- Page 1 PRODUCT MANUAL PRE-START WARNING CONTROLLER 12/24V Part No. 12539 | 12727 | 12728...
- Page 2 RCT provides the document to you on an “as is” basis. RCT is not required to provide any updates to this version of the document. RCT may make any change, amendment or modification to the contents in this document without notice to you.
-
Page 3: Table Of Contents
Contents GENERAL SAFETY WARNINGS PRODUCT OVERVIEW FEATURES AND FUNCTIONS OPERATION AND USE CONTROLLER STATUS INDICATOR OPERATION INSTALLATION GUIDE WIRING CONNECTIONS UPGRADE CONNECTION DETAILS EXTERNAL WIRING DIAGRAM (512a) CALIBRATION SERVICE INFORMATION SERVICE SCHEDULE SERVICE PROCEDURE PARTS LIST 12727 KIT, PRE-START WARNING WITH ALARM 12728 KIT, PRE-START WARNING NO ALARM TECHNICAL SPECIFICATIONS COMPLIANCE AND STANDARDS... -
Page 4: General Safety Warnings
Ensure electrical connections are made as per RCT’s recommendations. Test circuits prior to connecting power to any component. ■ The equipment contains no user serviceable parts inside. Return the unit to RCT for repairs. ■ Retain product and installation instructions for future use. -
Page 5: Product Overview
PRODUCT OVERVIEW The Muirhead ® Prestart Warning Controller, part number 12539, is designed to warn personnel that a machine is about to start/crank by activating an alarm for a selected time period prior to allowing the machine to start. The timer is automatically triggered when the ignition switch is turned to the start position. The pre-start time duration is configurable to suit the application. -
Page 6: Installation Guide
INSTALLATION GUIDE Install the controller in a suitable location. Refer to the wiring table below and the wiring diagram in this manual to connect the controller. It is recommended that the wiring is installed alongside the OEM wiring ensuring that it is secured at regular intervals;... -
Page 7: Upgrade Connection Details
UPGRADE CONNECTION DETAILS Refer to the following table if you are upgrading from an older RCT prestart warning timer (part number 2625 and 6337) to the 12539. The following connections can be re-used when upgrading any connections not listed here will still need to be connected as per the previous wiring connection table. -
Page 8: External Wiring Diagram (512A)
EXTERNAL WIRING DIAGRAM (512a) 8 | 16 M0937.docx | Rev 1.4 | Modified on 29/03/2021 | © Remote Control Technologies Pty Ltd... -
Page 9: Calibration
For example, if inputs 1 and 4 are connected to GND and inputs 2 and 3 are not connected the total prestart warning time would be 4+2+16 = 22 seconds. The default pre-start warning time can be adjusted between 4 and 10 seconds via the programmable controller utility program available from RCT. INPUT 1... -
Page 10: Parts List
PARTS LIST 12727 KIT, PRE-START WARNING WITH ALARM QUANTITY PART NO. DESCRIPTION INCLUDED PARTS SUGGESTED SPARES Controller 12539 12738 Generic Loom 6162 Alarm warning 102 dB 12/24 V 0824 Terminal to suit Alarm 12728 KIT, PRE-START WARNING NO ALARM QUANTITY PART NO. -
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS Dimensions, controller only Length: 119 mm | Width: 80 mm | Height/Depth: 65 mm Dimensions, boxed for freight Length: 220 mm | Width: 120 mm | Height/Depth: 120 mm Weight, controller only 255 g Weight, including loom / packaging 600 g for freight Input nominal voltage... -
Page 12: Compliance And Standards
COMPLIANCE AND STANDARDS RCT has an obligation as a manufacturer to comply with the regulations as required by the relevant regulatory bodies, depending on the market and location. This product currently complies with the following: ACMA ■ IEC 61000-6-1:2005 Electromagnetic Compatibility (EMC) – Part 6-1: Generic Standards – Immunity for Residential, Commercial and Light Industrial Environments. - Page 13 NOTES 13 | 16 M0937.docx | Rev 1.4 | Modified on 29/03/2021 | © Remote Control Technologies Pty Ltd...
- Page 14 NOTES 14 | 16 M0937.docx | Rev 1.4 | Modified on 29/03/2021 | © Remote Control Technologies Pty Ltd...
-
Page 15: Glossary
Multi Function Unit Mega Hertz (million(s) cycles per second) Minimum millimetres WARRANTY Please see the RCT standard warranty, available on our website - www.rct-global.com. 15 | 16 M0937.docx | Rev 1.4 | Modified on 29/03/2021 | © Remote Control Technologies Pty Ltd... - Page 16 Discover more: www.rct-global.com sales@rct-global.com AUSTRALIA: +61 (0) 8 9353 6577 AFRICA: +27 (0) 83 292 4246 CANADA: +1 705 590 4001 RUSSIA / CIS: +7 (910) 411 11-74 SOUTH AMERICA: +56 3 5229 9409 USA: +1 801 938 9214...
