to follow during installation and maintenance your extended battery pack (EBP). -
Page 4: Symbols And Abbreviations Used In This Guide
User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA 2. Symbols and abbreviations used in this guide Accumulators are usually used as an energy storage for a UPS system (Uninterruptible Power Supply). These are also colloquially referred to as accumulators or batteries. Battery cabinets are abbreviated as EBPs. -
Page 5: Installation
User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA 3. Installation Inspecting the Equipment If any equipment has been damaged during shipment, keep the shipping ■ cartons and packing materials for the carrier or place of purchase and a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage. - Page 6 User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA Battery installation Connect the batteries in their battery cabinet according to the following Figure 1: for a-TroniX Extended Battery Pack 72V for a-TroniX Extended Battery Pack 48V Figute 1 Battery installation for a-TroniX Extended Battery Pack 24V Page 6 09/2021...
- Page 7 User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA To install the optional EBP(s) for a UPS 1. On the rear of the UPS, remove the cable retention clip covering the battery connector. Retain the clip. See Figure 2. 2. Installations with one EBP only: Remove the cable retention clip covering the right or upper battery connector.
-
Page 8: Operation
User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA 4. Operation Configuring Battery Settings Set the UPS for the number of EBPs installed. ■ To ensure maximum battery runtime configure the UPS for the correct number of ■ EBPs refer to Figure 3 for the appropriate setting of battery numbers and type. Use the up and down buttons to select the number of battery strings according to your UPS configuration: Figure 3 –... -
Page 9: Maintenance
User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA 5. Maintenance Replacing Batteries NOTE: DO NOT DISCONNECT the batteries while the UPS is in battery mode. THE EBP can be replaced when the UPS in ON, but be aware that if the utility fails at that time, the load of the UPS may NOT be protected. - Page 10 User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA Testing New Batteries Plug the UPS into a power outlet for 48 hours to charge the batteries. ■ Start up the UPS by pressing the start-up combination button. ■ Press the battery test combination button to activate the battery test. The UPS starts ■...
-
Page 11: Specifications
User Manual Extended Battery Pack 1kVA, 2kVA, 3kVA 6. Specification MODEL 1kVA-EBP 2kVA-EBP 3kVA-EBP Voltage 208/220/230/240 VAC INPUT Frequency 50/60 Hz Input Protection Resettable Circuit Breaker DC Voltage 27.7/41.25 ± 0.5V 55/82.5/110 ± 0.5V 82.5/110 ± 0.5V CHARGER OUTPUT DC Current 1.4 A Output Protection Fuse... - Page 12 AKKU SYS complete catalogue: Go to our catalogue: AKKU SYS Akkumulator- und Batterietechnik Nord GmbH Verbindungsweg 23 · 25469 Halstenbek / Hamburg · GERMANY Tel. +49 4101 | 3 76 76-0 / Fax +49 4101 | 3 76 76-66 / info@akkusys.de / www.akkusys.de...
